Side 1/2

Cardiod

Captures primary audio

from the front of the mic.

Recording use for

- Podcasting & livestreaming

- Gaming voiceover

- Instrument & voice

CVL

-2009

Owner’s Guide

Professional USB Recording Mic

with color lights

Included in box:

• Microphone with adjustable stand

• 5’ USB connection cable

• Owner’s Guide

Quick Setup

SYSTEM REQUIREMENTS:

Windows 10, Windows 8, Windows 7, Mac OS X 10.4.11, or higher

SETTING UP YOUR MICROPHONE

Connecting to your computer

rom your microphone to your Connect the USB cable (included) f

computer. For the best performance, do not connect it to a USB hub.

Windows:

Open the control panel Window.

2. In the upper-right corner, change “View by” to Small icons.

3. Double click on “Sound”, then click on the “Recording” tab.

4. Select CVL-2009, then click Set Default.

Make sure that there is a green check mark next to CVL-2009

6. s.Click Set up Microphone, then follow the on-screen instruction

7. (Optional) To adjust the microphone volume, click Properties.

Mac:

1. r, then select Applications.Open the Finde

2. referOpen System P ences, then click Sound.

3. Select the Input tab, then select CVL-2009.

re that the mute button isnMake su ’t selected.

4. Select the Output tab, then select CVL-2009.

re that the mute button isnMake su ’t selected.

Best For Use In

Podcasting &

Livestreaming

Gaming Voice &

Instrument

Skype &

Internet Calls

Owner’s

Guide

Mic Capsule

Two microphone elements with different recording

characteristics for different sound environments.

Mic Mute

The LED power indicator will light blue when properly

plugged in. Press the button to mute the microphone.

The LED will change to red while muted.

Adjustable Stand

You can adjust the Microphone tilt angle or direction to your

desired recording position.

DUAL RECORDING PATTERNS

Light Button

Press to change the multi-colored lighting with 9 color control

settings: - Select green, blue, red, purple, yellow, light blue,

continuous color shifting, rainbow, or lighting effects off.

Mic Volume

Slide up and down to adjust the microphone gain.

Headphone Jack

Plug in your own headphones to monitor your microphone

recording in real-time, without latency delays.

Micro USB port

Connect the microphone with your computer using the

provided USB cable.

Mic Pickup Pattern

Press down the button to get recording in cardioid mode.

Press the button again and the button will rise up to get sound

recording in omnidirectional mode.

Plug and play. If microphone does not set up automatically:

Omnidirectional

Captures audio equally

around the mic.

Recording use for

- Conference calls

- Surroundings /

Orchestra

Frequency: 20Hz – 20KHz

Sampling Rate: 48KHz / 24bit

Connection Type: USB

Cable Length: 5 ft / 1.5m

Stand Mount Ready: Threaded for 1/4”

stands/tripods

Using your Microphone

For best recording quality:

Speak directly into the front of the microphone

where recording pickup is optimized.

Threaded Bottom for Mic Stand:

You can remove the adjustable stand and

use the microphone with any common 1/4”

threaded tripod or stand. Thread adapters

may be added for additional stand mount

options.

Troubleshooting

If your computer is not picking up audio from the microphone, attempt the following suggestions:

1. Check the computer speaker’s volume level.

2. Check proper seating of cable connections.

3. Verify the application settings you are using. Some applications have separate volume level control.

4. Check that the computer recognizes the Microphone - showing it connected and within your computer OS settings.selected

5. Verify the within the sound/audio settings of your computer’s OS. input (recording) levels

6. Check the microphone’s mute setting. Verify LED light color. If red, press again to un-mute.

Restart your computer and re-verify the above steps. Restarting often helps a computer connect to the Microphone.

Micro USB Port

Threaded Bottom

for Mic Stand

Headphone Jack

Mic Volume

Light Button

Mic Pickup Pattern

LED Power Indicator

Mic Mute

Adjustable Stand

Mic Capsule

Please keep in mind, under Windows OS, the audio out signal will be redirected to the CVL-2009 headphone outlet. You can

change the direction of the audio signal by going to the Control Panel, Sound window, Playback tab, and change the default settings.

Compliance Information Statement:

FCC Part 15

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna

•

Increase the separation between the equipment and receiving device

•

Connect the equipment into an outlet on different circuit from the receiving device

•

Consult the dealer or an experienced radio/TV technician for help

Responsible Party - Cyber Acoustics LLC

3109 NE 109th Ave., Vancouver, WA 98682

cyberacoustics.com

Supplier’s Declaration of Conformity 47 CFR § 2.1077 Compliance Information

sponsible for compliance could void the user’s authority

to operate the equipment.

•

Produkt Specifikationer

Mærke:	Cyber Acoustics
Kategori:	Mikrofon
Model:	CVL-2009
Type:	Pc-mikrofon
Bredde:	73.66 mm
Højde:	162.56 mm
Produktfarve:	Sort
Volumenkontrol:	Dreje
Forbindelsesteknologi:	Ledningsført
Strømkilde:	USB
Kabellængde:	1.5 m
Monteringstype:	Bord
Diameter:	1.7 mm
LED-baggrundsbelysning:	Ja
Mikrofon mute:	Ja
Enhedsgrænseflade:	USB/3.5 mm
Understøttede Windows-operativsystemer:	Windows 10, Windows 7, Windows 8.1
Understøttede Mac-operativsystemer:	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Desktop beslag:	Ja
Mikrofon frekvens:	20 - 20000 Hz
Mikrofonretningstype:	Kardioide/retningsuafhængig mikrofon
Udgang til hovedtelefoner:	Ja
Mikrofon vægt:	589.6 g
Antal produkter inkluderet:	1 stk
Prøvetagningshastighed:	48 kHz
Bithastighed:	24 Bit
