Side 1/50

K01-0001023-00 EN

SMART APP SINEWAVE UPS SERIES – PROFESSIONAL RACKMOUNT SERIES

PR750ERT2UC PR750ERTXL2UC

PR1000ERT2UC PR1000ERTXL2UC

PR1500ERT2UC PR1500ERTXL2UC

PR2000ERT2UC PR2000ERTXL2UC

PR2200ERT2UC PR2200ERTXL2UC

PR3000ERT2UC PR3000ERTXL2UC

USER’S MANUAL

Thank you for purchasing the CyberPower Smart App Sinewave PR750ERT2UC/ PR1000ERT2UC/ PR1500ERT2UC/

PR2000ERT2UC/ PR2200ERT2UC/ PR3000ERT2UC/ PR750ERTXL2UC/ PR1000ERTXL2UC/ PR1500ERTXL2UC/

PR2000ERTXL2UC/ PR2200ERTXL2UC/ PR3000ERTXL2UC Uninterruptible Power Supply!

The product features 2430 Joules of surge protection, provides battery backup during power outages and is Active

PFC compatible for safeguarding mission-critical servers, telecom equipment, VoIP and internetworking hardware that

require seamless sine wave power. Its full Automatic Voltage Regulation (AVR) boost/buck technology delivers a

consistent and clean AC power, protecting connected equipment and preventing costly business interruptions. This

UPS is GreenPower UPS™ Bypass circuitry patented to save on energy costs by reducing energy consumption and heat

buildup.

The UPS unit incorporates microprocessor-based full digital control and includes PowerPanel Business software

providing the user unsurpassed flexibility and control. An optional SNMP/HTTP Remote Management adapter

(RMCARD) supports remote management and control of the machine through a standard web browser.

System Block Diagram

CyberPower GreenPower UPS

Technology

CyberPower’s patented GreenPower UPS

with Bypass Technology are ENERGY STAR®

complainant ensuring lower power consumption and energy costs compared to conventional UPS

models. Even when utility power is normal, conventional UPS models constantly pass power

through a transformer. By contrast, under normal conditions the advanced circuitry of a

GreenPower UPS

bypasses the transformer. As a result, the power efficiency is significantly

increased while decreasing waste heat, using less energy, and reducing energy costs.

When an abnormal power condition occurs, the GreenPower UPS

automatically runs power

through its transformer to regulate voltage and provide “safe” power. Since utility power is normal

over 88% of the time, the GreenPower UPS

operates primarily in its efficient bypass mode.

The GreenPower UPS

is also manufactured in accordance with the Restriction on Hazardous Substances (RoHS)

directive making it one of the most environmentally-friendly on the market today.

Input

EMI

Filter

Surge

Suppressor

AVR

Charger

AC/DC

Inverter

Output

Battery

Normal Mode

Battery Mode

INTRODUCTIONS

AUTOMATIC VOLTAGE REGULATOR (AVR)

The incoming utility power may be damaging to important data and hardware, but with Automatic Voltage Regulation, the

computer will not experience damaging voltage levels. The AVR automatically increases low or decreases high voltage to a safe

and consistent output voltage.

Produkt Specifikationer

Mærke:	CyberPower
Kategori:	Uafbrydelig strømforsyning (UPS)
Model:	PR1500ERTXL2U
Bredde:	433 mm
Dybde:	500 mm
Højde:	86.5 mm
Vægt:	36500 g
Brugervejledning:	Ja
Produktfarve:	Sort
Kontroltype:	Knapper
Skærmtype:	LCD
Pakkevægt:	38800 g
Pakkedybde:	620 mm
Pakkebredde:	560 mm
Pakkehøjde:	275 mm
USB-port:	Ja
Batteriteknologi:	Blybatterier (VRLA)
Formfaktor:	Reolbeslag/tårn
Responstid:	4 ms
Opbevaringstemperatur (T-T):	-15 - 45 °C
Relativ luftfugtighed ved drift (H-H):	0 - 95 %
Relativ luftfugtighed ved opbevaring (H-H):	0 - 95 %
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	1
Driftstemperatur (T-T):	0 - 40 °C
Husmateriale:	Metal
Kabler inkluderet:	Serial, USB cable
Støjniveau:	55.5 dB
Udgangseffekt:	1500 W
LED-indikatorer:	Ja
Kabellængde:	3.05 m
Harmoniseret systemkode (HS):	8504408590
Batteritype:	RBP0129
Antal understøttede batterier:	1
Opladningstid for batteri:	3 t
Bæredygtighedscertifikater:	CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI
Ikke-drift højde:	0 - 15000 m
Oprindelsesland:	Kina
Indgangsfrekvens:	50/60 Hz
Overholdelse af bæredygtighed:	Ja
Varmeafgivelse:	71.7 BUT/t
Seriel grænsefladetype:	RS-232
Lydalarmer:	Ja
Strømbeskyttelsesfunktioner:	Overbelastning
Antal serielle porte:	1
Strømstik:	C14 forbinder
Strømkorrektionsfaktor (PFC):	Aktiv
Kølingstype:	Aktiv
Rack monteringskit:	Ja
Indbygget ventilator:	Ja
AC udgange, antal:	10 AC stikkontakt(er)
AC stikkontakt typer:	C13 forbinder
Overspænding energivurdering:	2430 J
Indgående driftsspænding (maks.):	288 V
Rackkapacitet:	2U
Output strømkapacitet (VA):	1.5 kVA
Indgående driftsspænding (min.):	159 V
Udgangs driftsspænding (min.):	220 V
Udgangs driftsspænding (maks.):	240 V
UPS topologi:	Interaktivt indgangsstik
Strøm (maks.):	10 A
Beskyttelse ved overspænding:	Ja
Bølgeform:	Ren sinus
Hørbare alarmtilstande:	Alarm when on battery, Fault, Low battery alarm, Overload alarm
Typisk backup tid ved halv styrke:	19.3 min.
Typisk backup tid ved fuld styrke:	6.5 min.
Hot-swap batteri:	Ja
Seriegrænseflade:	Ja
Automatisk spændingsregulering (AVR):	Ja
Uddgående frekvens:	50/60 Hz
Nødstrøm Off (EPO):	Ja
EMI/RFI støjfiltrering:	Ja
Antal indgående faser:	1
Udgående strømfaktor:	1
Antal udgående faser:	1
Nødslukning (EPO) stik:	Ja
