DSCON3000-7U

www.dahuasecurity.com

Features：

· 19” standard 7U ATCA industry box

· Easy and exible conguraon with pluggable card module

design

· High speed passive rear panel design, reliable and stable

· FPGA array framework, built in ultrahigh bandwidth switch

matrix, high image processing capacity, exible data exchange

· PCI-E bus, high system bandwidth

· Support analog/digital video signals input and matrix output

· Support non-compressed digital signal encoding output

· Support 4K/30fps video inputs and 4K/30fps outputs

· Maximum 320ch@1080P or 1280ch@D1 signal decoding

(full congured)

· Remote cast analog/digital video onto the video-wall

· Redundant power oponal and smart temperature

controlled fan

· Remote reboot/upgrade/default seng and other

operaons

DSCON3000-7U

Mul-screen Controller

Technical Speciﬁcaon

Model

Model DSCON3000-7U

System Parameter

Main Processor Intel X86 Baytrail microprocessor

Operating System Embedded LINUX

Bus PCI-E

Slot 22(2 Main Control Board Slot, 20 Video Funcon Board)

Mainframe

Power module (redundant power optional), main control

board, control board, PCI-E bus rear panel, smart

temperature controlled fan

Video Input Card Max. 20

Video Output Card Max. 20

Video Input

VI0201UH-DC3000(HDMI)

Interface 2ch HDMI1.4 support HDCP

Access Capability 2ch@4K, downward compability

VI0401HH-DC3000(HDMI)

Interface 4ch HDMI1.3 support HDCP

Access Capability

4ch@1080P, support resoluon:

1080P/720P/UXGA/SXGA+/SXGA/XGA/

SVGA/VGA

VI0801HH-DC3000(HDMI)

Interface 8ch HDMI1.4 support HDCP and

I-SYSTEM

Access Capability

8ch 1080P@60Hz(30fps

eecve), support resoluon:

1080P/720P/UXGA/SXGA+/

SXGA/XGA/SVGA/VGA

VI0401HD-DC3000 (DVI-I)

Interface 4ch DVI-I (support VGA/

HDMI1.3 with convertor)

Access Capability

4ch@1080P, support resoluon:

1080P/720P/UXGA/SXGA+/

SXGA/XGA/SVGA/VGA

VI0401HS-DC3000(3G-SDI)

Interface 4ch BNC

Signal Format 3G-SDI, 2.97Gbps

Access Capability 4ch@1080P, downward

compability

VI3201FB-DC3000 (CVBS)

Interface 2ch DVI-D, 2 BNC interface

braided lines which is 16 in 1

Signal Format PAL

Access Capability 32ch@960H or D1

Network Video

Transfer Protocol TCP/UDP/RTP/RTSP/RTCP

Support Device IPC, NVR, EVS and etc.

Video Resoluon 4K/1080P/UXGA/720P/D1/

HD1/2CIF/CIF/QCIF

Slots

H.265

USB Decording

Multi-segmentationRoaming Collection

DSCON3000-4U

www.dahuasecurity.com

Video Output (Without decoding)

VO0801HH-DC3000 (HDMI)

Interface 8ch HDMI1.3

Split Max 32 layers

Resoluon

1920*1080@60Hz(30fps eecve)

/1600*1200@60fps/1400*1050@

60fps/1366*768@60fps/1280*720

@60fps/1280*1024@60fps/1024*

768@60fps

VO0401HS-DC3000(3G-SDI)

Interface 4ch BNC

Split Max 32 layers

VO0801HS-DC3000(HD-SDI)

Interface 8ch BNC

Split Max 32 layers

Video Decoding Output

VO0405UH-DC3000(HDMI)

Interface 4ch HDMI1.4

Split 1/4/9/16/32, free split

Decoding Capability

2ch@12Mp(15fps)/4ch@4K(25fps)

/16ch@1080P(25fps)/32ch@720P(

25fps)/64ch@D1(25fps), supporng

H.265

Resoluon

3840*2160@30fps(HDMI 2,

3)/1920*1080@60fps/1600*1200

@60fps/1400*1050@60fps/1366*

768@60fps/1280*1024@60fps/12

80*720@60fps/1024*768@60fps

Matrix Switch

Video Input Analog Camera, Digital Camera, IPC, NVR, EVS and etc.

IP HD Matrix Switch 1024 IP input, 160ch@1080p, 320ch@720p, 640ch@D1

Video-Wall

VideoWall Splicing

Splicing Support videowall splicing (max

160 LCD display units)

Video-Wall Support Splicing/Zoom/Merge/

Roam/Overlay

Input Source HD/SD, Digital/Analog (support

hybrid input)

Output Port HDMI

Control Mode PC client/Local GUI/Network

Keyboard/iPad

Network

Interface 2 RJ-45 ports (10/100/1000M)

Serial Port 4 RS232 ports (1 DB9, 3 RJ45), for console and control

1 RS485 port

USB 3 USB2.0, 1 USB3.0

Environmental

Power Supply 100~120V AC, 200~240V AC (Redundant power oponal)

Power Consumpon 90W(Minimum system)/590W(Full conguraon)

Working Environment -10°C ~+55°C (14 °F to 131 °F) / 10~90%RH / 86~106kpa

Dimensions (mm/inch)

Dimension 7U, 482.6 × 434 × 310 mm (19 × 17.1 × 12.2 inch),

(W*D*H)

Weight ≤35Kg (77.16 lb) (full congured)
