Side 1/2

Warranty

DPA Headset Microphones are covered by a two-year limited

warranty.

Service & repair

If you are not satisﬁed with the characteristics exhibited by

this product, please contact your nearest DPA Microphones

representative for support.

CE marking

This product conforms to all relevant directives approved by

the European Commission.

dpam i c r o p h o n e s . c o m

Quickstart guide for Headset Microphones

4466

Omnidirectional Headset

4488

Directional Headset

Adjusting frame size Adjusting boom length

Adjusting boom height Adjusting ear grips

Flipping boom (left to right side)

90º cable management system

We suggest that you

expand the frame and

then place it on your head

before adjusting it to the

correct size.

See full manuals, speciﬁcations and instruction videos:

dpa dpamicrophones.com/4466 microphones.com/4488

345

The microphone capsule is

correctly positioned when it

sits close to (but not touching)

your face, at the corner of

your smile.

Placement of an omni headset Placement of a directional headset

The positioning of this mic, due to its

directional characteristics, is essential as the

low-frequency level will change according to

the distance to the mouth. Mount the mic

2-3 cm (1 in) from the corner of the mouth

to ensure optimal sound quality.

Detach the boom pole from the ear grip by gently pulling the boom down (starting

at the back and tipping forward). (ﬁg. 1) Move the cable to the other side of the cable

guide. (ﬁg. 2) Move the boom pole to the other side and reattach it by gently pushing

up until it clicks onto the ear grip. (ﬁg. 3) Release the sliding lock and turn the boom

pole 180. (fig. ) Move the sliding lock back on the ear grip and it’s ready to use. (ﬁg. 5)4

DPI-Reﬁne-QG

Produkt Specifikationer

Mærke:	DPA
Kategori:	Mikrofon
Model:	4488
Type:	Mikrofon til IP-telefon
Produktfarve:	Beige
Relativ luftfugtighed ved drift (H-H):	0 - 90 %
Driftstemperatur (T-T):	-40 - 45 °C
Forbindelsesteknologi:	Ledningsført
Kabellængde:	1.2 m
Enhedsgrænseflade:	3.5 mm (1/8")
Mikrofon frekvens:	20 - 20000 Hz
Mikrofonretningstype:	Kardioid
Mikrofon sensitivitet:	-44 dB
klirfaktor (THD):	1 %
Følsomhed (1 kHz):	6
Antal produkter inkluderet:	1 stk
Output impedans:	30 - 40 ohm (Ω)
Mikrofon total harmonisk forvrængning (THD):	1 %
Mikrofon dynamikområde:	111 dB
Maksimalt lydtrykniveau (1kHz):	144 dB
