SOLDERING

IRON & GAS

TORCH

GAS

TORCH

78772

78776

2 IN 1 COMPACT

Original Instructions

Version 1 – March 2023

1. Specication

2. HealthandSafetyWarnings

• Observe all standard safety precautions and good

practices when working with naked ames, solder and

ammable fuels.

• Keep the work environment clear and well-lit, with

bystanders at a safe distance.

• Keep this product out of reach of children at all times.

• ALWAYS wear appropriate eye and face protection and

protective gloves when using this product.

− Take additional precautions when using chemicals

like ux or solder paste; refer to the manufacturer

instructions for safe use.

• Check the torch for damaged, clogged or corroded parts

and leaks before every use.

− DO NOT use the product if it is damaged or leaking

in any way; contact Draper Tools for repair and

replacement options.

− If you suspect that the product is leaking gas, move

it to an external environment immediately.

Important: The product can be tested for leaks by

dabbing soapy water solution on joints and

connections while gas is added to or stored in the

product. Leaks will create a steady feed of soapy

bubbles at the breach point.

• Use ONLY in well-ventilated environments.

• DO NOT use this product in environments where paint

fumes, solvents and other ammable materials are

present.

• Use only good quality butane gas.

 WARNING!Butanegasishighlyammable;

handle it carefully and in accordance with the

instructions on the canister.

• During rst use, allow a few minutes for the product to

settle once ignited before directing it towards the

workpiece.

  WARNING!Themetalpartsofthetorchbecome

veryhotduringuse.DONOTtouchthebarrel,

soldering tip or workpiece until they have cooled

thoroughly.

WARNING! NEVER direct the product towards

skin,clothingorotherammablematerials,or

lookdirectlydownthebarrel.

Stock No. 78772 78776

Part No. GT6 GT10

Fuel type Butane Butane

Fuel capacity 15ml 15ml

Approx. temperature 200–400°C 1,300°C

Operating time (one gas lling) 50 mins approx. at low setting 50 mins approx. at low setting

Dimensions W 53 × H 185 × D 150mm W 53 × H 175 × D 100mm

Net Weight 170g 160g

• DO NOT use this product to light cigarettes or pipes.

• To prevent damage caused by reected heat, avoid

directing this product directly downwards when used as

a torch.

• DO NOT leave the product running while unattended.

• DO NOT expose the product to temperatures above 49°C

(120°F) or to prolonged periods of sunlight.

• ALWAYS switch o the product while it is not in use and

move the ame adjustment dial to its lowest position.

• After each use, ensure that the ame is fully

extinguished and the product has completely cooled

before storing.

• Stand the product upright while it is not in use.

− NEVER place the torch onto ammable substances.

• DO NOT attempt to disassemble or modify this tool in

any way.

• ALWAYS refuel outside.

• NEVER smoke while refuelling.

WARNING! This product is not insulated against

electricity. NEVER use this product on

workpieces that are connected to electrical

power.

4. Refuelling

  WARNING!Beforellingtheproduct,ALWAYS

ensurethatboththeon/oleverandtheame

adjustment dial are in their lowest positions.

ONLYusebutanegastofueltheproduct.

Important: This product is not shipped with butane gas

and MUST be fuelled before use.

1. Turn the torch upside-down and push the butane

can nozzle rmly into the lling valve (D).

2. Filling begins automatically and takes only a few

seconds.

3. The fuel level can be viewed through the window (F)

beneath the on/o lever (H).

4. Allow a few minutes after lling for the gas in the

product to stabilise.

WARNING! Allow escaped gas to disperse

beforelightingthetorch.NEVERlightthe

product while a gas canister is inserted

intothellingvalve.

3. Identication

A. Barrel

B. Barrel guard

C. Barrel locking nut

D. Filling valve

E. Flame adjustment dial

F. Fuel level window

G. Ignition button

H. On/o lever

I. Soldering tip

Stock No.78776 Stock No.78772

(I)

(C)

(A)

(B)

(H)

(G)

(E)

(F)

(D) (D)

(H)

(E)

(F)
