BLOW TORCH

78773

MICRO BUTANE

Original Instructions

Version 2 – March 2023

1. Specication

2. HealthandSafetyWarnings

• Observe all standard safety precautions and good

practices when working with naked ames and

ammable fuels.

• Keep the work environment clear and well-lit, with

bystanders at a safe distance.

• Keep this product out of reach of children at all times.

• ALWAYS wear appropriate eye and face protection and

protective gloves when using this product.

• Check the torch for damaged, clogged or corroded parts

and leaks before every use.

− DO NOT use the product if it is damaged or leaking

in any way; contact Draper Tools for repair and

replacement options.

− If you suspect that the product is leaking gas, move

it to an external environment immediately.

Important: The product can be tested for leaks by

dabbing soapy water solution on joints and

connections while gas is added to or stored in the

product. Leaks will create a steady feed of soapy

bubbles at the breach point.

• Use ONLY in well-ventilated environments.

• DO NOT use this product in environments where paint

fumes, solvents and other ammable materials are

present.

• Use only good quality butane gas.

 WARNING!Butanegasishighlyammable;handle

itcarefullyandinaccordancewiththe

instructions on the canister.

• During rst use, allow a few minutes for the product to

settle once ignited before directing it towards the

workpiece.

 WARNING!Themetalpartsofthetorchbecome

veryhotduringuse.DONOTtouchthebarrelor

workpieceuntiltheyhavecooledthoroughly.

 WARNING!Avoidcontactwithskin,clothingor

otherammablematerials.

• DO NOT leave the product running while unattended.

• DO NOT expose the product to temperatures above 49°C

(120°F) or to prolonged periods of sunlight.

• ALWAYS switch o the product while it is not in use and

ensure that the control lever remains in its lowest

position.

• After each use, ensure that the ame is fully

extinguished, the control lever is in its lowest position

and the product has completely cooled before storing.

• DO NOT attempt to disassemble or modify this tool in

any way.

• ALWAYS refuel outside.

• NEVER smoke while refuelling.

 WARNING!Thisproductisnotinsulatedagainst

electricity.NEVERusethisproductonworkpieces

thatareconnectedtoelectricalpower.

3. Refuelling

 WARNING!Beforellingtheproduct,ALWAYS

ensurethatthecontrolleverisinitslowest

position.ONLYusebutanegastofueltheproduct.

Important: This product is not shipped with butane gas

and MUST be fuelled before use.

1 Fig.

(A)

1. Turn the torch upside-down and push the butane

can nozzle rmly into the lling valve (A).

Stock No. 78773

Part No. GT7

Fuel type Butane

Approx. temperature Up to 13,00°C

Operating time (one gas

lling)

20 mins approx. at mid

setting

Dimensions W 90 × H 35 × Ø 20mm

Weight (80% gas ll) 36g

Read this manual in full before using this product and

retain it for future use. Always use the latest version of the

manual. Please visit drapertools.com/manuals for the

latest version of this manual.

2. Filling begins automatically and takes only a few

seconds.

The fuel level can be viewed through the window (B)

beneath the control lever (C).

3. Allow a few minutes after lling for the gas in the

product to stabilise.

 WARNING!Allowescapedgastodispersebefore

lightingthetorch.NEVERlighttheproductwhilea

gascanisterisinsertedintothellingvalve.

4. IgnitionandUse

 WARNING!Keepyourhandsandfaceawayfrom

thebarrelwhenignitingandoperatingthe

product.Gripthetorchbythehandleonly.

1. Fuel the product and allow the gas to settle.

2. Move the control lever (C) to the + position to start

the fuel supply.

2 Fig.

(C)

(B)

3. Depress the ignition button (D) repeatedly until the

ame is lit.

3 Fig.

(D)

4. Adjust the size and temperature of the ame using

the control lever.

5. Allow the ame to settle, then direct it safely towards

the workpiece.

6. To switch o the product, move the control lever

fully to the – position. Allow the torch to cool

thoroughly.

Important: Avoid using the product in sideways or inverted

orientations as this may interrupt the ow of fuel to the

ame.

5. MaintenanceandDisposal

WARNING! ALWAYS ensure that the control lever

isintheOFFpositionandthatthetorchis

completelycoolbeforemaintainingorstoringthe

product.

• Keep the barrel clean and dry.

− Use a dry cloth ONLY to clean the barrel.

− Clean the soldering tip using a wet sponge while the

barrel is hot.

 WARNING!Takecarenottotouchanypart

oftheheadassemblywhilethebarrelis

hot.

− DO NOT use solvents or other aggressive chemicals

to clean the product as they may damage plastic or

insulated parts.

• Keep the air vents of the barrel free from dust and

obstructions.

• Store the product in a clean, cool and dry location, out

of direct sunlight and out of reach of children.

At the end of its working life, dispose of the product

responsibly and in line with local regulations. Recycle

where possible. Exhaust the fuel before disposing of the

product and dispose of butane separately and responsibly.

6. ExplanationofSymbols

Read the instruction leaet

Max. potential operating time per refuel

Operating temperature

Rellable gas

Keep out of the reach of children

min

1300°C

REFILLABLE
