Side 1/10

For more information, please visit

www.earthworksaudio.com or call 1-603-654-2433.

HANDHELD CONDENSER VOCAL MICROPHONE

SR40V

1 SR40V Microphone

1 Microphone Clip

1 Protective Fabric Bag

YOUR PURCHASE INCLUDES

Thank you for purchasing the

Earthworks SR40V Handheld Vocal Microphone!

SPECIFICATIONS

SR40V

Frequency Response 20Hz - 40kHz

Polar Pattern Cardioid

Sensitivity 10mV/Pa (-40dBV/Pa)

Power requirements 24-48V Phantom, 10mA

Peak acoustic input 145dB SPL

Output XLR-3M

Minimum output load 600Ω, balanced between pins 2 & 3

Noise 20dB SPL (A weighted)

Dimensions Length: 7.25 in. (184mm)

Max dia: 1.95 in. (55.3mm)

Min dia: .97 in. (27.5mm)

Weight .80lb (363g)

37 Wilton Rd. Milford, NH 03055

(603) 654-2433

sales@earthworksaudio.com

earthworksaudio.com

Before setting up the microphone, pull back all existing settings and EQ. By doing this, you will have a

baseline understanding of how our microphones sound, and will then be able to adjust accordingly.

Begin by removing all included components from the packaging. Make sure to mute any incoming

signal to speakers or headphones to avoid any loud “pops” when connecting.

Connect the microphone to an audio interface supplying 24-48V phantom power using a standard

XLR cable. Because of the microphone’s larger capsule size, please allow one minute for the

microphone to settle. (Plugging in the microphone while phantom power is turned on will not damage

the microphone, and will actually settle the microphone faster.)

To guarantee your microphone provides years of performance, follow these guidelines:

• Avoid extreme heat and condensing humidity.

• Rough handling may damage the microphone even if no markings are visible.

• When not in use, keep the microphone in its case.

GETTING STARTED

If you encounter issues while using your Earthworks Audio microphone, please make sure that:

• Your microphone is connected to an active power supply.

• Phantom power is being supplied to the microphone.

• Your microphone and XLR cable are well connected.

• The microphone is positioned at an appropriate distance from the sound source.

• External noise in your recording environment is kept to a minimum.

• Your recording space is at room temperature and free of dust.

If your issue persists after checking, please contact us via our website.

TROUBLESHOOTING

PROPER MAINTENANCE

WARRANTY

All Earthworks® products carry a limited warranty (parts and labor). Please register your warranty at:

earthworksaudio.com/register. If you have any problems with your Earthworks products, please contact our

warranty/repair department by email at: returns@earthworksaudio.com.

NOTE: This warranty only applies to Earthworks microphones purchased brand new. For microphones purchased/

received second-hand, please contact us via our website.

Produkt Specifikationer

Mærke:	Earthworks
Kategori:	Mikrofon
Model:	SR40V
Type:	Scene/optræden mikrofon
Højde:	184 mm
Produktfarve:	Sort
Forbindelsesteknologi:	Ledningsført
Diameter:	55.3 mm
Enhedsgrænseflade:	XLR-3
Mikrofonindgangsimpedans:	65 ohm (Ω)
Mikrofon frekvens:	20 - 40000 Hz
Mikrofonretningstype:	Hypercardioid/subcardioid mikrofon
Strømforbrug:	10 mA
Mikrofon sensitivitet:	-40 dB
Mikrofon vægt:	377 g
Følsomhed (1 kHz):	10
Inklusiv klemme:	Ja
Antal produkter inkluderet:	1 stk
XLR udgående:	1
Fantomstrøm:	24 - 48 V
Tilsvarende støjniveau:	20 dB
Maksimalt lydtrykniveau (1kHz):	145 dB
