ECLER TECHNICAL DATA SHEET
96 00 01 EN- 74- 01 -2B9 AURA 00
1
AURA-2B9 00
COMM ERCIAL AMPLIFIERS
Two channels LoZ & HiZ Amplifier
AURA 2B- 900 9is two channels, 2x 00 W RMS @4Ω, high efficiency amplifier (class D). Compatibility with both Low
and Hi impedance configurations and supporting dual or bridge mode (@4/8Ω). AURA Series are built with the highest
robustness for long lasting performances with special power supply circuitry designed for optimized electrical
consumption with fan cooling system. AURA Series also features the possibility of linking channels to the first input by
selecting it on the rear panel, as well as auto stand by, overload and thermal protec- tion, PFC and anti-clipping system.
The front panel volume knobs can be locked using rear panel switches for added security.
KEY FEATURES
• 2 analogue audio inputs and 2 x900 WRMS @4Ω powered
audio outputs.
• Low (2, 4 and 8Ω) and high impedance (70/100V)
compatibility via rear panel switch.
• Supports dual or bridge mode (@4/8Ω).
• Euroblock input and output connectors.
• Euroblock connectors with anti-pulling locking system.
• Link to input 1 available.
• The front panel volume control knobs can be locked using
the rear panel switches for added security.
• High efficiency (Class D).
• Auto Standby function.
• Fan cooling.
• Thermal protection.
• Overload protection.
• Anti- clip system.
APPLICATIONS
• Leisure
• Hospitality
• Education
• Corporate
• Sports & Wellness
• Retail
ECLER TECHNICAL DATA SHEET
2
TECHNICAL SPECIFICATIONS
AURA-2B9 00
CHANNELS
Number of Outputs channels
2
Output connection type
2- pin Euroblock. Pitch: 7,62 mm
Number of Inputs channels
2
Input connection type
3- pin Euroblock, balanced, pitch 3,5 mm
Input configuration
Input link to CH1 selector per input
OUTPUT POWER All channels driven @1kHz @CF9dB @ 1%THD
Max output power @ 8Ω
450W
Max output power @ 4Ω
900W
Max output power @ 2Ω
1000W
Max output power @ 4Ω bridge mode
2000W
Max output power @ 8Ω bridge mode
1600W
Max output power @ 100V
900W
Max output power @ 70V
900W
OUTPUT POWER Single channel driven @1kHz @CF9dB @ 1%THD
Max output power @ 8Ω
450W
Max output power @ 4Ω
900W
Max output power @ 2Ω
1200W
Max output power @ 4Ω bridge mode
2000W
Max output power @ 8Ω bridge mode
1600W
Max output power @ 100V
900W
Max output power @ 70V
900W
SIGNAL
Voltage gain
34 dB
Input sensitivity
0 dBV
2,21 dBu
1 Vrms
Input impedance
20kΩ balanced
Max input level
+18dBV
20,21 dBu
Frequency response
15Hz - 30kHz
THD + Noise
<0,01%
SNR
100dBA
Crosstalk
>70dB
CMRR
> 55 Typ
Damping Factor
>150
ELECTRICAL
Power supply
Universal, regulated SMPS with PFC
AC mains requirement
100 240 V @ 50- -60Hz (±10%)
Power factor correction
> 0,93
AC mains connector
IEC C14 inlet
