Side 1/4

Organ Machine

Congratulations on your purchase of the Electro-Harmonix Organ Machine The C9 C9 .

transforms the tone of a guitar or keyboard into that of a convincing electric organ

yet is easy to use and play. Based on the sound engine found in the EHX B9 Organ

Machine, the C9 delves deeper into the sonic territory of classic organs covering a

vast array of memorable electric organ tones The s controls covering . C9 ha

percussive attack level, modulation speed, and both organ and dry volume.

WARNING: Your comes equipped with an Electro-Harmonix 9.6DC-200BI power supply C9

(same as used by Boss

& Ibanez

: 9.6 Volts DC 200mA). The requires 0mA at 9VDC with C9 10

a center negative plug. Using the wrong adapter or a plug with the wrong polarity may damage

your and void the warranty. C9

GETTING STARTED

Connect the supplied power adapter to the 9V power jack. Plug your instrument into

the INPUT jack; connect your amp to the ORGAN OUTPUT jack Set the DRY knob to .

minimum and all the other top row knobs to about mid position Select the preset .

named TONE WHEEL and step on the footswitch to turn on the LED. Play your

instrument and adjust controls to your liking. MOD controls modulation speed and

CLICK controls percussive click level.

DRY VOLUME KNOB

Controls the volume of the untreated instrument the ORGAN OUTPUT jack. at

ORGAN VOLUME KNOB

Controls the overall volume of the ORGAN preset.

MOD KNOB

MOD controls the . Modulation can be completely turned off speed of modulation

when MOD is set fully counterclockwise The type of modulation is contingent on the .

preset selected. The different types of modulation available are vibrato, tremolo and

chorus. See the preset descriptions for modulation type.

CLICK KNOB

CLICK controls It was design to simulate the harmonic percussive click level. ed

percussion effect on classic B3 and C3 organs. The click added to the very first is

note or chord played. The click will retrigger only when current notes have been

released and the amplitude falls below a threshold. For most presets, CLICK controls ir

parameters unique to the preset. See the preset descriptions for details.

BYPASS FOOTSWITCH

Press the BYPASS Footswitch to toggle the between buffered Bypass and Effect C9

mode. The status LED lights when in Effect mode.

DRY OUTPUT JACK

DRY outputs the signal present at the INPUT Jack through a buffer circuit. The dry

signal is outputted regardless if the is in Effect or Bypass mode. The DRY Volume C9

knob does not change the volume at the DRY Output jack.

ORGAN TPUT JACK OU

ORGAN outputs the mix set by the DRY and ORGAN controls.

PRESET DESCRIPTIONS

1. Tone Wheel - Classic tone wheel-esque organ sound.

MOD type:

Chorus.

CLICK sets level of click sound.

2. Prog – Paying homage to the massive sound of Keith Emerson of Emerson

Lake and Palmer.

MOD type:

Chorus.

adjusts the level of two CLICK

intervals: a fifth above and an octave below.

3. Compact - This preset imitates a sound similar to Ray Manzarek’s tone on

the Door’s “Light My Fire.”

MOD type:

Vibrato.

CLICK adjusts the level of

upper harmonics.

4. Shimmer - is preset is based on effect made popular by Brain Eno Th an

and Daniel Lanois. adjusts the attack time. controls the sustain MOD CLICK

amount.

5. Lord Purple – Our salute to the Jon Lord-ish type organ sound of Deep

Purple. The ORGAN level controls the level of one set of 3 drawbars.

MOD

Type: Chorus.

CLICK adjusts the level of a second set of 3 drawbars.

6. Mello Flutes – A tribute to the classic Mellotron flute tape sound of The

Beatles’ “Strawberry Fields Forever.” song

MOD Type: Vibrato.

CLICK

adjusts the depth of the vibrato.

7. Blimp - Led Zeppelin type sound

. MOD Type: Chorus.

CLICK adjusts the

level of upper harmonics.

8. Press Tone – EHX’s nod to the great organ sound found on ’ The Beatles

song “Let It Be.”

MOD type:

Chorus.

CLICK sets level of click sound.

9. Telstar - Envisions the legendary sound of a Clavioline as used on The

Tornadoes song “Telstar.”

MOD Type: Vibrato.

CLICK adjusts the level of

upper harmonics.

Note: On presets 2, 3, 5 and 7; the CLICK knob is a volume control that works

independent of the main ORGAN volume knob. ly

NOTES AND SPECIFICATIONS

• C9 has buffered bypass.

•  Input impedance is 1M .

•  Output impedance for both output jacks is 500 .

• Current draw of the is mA. C9 100
