FCC COMPLIANCE

Note:

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Modifications not expressly approved by the manufacturer could void the

user's authority to operate the equipment under FCC rules.

DOCTOR Q

Congratulations! You have just purchased the DOCTOR Q, the

classic envelope funk box. Exactly the same as the original

DOCTOR Q, but in a more compact package.

-CONTROLS-

RANGE CONTROL— Controls the frequency range in which the filter

moves. The DOCTOR Q responds to your picking dynamics. Depending on

your guitar volume control, the DOCTOR Q’s RANGE control and how hard

you pick, different wah-like effects will be produced. The range of the filter is

determined by the interaction of instrument volume and the RANGE control.

Both stronger attacks and higher (clockwise) control settings increase the

sweep range. Low volume and low RANGE settings will create little or no

sweep.

BASS SWITCH — When in the up position allows more low frequencies to

pass. Use to boost lower frequencies when the DOCTOR Q is set to create

little or no filter sweep.

FOOTSWITCH – Selects whether the DOCTOR Q is engaged or in True

Bypass. The corresponding LED will be lit when the pedal is engaged, and

dark when True Bypassed.

-OPERATION AND WARNINGS-

Power, from the internal 9-volt battery or external battery eliminator, is

activated by plugging into the input. The input cable should be removed

when the unit is not in use to avoid running down the battery. The input

impedance presented at the Input Jack is 47 kohms. The output impedance

at the Output Jack is 47 ohms.

The barrel connector on the front of the DOCTOR Q is for a 9-volt battery

eliminator capable of delivering 100 mA of current. The inner ring of the 9-

volt battery eliminator must be negative, the outer ring positive. The unit’s

battery may be left in or taken out when the eliminator is in use.

To change the 9-volt battery, you must remove the 4 screws on the bottom

of the DOCTOR Q. Once the screws are removed, you can take off the

bottom plate and change the battery. Please do not touch the circuit board

while the bottom plate is off or you may damage a component.

The optional 9V power supply from Electro-Harmonix is US96DC-200BI

(same as used by Boss ™ & Ibanez™) 9.6 volts/DC 200ma. The barrel

connector on the front of the DOCTOR Q is for the 9-volt battery eliminator

capable of delivering 100 mA of current. The inner ring of the 9-volt battery

eliminator must be negative, the outer ring positive. The unit’s battery may

be left in or taken out when the eliminator is in use.

- WARRANTY INFORMATION -

Please register online at http://www.ehx.com/product-registration or

complete and return the enclosed warranty card within 10 days of purchase.

Electro-Harmonix will repair or replace, at its discretion, a product that fails

to operate due to defects in materials or workmanship for a period of one

year from date of purchase. This applies only to original purchasers who

have bought their product from an authorized Electro-Harmonix retailer.

Repaired or replaced units will then be warranted for the unexpired portion

of the original warranty term.

If you should need to return your unit for service within the warranty period,

please contact the appropriate office listed below. Customers outside the

regions listed below, please contact EHX Customer Service for information on

warranty repairs at info@ehx.com or +1-718-937-8300. USA and Canadian

customers: please obtain a Return Authorization Number (RA#) from

EHX Customer Service before returning your product. Include with your

returned unit: a written description of the problem as well as your name,

address, telephone number, e-mail address, and RA#; and a copy of your

receipt clearly showing the purchase date.

United States & Canada

EHX CUSTOMER SERVICE

ELECTRO-HARMONIX

c/o NEW SENSOR CORP.

47-50 33RD STREET

LONG ISLAND CITY, NY 11101

Tel: 718-937-8300

Email: info@ehx.com

Europe

JOHN WILLIAMS

ELECTRO-HARMONIX UK

13 CWMDONKIN TERRACE

SWANSEA SA2 0RQ

UNITED KINGDOM

Tel: +44 179 247 3258

Email: electroharmonixuk@virginmedia.com

This warranty gives a purchaser specific legal rights. A purchaser may have

even greater rights depending upon the laws of the jurisdiction within which

the product was purchased.

To hear demos on all EHX pedals visit us on the web at www.ehx.com

Email us at info@ehx.com
