Side 1/4
Q-TRON
Envelope Controlled Filter
-OPERATING INSTRUCTIONS-
Congratulations on your purchase of the
envelope controlled lter! You have
purchased a very powerful tool for musical expression.
Please take a few minutes to familiarize yourself with the
Q-Tron’s
controls and how they
work.
Envelope controlled filters are a unique type of sound modier where the intensity of the
eect is controlled by the user’s playing dynamics.
The volume (also know as the envelope) of an incoming audio signal is used to control a
swept lter. As the volume increases or decreases so does the pitch of the lter.
-CONTROLS-
Drive Switch
(Up/Down) – Selects direction of filter sweep
Range Switch
(HI/Lo) – Emphasizes vowel-like sound in low position and overtones in high
position.
Gain Control
(0-11) – Functions as both a volume control and a lter sensitivity control in
boost mode. In Normal mode the Gain control acts as a lter sensitivity control and has no
eect on the unit’s output volume.
Boost Switch
(Normal/Boost) – Normal mode disengages internal pre-amp, Boost mode
activates it. Also determines function of Gain control (see above).
Peak Control
(0-11) – Determines frequency peak of lter. This control will create a more
dramatic eect when turned clockwise.
Mode Switch
(LP, BP, HP, MIX) – Determines what frequency range the filter will sweep in.
Emphasizes lows in Low Pass, midrange in Band Pass, treble in High Pass. Mix mode
combines BP with dry instrument signal.
Bypass Switch
(in/out) – Disengages eect.
Lastly, the
Q-Tron’s
eect can be controlled by the user’s playing dynamics. A strong attack
will yield a more dramatic eect, while softer playing will yield more subtle eects or none at
all.
-OPERATION-
Your unit comes equipped with a 24-volt/100mA tip positive, external power adapter
(European models come equipped with a 24v DC/30mA tip positive adapter). Use only the
power adapter supplied. Using the wrong adapter can cause serious bodily injury. Using the
wrong adapter may also damage your unit and will void the warranty.
Make sure all controls are set at minimum. Connect your instrument to the input jack and your
amplifier to the effect out jack. The unit’s power LED should be lit.
Set the Q-Tron’s controls to the following:
Drive Switch: Up
Range Switch: Low
Mode Switch: BP
Peak Control: Maximum
Boost Switch: Normal
Gain Control: See Below
Vary the Gain control until the Overload Indicator LED lights on most of the notes you play. If
no effect is noticeable, depress the Bypass switch to engage the eect. With this setting the
user should be able to approximate the sound of a conventional wah wah pedal. Experiment
with this setting to see how the
Q-Tron
reacts to playing dynamics.
Adjusting the Gain and Peak controls will vary the amount and intensity of the effect. For
tonal variations adjust the Range, Mode, and Drive controls.
To attain an eect similar to an original Mutron III, set the Q-Tron’s controls to the following:
Drive Switch: Down
Range Switch: Low
Mode Switch: BP
Peak Control: Maximum
Boost Switch: Boost
Gain Control: See Below
Vary the Gain control until the Overload Indicator LED lights on only the loudest notes you
play. Increasing the Gain will saturate the lter, yielding those famous, “chewy” Mutron-like
sounds. Adjusting the Peak control will vary the intensity of the effect. For tonal variations,
adjust the Range, Mode, and Drive controls.
