Congratulations on your purchase of the Nano Deluxe Memory Man.

Since its introduction in 1978, the Deluxe Memory Man has been

used on countless recordings and has become the gold standard

analog delay with its warm, pristine tone and reliable, musical

performance. This nano version of the Deluxe Memory Man is a

reissue of the original Deluxe Memory Man, with a few added features

for modern players.

Features Include:

t Added control over modulation with the addition of a Rate knob

t Internal switch to enable tails or true bypass

t High input impedance to preserve your guitar’s tone

t Powered from standard 9VDC, center-negative power supplies

t More compact, pedal-board friendly footprint

WARNING: This device comes equipped with an Electro-Harmonix 9.6DC-200 power sup-

ply. It requires 150mA at 9VDC with a center negative plug. Use of the wrong adapter or

a plug with the wrong polarity may damage the device and void the warranty. Do not

exceed 12VDC on the power plug. Power supplies rated for less than 150mA will cause

the device to act unreliably.

Nano Analog Delay with Modulation

Controls and Connections

1. DELAY Knob Sets delay time from 30ms to 550ms. As DELAY is turned clockwise, the

delay time increases. Turning the DELAY knob while playing can produce strange, eerie

and unusual pitch-shift effects, especially with FEEDBACK set above noon. Note:

it is normal to hear ring modulation artifacts when DELAY is set above 3 o’clock.

2. FEEDBACK Knob Controls the amount of signal that is circulated from the

output of the delay block back to its input yielding delay repeats, or multiple

echoes. If set very high, runaway oscillation will occur. Fairly high feedback

with short delay settings produces a reverb effect.

3. BLEND Knob Varies the output mix between the dry and delayed signals. The

BLEND knob ranges from 100% dry (CCW position) to 100% wet (CW position).

Set BLEND to the center position for equal levels of both.

- 2 -

Operating Instructions

Connect your guitar to the INPUT jack on the Nano Deluxe Memory Man (Nano DMM)

and the OUTPUT jack to your amp’s input. Plug in the included power supply and

insert its output plug into the power jack. Press the footswitch to ensure the

STATUS LED is lit, now your Nano DMM is ready to go. Have fun experimenting with

the Nano DMM and other effects pedals to develop your own unique sound.
