Side 1/4

Sovtek Deluxe Big Muff Pi

Congratulations! You have just purchased the passionate lovechild of our revered Green Russian

Big Muff Pi reissue and the Big-Muff- -steroids Deluxe Big Muff Pi: the Sovtek Deluxe Big Muff on

Pi! thinking , yes, we did! We know what you’re – “Oh, no they didn’t!” Oh, It’s the beefy, woolly

tone you love from the Green Russian Big Muff with all the bells and whistles from the Deluxe Big

Muff. Check it out.

Features Include:

• Big Muff Knob Layout familiar Sustain, Tone and Volume controls–

• MIDS EQ fully parametric MIDS EQ includes variable frequency sweep, boost or cut –

level control and switchable Q or bandwidth amount

• Footswitch for MIDS EQ –turn on the MIDS EQ circuit with the stomp of your foot

• Gate remove unwanted hiss and –hum

• Blend allows you to mix the dry signal with the distortion –

• Wicker switch – opens up the high end for extra attack

• Expression Pedal Input sweep the frequency of the MIDS EQ with your foot –

• True Bypass

CONTROLS

VOLUME Knob – Works as a master volume control for the entire pedal

BLEND Knob This mixes between the dry and distorted signals. Turn this knob fully –

counterclockwise for 100% dry signal and fully clockwise for 100% wet signal. Setting the BLEND

knob to noon yields a 50/50 mix of dry/distorted signal.

TONE Knob Provides a range of sounds from high treble to deep bass. As you turn the TONE –

knob clockwise, treble increases and bass decreases.

SUSTAIN Knob As in the original Big Muff Pi, adjusts the amount of sustain and distortion –

Wicker Switch This feature is the same as the switch found on the Big Muff Pi with Tone –

Wicker. With the switch up, the wicker is engaged and high frequency bandwidth opened up is

for a bright and clear top end and more pronounced attack. With the switch down, the effect is

disengaged and the Big Muff circuit is back to stock.

GATE Knob – Turning GATE clockwise raises the Gate threshold requiring greater input amplitude

to open the noise gate, allowing your notes to be heard and your instrument to pass through.

Turn the GATE knob down all the way, to fully counter-clockwise, to disable the noise gate.

MIDS LEVEL Knob When MIDS is engaged (LED near MIDS Footswitch is lit) the MIDS LEVEL –

knob either boosts or cuts up to +/- 10dB, at the frequency set by the FREQ knob located below

it. Turn MIDS LEVEL clockwise from its center 12 o’clock position to boost the center frequency.

To cut, turn MIDS LEVEL counter-clockwise from the 12 o’clock position. This knob has a notch

near the 12 o’clock position to help identify the center of the knob’s travel. In the center position,

MIDS EQ is flat; it does not boost or cut. The MIDS LEVEL knob has no function when MIDS is

bypassed (LED near MIDS Footswitch is off).

MIDS FREQ Knob Sets the center frequency of the MIDS EQ circuit ranging from 310Hz to –

5.0kHz. To hear the range of the MIDS FREQ knob, turn the MIDS LEVEL knob up past 3 o’clock,

make sure MIDS is enabled (LED near MIDS Footswitch is lit), then play your instrument while

turning the MIDS FREQ knob. This knob has no function if either the MIDS section is bypassed

(LED near MIDS Footswitch is off) or the MIDS LEVEL knob is set to its center pos ition.

The MIDS FREQ knob can be controlled by an external expression pedal or control voltage (CV).

Connect the external device to the EXP jack on the input side of the Sovtek Deluxe Big Muff. The

position of the MIDS FREQ knob sets the toe position of the expression pedal or maximum

frequency for CV. The heel position of the expression pedal equals the MIDS FREQ knob’s fully

counter-clockwise position. Please see EXP Input below for more on the expression pedal.

MIDS Q Switch (HIGH/LOW) The Q switch sets the resonance or bandwidth of the MIDS –

EQ. What this means is in LOW mode the EQ sounds broader or rounder and affects a larger

range of frequencies; in HIGH mode the EQ sounds sharper or peakier and affects a narrow range

of frequencies.

MIDS FOOTSWITCH / LED – Engages or bypasses the MIDS EQ section. When the white status

LED is lit, the MIDS EQ circuit is active and the MIDS LEVEL and FREQ knobs can be used to

produce a multitude of different tones.

BYPASS FOOTSWITCH / LED Toggles between effect mode and true bypass When the red –.

status LED is lit, the effect is active. When the LED is off, the Sovtek Deluxe Big Muff Pi is in True

Bypass mode.

I/O AND POWER CONNECTIONS

INPUT Plug your instrument into here. The input impedance presented at this jack is –

approximately with the input buffer off. The input impedance is 1M with the input 130k

buffer on.

OUTPUT This is the output of the Sovtek Deluxe Big Muff Pi. Connect it to the input of your –

amp or another effects pedal. The output impedance at the OUTPUT jack is 300 ohms.

EXP Input – Connect an expression pedal with a TRS plug to this jack to sweep the MIDS center

frequency with your foot or other extremi Additionally, the EXP IN jack can be connected to a ty.

Control Voltage (CV) source using a TS plug; the acceptable range for the control voltage is 0V to

5V. Some suggested Expression Pedals: EHX Expression Pedal, M-Audio

EX-P, Moog

-2, EP

Roland

-5 or BossEV

- connect the FV 500L. The polarity of the expression pedal’s plug must

Sleeve to the heel position, Ring connected to the toe position and the Tip connected to the wiper.

The nominal expression pedal impedance is 10k but it can accept impedances ranging from 6k to

100k. Please note: if the MIDS EQ section is bypassed, the expression pedal is disabled.

9V POWER The Sovtek Deluxe Big Muff can run off of a 9V battery or you can use a 9VDC AC –

Adapter capable of delivering at least 50mA. The optional 9V power supply from Electro-Harmonix

is the 9.6DC- and delivers up to 200mA at 9.6 Volts 200BI (same as used by Boss™ & Ibanez™)

DC. The actual current draw of the Sovtek Deluxe Big Muff 22mA at 9VDC. The AC Adapter is

must have a barrel connector with center negative plug. The Sovtek Deluxe Big Muff accepts most

BOSS® style AC Adapters. Please do not exceed 12VDC at the power jack. The battery may be

left in or taken out when using an AC Adapter.
