PID Temperature Controller ESM-XX20

ENGLISH

PID

TEMPERATURE

CONTROL

UNITS

ESM-XX20

Introduction Brochure. ENG ESM-XX20 01 V16 02/23

ESM-9920, ESM-9420, ESM-7720 , ESM-4920, ESM-4420

PID Temperature Control Units

- 4 digit process (PV) and 4 digit set (SV) display

- Process input (TC, RTD)

- Programmable ON/OFF, P, PI, PD and PID control forms

- Adaptation of PID Coefficients to the system with Self-Tune

and AUTO-Tune operations

- Programmable Heating or Cooling Functions for Control

Output

- Selectable Alarm Functions for Alarm Output

ESM series temperature controllers are designed for measuring and

controlling a process value. They can be used in many applications

with their TC and RTD temperature measurement input, multi-

function control outputs, selectable alarm functions.

They are mainly used in glass, plastic, petro-chemistry, textile,

automotive and machine production industries. Accurate and

advanced controlling is performed with selectable ON-OFF, P, PI,

PD, PID and Self Tune and Auto Tune PID functions.

ENGLISH

Supply Voltage

Specifications

Output

Process Output : Relay (5A@250VVat resistive load) or SSR

Driver Output (Maximum 24mA, Max. 12V Z )

Alarm Output : Relay(5A@250VV at resistive load) or SSR Driver

Output(Alarm Output - 2) (Maximum 24mA, Max. 12V Z )

24V V ( ±15% ) 50/60 Hz - 6VA or 24VZ (±%15) -6W

230V V ( ±15% ) 50/60 Hz - 6VA

115V V ( ±15% ) 50/60 Hz - 6VA

24V V ( ±15% ) 50/60 Hz - 6VA

(It must be determined in order)

Display

Process Display :

ESM-4420 : 10.1 mm Red 4 digit LED Display

ESM-4920 : 13.2 mm Red 4 digit LED Display

ESM-7720 : 13.2 mm Red 4 digit LED Display

ESM-9420 : 10.1 mm Red 4 digit LED Display

ESM-9920 : 19 mm Red 4 digit LED Display

Set Value Display :

ESM-4420 : 8 mm Gr een 4 digits LED Display

ESM-4920 : 8 mm Gr een 4 digits LED Display

ESM-7720 : 9.1 mm Green 4 di gits LED Display

ESM-9420 : 8 mm Gr een 4 digits LED Display

ESM 9920 : 10.8 mm G reen 4 digits LED Display

Leds : PS (Process Set Value), PO (Process Output Status Led) ,

AS1, AS2 (Alarm Set Values), AO1, AO2 (Alarm Output Status

Operating Temperature : 0...50°C

Humidity : 0-90%RH (none condensing)

Protection Class : IP65 at front, IP20 at rear

Weight : ESM-4420 : 220 gr. , ESM-4920 : 240 gr.

ESM-7720 : 270 gr. , ESM-9420 : 230 gr.

ESM-9920 : 340 gr.

Environmental Ratings and Physical Specifications

Process Input : TC,RTD

Thermocouple (TC): J, K, R, S and T (IEC584.1)(ITS90)

Thermoresistance (RTD): PT-100 (IEC751)(ITS90)

Measurement Range : Please refer to Table-1 for selection of input

type and scale.

Accuracy : ± 0.25% of scale for thermocouple and thermoresistance

Cold Junction Compensation : Automatically ±0.1°C/1°C

Line Compensation : Maximum 10 Ohm

Sensor Break Protection : Upscale

Sampling Cycle : 3 samples per second

Input Filter : 1.0 second

Control Form : ON/OFF, P, PI, PD or PID (Control form can be programmed by the user)
