THANK YOU FOR PURCHASING THIS
ERICA SYNTHS BLACK SERIES
MODULE! These are high-end modules
with unique functionality. Only the
highest quality components are used
and all inputs and outputs are
protected against undesired
overvoltage. When designing the Black
Series, we did not economise on the
module width, we put design and
usability first. Big knobs are assigned to
functions that make dierence in sound.
The Erica Black series are a range of
modules that together make an entire
synthesizer. Enjoy!
The Erica Black Digital Noise is our
pathological brainchild. A unique noise
module that makes wide range of noise
eects; almost pure white noise, Atari
console-like one bit noise and other
crazy, more-less predictable sounds.
At the heart of the module is a
programmable logic matrix that
includes two linear feedback shift
registers that generate polynomial noise
eects.
SPECS:
Output signal amplitude…..…....-5V - +5V
Noise bitwidth………….......………1bit – 4 bits
CV level…………………......…………-10V - +10V
Power consumption…..... +93mA, -25mA
Module width……..............………………10HP
Module depth…………..........………..25mm
BLACK DIGITAL NOISE
Use the big knob to
set the desired noise
character – from very
grainy noise fully CCW
to white noise fully CW
Select noise bitwidth
from 1bit, Atari
console-like noise fully
CCW to 4bit noise fully
CW
Set desired
polynomial feedback
CV value. This is stereo
knob and it attenuates
both CV1 and CV2
simultaneously
Get your noise here!
Apply two polynomial
feedback CVs (up to
+-10V) here. Try using a
sequencer to sequence
both polynomial feeds
Connect the output from any
VCO (for best results set to
high frequency) here, and
noise character will follow
frequency of the VCO! When
something is patched in this
jack, the internal clock gets
disconnected
Any signal (pulse, random
gate, audio, etc) here resets
polynomials and the eect is
similar to syncing VCO. Try to
patch speech from
microphone preamp here,
mix noise output with dry
signal and get your voice
distorted beyond recognition!
These two knobs select 4
polynomial feedback
segments each giving 16
possible variations of noise
eects. However this doesn’t
mean that you only have 16
possible sounds. The sound
will be dierent each time
you enter the segment, as
polynomials are shifted
inside the segment
Please follow the instructions for use of this Erica
Synths module below, ‘cause only this will guarantee
proper operation of the module and ensure
warranty from Erica Synths.
Water is lethal for most of the electric devices, unless
they are made waterproof. Erica Synths module is
NOT intended for use in a humid or wet
environment. No liquids or other conducting
substances must get into the module. Should this
happen, the module should be disconnected from
mains power immediately, dried, examined and
cleaned by a qualified technician.
Do not expose the module to temperatures above
+50° C or below -20° C.
Transport the instrument with modules installed
carefully, never let it drop or fall over. Warranty does
not apply to modules with visual damages.
The module has to be shipped in the original
packaging only. Any module shipped to us for
return, exchange and/or warranty repair has to be
in its original packaging. All other deliveries will be
rejected and returned to you. Make sure you keep
the original packaging and technical
documentation.
You will find Erica Synths terms of warranty at
www.ericasynths.lv.
Items for return, exchange and/or warranty repair have
to be sent to: Erica Synths Andrejostas Str. 4a, room T8-C,
Riga, Latvia, LV-1045
This device complies to the EU guidelines and is
manufactured RoHS conforming without use of led,
mercury, cadmium and chrome. Nevertheless, this device is
special waste and disposal in household waste is not
recommended.
Designed and made in Latvia.
User manual by Girts Ozolins@Erica Synths.
Design by Ieva Andrupe.
Copying, distribution or any commercial use in any way is
prohibited and needs the written permission by Erica Synths.
Specifications are subject to change without notice.
In case of any questions, feel free to contact us through
www.ericasynths.lv or via e-mail info@ericasynths.lv.
CHECK THE DEMOS OF OTHER ERICA SYNTHS
MODULES ON WWW.ERICASYNTHS.LV
SAFETY INSTRUCTIONS
DISPOSAL
BLACK DIGITAL NOISE
