SAFETY INSTRUCTIONS

Please follow the instructions for use of the Erica Synths

module below, ‘cause only this will guarantee proper operation

of the module and ensure warranty from Erica Synths.

Water is lethal for most of the electric devices, unless they are made waterproof.

This Erica Synths module is NOT intended for use in a humid or wet environment.

No liquids or other conducting substances must get into the module. Should this

happen, the module should be disconnected from mains power immediately, dried,

examined and cleaned by a qualiﬁed technician.

Transport the instrument carefully, never let it drop or fall over.

Warranty does not apply for modules with visual damage.

Do not expose the module to temperatures above +50° C or below -20° C.

If you have transported the module in extreme low temperatures, leave it in

room temperature for an hour before plugging it in.

The module has to be shipped in the original packaging only. Any module

shipped to us for return, exchange and/or warranty repair has to be in its

original packaging. All other deliveries will be rejected and returned to you.

Make sure you keep the original packaging and technical documentation.

This device complies to the EU guidelines and is manufactured RoHS conforming

without use of lead, mercury, cadmium and chrome. Nevertheless, this device is

special waste and disposal in household waste is not recommended.

You will ﬁnd Erica Synths terms of warranty at

www.ericasynths.lv

Inquiries regarding items for return, exchange and/or warranty

repair should be submitted to our support team at

www.ericasynths.lv/support/

User manual by Girts Ozolins@Erica Synths, Leo Novus@Erica Synths.

Design by Ineta Briede@Black8.

Copying, distribution or any commercial use in any way is prohibited and

needs the written permission by Erica Synths. Speciﬁcations are subject to

change without notice.In case of any questions, feel free to contact us

through www.ericasynths.lv.

Manual January 2025

As its name suggests, the Erica Synths Perkons Voice is a eurorack incarnation of the

percussion voices from the PĒRKONS HD-01 Drum machine. Like on the drum machine, the

module has hybrid architecture, featuring a digital sound engine followed by an analogue

multimode ﬁlter and overdrive. Users can select among 13 sound generation algorithms and

save up to 99 presets that can be recalled easily. Tune and Patch CV inputs are conﬁgurable

for various CV settings and are tuned to 1V/oct.

Alternative percussion algorithms can be implemented easily via ﬁrmware updates.

SPECS

Audio output

CV levels

Power consumption

Module width

Module depth

10Vptp

conﬁgurable -5V - +5V

+59mA, -30mA

14HP

35mm

THANK YOU FOR PURCHASING

THE ERICA SYNTHS

PERKONS VOICE MODULE!

The Erica Drum Series includes high-end, unique functionality and superior

quality modules, which allow for creating feature-rich modular systems for sound

design and live performance in various styles of rhythmic electronic music. Enjoy!

FEATURES

Versatile digital sound engine followed by analogue

multimode VCF and overdrive

13 sound design algorithms

Up to 99 user presets

1V/oct tuning on TUNE and PATCH CV inputs

Drone mode

PERKONS VOICE

OUT

C-OFF CV

ACC

CV P

PATC

DRIVE CV

TUNE CV

DECAY CV

TRIG

PARAM 2 CUTOFFPARAM 1

DECAY DRIVETUNE

ALGO

PATCH

VCF

DATA

ALGO

PATCH

LED SCREEN

DATA

TUNE

DECAY

DRIVE

PARAM 1

PARAM 2

VCF

CUTOFF

TRIG

TUNE CV / DECAY CV / DRIVE CV / PATCH CV / P1 CV / P2 CV / C-OFF CV

ACC

OUT

Push this button to activate ALGORITHM selection mode. The letter indicates the algorithm and the digit indicates a

mode within the algorithm. Refer to the table of algorithms below for more information. Rotate the encoder to select

the algorithm and push the encoder to choose between MONO (n o) and POLY (P Y) mode. In MONO mode, each

incoming trigger plays the drum once and the next one overrides it; in the POLY mode, with longer decay times, the

drum keeps playing even when the next trigger is applied.

The module can play up to 4 voices simultaneously

Push this button to activate PATCH selection mode. You can save up to 99 presets (patches). The dot next to the second

digit indicates that the memory slot is occupied and the dot next to the ﬁrst digit indicates that the patch is selected. Rotate

the encoder and push it to conﬁrm selection. In order to SAVE the patch, push and hold the encoder for 2”. The screen will

show «S u» to conﬁrm saving. In order to manually override the saved parameter positions, hold PATCH and short press

the DATA encoder to unload the patch. In order to delete a patch, hold PATCH and long press (2") the DATA encoder

The screen provides a visual reference for selected algorithms, patches, VCF mode and conﬁguration settings.

The encoder allows for navigating through algorithms, presets and conﬁguration settings

Set the initial TUNE of the drum. The incoming CV is added to the tune potentiometer position

Set the initial DECAY of the drum. The incoming CV is added to the decay potentiometer position. With the DECAY

potentiometer turned all way clockwise, the module will go into DRONE mode

Set the initial OVERDRIVE of the drum. The incoming CV is added to the drive potentiometer position

Set the initial PARAMETER 1 of the drum voice. The incoming CV is added to the PARAM 1 potentiometer position

Set the initial PARAMETER 2 of the drum voice. The incoming CV is added to the PARAM 2 potentiometer position

Select between Lowpass, Highpass and Bandpass ﬁlter modes. The screen and intensity of the LED built into the button

will indicate the selected mode. it can also indicate incoming triggers or audio level, depending on the conﬁguration

(see available settings below)

Set the initial CUTOFF of the VCF. The incoming CV is added to the cutoff potentiometer position

This is the MANUAL TRIGGER button

These are CV inputs. The PATCH CV input is conﬁgurable - refer to the table of conﬁguration settings below. Pleasenote

that PATCH CV will navigate through occupied patch slots only. With a CV applied to PATCH CV, the patch is changed

only on an incoming trigger

This is the ACCENT input. Any signal above 1V, applied here, will accent the percussion sound – the volume will

increase by 2 dB

This is the audio output of the module
