FEATURESTECHNICAL SPECS

Thank you for purchasing Erica Synths Pico Series module!

With Pico Series we challenged ourselves – can we make ANY

superior functionality synth module 3HP wide and affordable?

Erica Pico VCO is great, deep sounding VCO with 32 selected

waves – classical, fattened with sub-oscillator, FM synth and

others. Typically you need several rather expensive modules

to generate similar sounds. Extra feature – flip a switch, and

you have a versatile LFO!

2 banks, each contains 16 waves

VCO/LFO mode

Voltage controlled wavesurfing

Wave morphing in LFO setting

VCO frequency range 30Hz – 5kHz

LFO frequency range 0,1Hz – 20Hz

Output amplitude 10Vptp

Power consumption +26mA, -4mA

Module width 3HP

Module depth 35mm

PICO

VCO

1V/OCT

W-CV

OUT

WAVE

TUNE

PICO

BANK2

BANK1

LFO

VCO

Use this knob to select one of

16 waves in each bank

Use this knob to tune the VCO to

desired initial frequency

Switch between banks of waves

Apply wavesurf CV here! You may

want to use Pico Attenuator or

Scaler to adjust wavesurfing span

This is the output, obviously

LED gives visual control of the output

signal in LFO mode

Select VCO or LFO mode. IN LFO MODE

WAVE MORPHING WILL BE AUTOMATICALLY

ACTIVATED. IT PROVIDES MORE

INTERESTING MODULATIONS IN TRANSITION

FROM ONE WAVE TO ANOTHER

Apply tune CV here! The VCO has

perfect 1V/oct tuning

Thank you for purchasing It comes 1V/oct calibrated, but PSUs on modular Erica Synths Pico VCO!

synths are so different, therefore, if needed, you can perform the calibration procedure specifically

for your modular setup. We have introduced two step calibration where you will need precise 5,000V

and 1,000V CV source (you can use midi-cv keyboard with 5 octaves range). To perform a calibration

procedure, follow these steps:

1) Disconnect your Pico VCO from the PSU.

2) Connect a patch cable to the CV source and make sure, you get 1,000V (exactly ONE VOLT) on the

output – you can play C1 on the midi-cv keyboard.

3) Turn both WAVE and TUNE knobs all way clockwise and flip both switches up (BANK1 and VCO

position). Then connect the VCO to the PSU on your modular! Output LED will light on.

4) Connect 1,000V patch cable to 1V/oct input of the Pico VCO!

5) Flip VCO/LFO switch down to LFO position to initiate the calibration step 1!

6) Now set the CV source to 5,000V (exactly volts) – you can play C5 on the midi-cv keyboard.five

7) Flip VCO/LFO switch up to VCO position to initiate the calibration step 2!

8) Output LED will blink once, and this means that you have successfully calibrated the VCO!
