Art.nr. BGM1001

BS-702

USERS MANUAL 2

GEBRAUCHSANWEISUNG 5

GEBRUIKSAANWIJZING 7

MODE D’EMPLOI 10

MODEO DE EMPLEO 12

MANUALE UTILIZZATI 15

BRUKSANVISNING 17

KÄYTTÖOHJE 20

BRUKSANVISNING 22

BRUGERVEJLEDNING 24

HASZNÁLATI UTASÍTÁS 27

êìäéÇéÑëíÇé èé ùäëèãìÄíÄñàà

Ferm 35

AVAILABLE SPARE PARTS FOR BS-702

REF.NR. DESCRIPTION FERM NR.

4 BALL BEARING 6201 ZZ 806201

5 DRIVE ROLLER 402800

12 ADJUSTMENT BOLT 402801

14 IDLER ROLLER 402802

17 PLATE TABLE 402803

21 DRIVE PULLEY 402804

23 MOTOR 402805

27 BASE PLATE 402806

28 SWITCH 402807

30 BAR 402809

31 ADJUSTMENT BLOCK 402810

32 MOTOR PULLEY 402811

33 V-BELT M21 402812

36 ALUMINIUM DISC 402815

39 TABLE BRACKET 402816

40 TABLE TILT TRUNION 402817

41 MITRE BAR 402818

42 KNOB/BOLT FOR MITRE BAR 402819

46 TABLE 402820

47 MITRE GAUGE 402821

49 SHAFT FOR DRIVE ROLLER 402822

51 SHAFT FOR IDLER ROLLER 402823

52 BALL BEARING 6201 ZZ 806201

56 INDICATOR 402824

78 CAPACITOR (6 µF = 450 VAC) 402825

77 RUBBER FOOT 402826

2 Ferm

Product: Ferm Belt sander

Type BS-702, Article number 330702

Ferm, Genemuiden, The Netherlands

Sound pressure level L

71 dB(A)

SERIAL NUMBER

The serial number on the machine consists of the fol-

lowing elements.

Serial nr.

READ THIS MANUAL CAREFULLY BEFORE USING

THE BELT SANDER!

1. SPECIFIC SAFETY RULES

BEFORE USING THE MACHINE:

1. The following points need to be checked:

- Do the connecting voltage of the machine corre-

spond with the mains voltage;

- Are the mains lead and the mains plug in a good

condition; strong, without ravels or damages.

2. For functional reasons the turning parts of this machi-

ne are not covered. Therefore it is of utmost impor-

tance to be careful. Hold the workpiece firmly, to

prevent it from slipping from your hands. Never

touch the sanding surfaces of a working machine with

your hands.

3. Avoid the use of long extension cables.

4. If necessary, secure the sanding machine with screws.

BEFORE YOU OPERATE THE MACHINE:

1. Always keep the mains cable away from moving parts

of the machine;

2. Use safety goggles;

3. Use a dust mask.

IMMEDIATELY SWITCH OF THE MACHINE

IN CASE OF:

1. defective mains plug, mains line or damage to the

mains line;

2. defective switch;

3. smoke or bad smell caused by scorched isulation.

2. INSTALLATION

Avoid the use of long extension cables. If necessary, secu-

re the sanding machine on a working bench with help of

screws through the holes in the feet of the machine fra-

me. Do not forget to leave enough space around the ma-

chine for the workpieces to be sanded.

3. DESCRIPTION

This machine combines all the advantages of a horizontal

and a vertical belt sander with those of a disc sander. Its

sturdy construction in cast iron and steel makes the ma-

chine suitable for every sanding job.

4. BEFORE PUTTING THE MACHINE

INTO OPERATION

OPERATION (SEE FIG. 1)

1. Machine frame;

2. Motor;

3. Roller stop and parallel stop;

4. Clamping handle;

5. Transport roller;

6. Sanding belt;

8. Fence;

9. Drive roller;

10. Aluminium disc;

11. Sanding disc;

12. Work plate;

13. Mitre scale;

14. Supporting arm.

ASSEMBLY

- Put the machine frame on its head and press the four

rubber stops into the foot of the frame.

- Machine frame, aluminium disc (10) and work plate

(12) are supplied in separate packaging.

- Push the aluminium disc on the shaft and fasten the

ORDER NUMBER/YEAR OF CONSTRUCTION

230 V~

50 Hz

375 W

;

= 1450/min (disc)

= 275 m/min (belt)

150 mm

915 x 100 mm
