Side 1/12
FETCO®, and Driven To Innovation™ are trademarks or trade names of Food Equipment Technologies Company.
© 2012 Food Equipment Technologies Company May-2012
NOTICE TO INSTALLER: Please leave this book with the machine.
www.fetco.com
www.fetco.com
www.fetco.com
www.fetco.com www.fetco.com
Model:
Model:
Model:
Model: Model:
f Hot Water Dispenser HWD_2102
Hot Water Dispenser HWD_2102
Hot Water Dispenser HWD_2102
Hot Water Dispenser HWD_2102 Hot Water Dispenser HWD_2102
With
With
With
With With Portion
Portion
Portion
Portion Portion Control
Control
Control
Control Control
USERS GUIDE-Preliminar
y
Edition
®
2
FETCO Hot Water Dispenser HWD_2102
FETCO Hot Water Dispenser HWD_2102
FETCO Hot Water Dispenser HWD_2102
FETCO Hot Water Dispenser HWD_2102 FETCO Hot Water Dispenser HWD_2102
Contact Information
FETCO ®
Food Equipment Technologies Company
600 Rose Road
Lake Zurich • IL USA • • 60047-0429
Internet: www.fetco.com
Phone: (800) 338-2699 (US & Canada)
(847) 719-3000
Fax: (847) 719-3001
Email: sales@fetco.com
techsupport@fetco.com
Description & Features
The following are the factory settings—and range of variables that are adjustable:
Temperature Control: Water temperature is factory set at maximum 97°C/208°F
(Temperature selectable 50-97°C/122°-208°F)
Portion Control: Delivery volume factory set to deliver up to maximum 21fl.oz/630cc.
(Portion control selectable 5-53fl.oz/158-1575cc by timer adjustment)
Operating Instructions
Operating Instructions
Operating Instructions
Operating Instructions Operating Instructions
To Start:
Follow installation and set up procedures. If desired, set custom dispense temperature; dispense time/volume interval.
1) Open water valve
2) Power unit “ON” from rear power switch. Unit will fill and heat (up to 20 minutes for a new unit).
-After unit is filled and heated
3) Ready Lamp will glow green
-Unit may be operated when Ready Lamp is “off” (after initial fill).
4) White colored backlight intensity of control panel slowly pulsates during “READY” condition
Æ the HWD_2102 should be left “ON”. The hot water tank is well insulated to control energy loss.
-The HWD_2102 is ready to dispense-
Refer to control panel layout diagram for HWD_2102 hot water dispenser on Page 3
To dispense
1) Touch UNLOCK/DISPENSE pad for 1-3 seconds to unlock and activate dispensing system
-Border of UNLOCK/DISPENSE pad will change: briefly turn pink and blink signaling activation
2) Remove finger from pad
-Border of UNLOCK/DISPENSE pad will glow steady red: ready to dispense
3) Touch center of UNLOCK/DISPENSE pad to dispense. Keep finger on pad until dispense is complete.
-Dispense automatically stops when time out is complete, or if finger is removed.
Æ Dispense is unlocked and functioning only when Border of UNLOCK/DISPENSE pad is steady red.
Multiple dispenses are possible when the light bordering the UNLOCK/DISPENSE pad is steady and red colored
Lift finger and reactivate after portion by retouching pad for next dispense portion. Finger must be on pad to dispense.
The UNLOCK/DISPENSE pad rapidly flashes red if finger remains on it after dispensing and no water is dispensed.
If finger remains on the UNLOCK/DISPENSE pad more than 10 seconds while rapidly flashing red-the controls “lock out”
and READY LIGHT & HEATING LIGHT will flash rapidly to show a fault state. All controls are disabled during fault state.
To clear Fault State:
Switch machine “OFF” for about ten seconds, and then toggle back “ON” (Control Reset)
After controls initiate, hot water tank level and temperature are checked- then the “READY” light will activate .
Æ This will take approximately 2 minutes for filled and heated unit; up to 20-30 minutes for a new and empty unit.
