Side 1/2

FLIR Ariel

Corner Camera

Superior Low Light Performance in 5MP and in 8MP with Edge AI Video Analytics

www.ir.com/products/ariel-corner-camera

For technical or sales support, please visit: www.ﬂir.com/about/general-inquiries

Key Features

• Provides total room coverage due to unique corner mounting,

ligature-free, housing, and discrete infrared illumination

• Ensures forensic detail in 5 MP or 8 MP video stream—even in

harsh lighting conditions—thanks to superior low-light performance

and wide dynamic range quality

• 8 MP Corner Camera with Edge AI Video analytics for Abandoned

Object, Intrusion Detection, Camera sabotage, Trip wire, Loitering,

Object removal, Object counting, Stopped vehicle, Face detection

• Offers a complete solution with FLIR United VMS as well as open

integration with various of 3rd party VMSs

Main Applications

• Commercial buildings and close area surveillance inside critical

infrastructure sites

• Areas that require complete coverage from a single camera

• 24/7 monitoring at correctional institutions, healthcare facilities,

building lobbies and elevators

SPECIFICATIONS

Specications subject to change. For the most up-to-date specications, please visit .ir.com

CC-3405-01-I CC-3408-01-IA

Image sensor 1/2.7” 1/2.3”

Sensor resolution 5 MP 8 MP

Scanning mode Progressive

Lens type

2.1 mm, F/2.0,

139.1° HFOV × 101.65° VFOV

@ 2592 × 1944

2.8 mm, F2.2,

132.9° HFOV × 98.1° VFOV

@ 4000 × 3000

Digital slow shutter (DSS) 1/4 (1/4) – 1/60 (50) NTSC (PAL)

White balance AUTO

Automatic gain control

(AGC)

Yes

Backlight compensation

(BLC)

Yes, ON/OFF in linear mode

Shutter WDR 130 dB

Noise reduction 3DYes

Tamper detection Yes

Privacy zones Yes

Video motion detection Yes

Day/Night mode Yes

Mechanical IR cut lter Yes

Signal to noise ratio ±45 dB

Camera

Automatic electronic

shutter (AES)

1/1 to 1/32,000

Sensitivity B/W: 0.036; Color: 0.172 B/W: 0.077; Color: 0.37

Video

Compression Enhanced H.265 main prole + Enhanced H.264

main/high/baseline Prole + MJPEG

Max performance HDR:

2592 × 1944 + 800 × 600,

@30 fps

2048 × 1536 + 800 × 600,

@30 fps

HDR:

3328 × 2496 + 720 × 480 +

640 × 480, @27 fps

3328 × 2496 + 720 × 575 +

640 × 480, @25 fps

Linear:

3328 × 2496 + 720 × 480 +

640 × 480, @30 fps

3328 × 2496 + 720 × 576 +

640 × 480, @25 fps

Resolution range Scalable from SVGA to

5 MP

Scalable from SVGA to

8 MP

Bandwidth Congurable between 64 kbps and 20 Mbps

Rate control LBR, CBR, VBR

SD card recording microSD/microSDHC/microSDXC size up to 1 TB

Network

Network protocols IPV4/6, HTTP, HTTPS, UPnP, DNS, NTP, RTSP, RTP, TCP,

UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X, SNMP, QoS,

TLS, SMTP, FTP, DDNS, PPPoE, RTCP

Ethernet 10/100 mbps 10/100/1000 mbps, auto

sensing, half / full duplex

Remote conguration Via web browser or supported VMS

Firmware upgrade Flash memory for upgrade of camera rmware

over the network

Supported web browser Firefox, Chrome, Edge, Safari

Security Password protection

IP address ltering

TLS/HTTPS

IEEE 802.1X network access control

Digest authentication

Password policy

Protect from multiple failure login

ONVIF support Proles S, G, M, and T

This product is subject to United States export regulations and may require US authorization prior to export,

reexport, or transfer to non-US persons or parties. Diversion contrary to US law is prohibited.

For assistance with conrming the Jurisdiction & Classication of Teledyne FLIR, LLC products, please contact

Revised 03/21/25

FLIR_Ariel_5MP-8MP_Corner_Cameras_Datasheet _en-US-LTR 25-0137-INS

For technical or sales support, please visit:

www.ﬂir.com/about/general-inquiries

FLIR Ariel

Corner Camera

Superior Low Light Performance in 5MP and in 8MP with Edge AI Video Analytics

www.ir.com/products/ariel-corner-camera

Specications subject to change. For the most up-to-date specications, please visit .ir.com

For more information

about FLIR Ariel

™

Corner Camera please

scan or visit:

ORDERING INFORMATION

Model Description

CC-3405-01-I FLIR Ariel

™

5 MP Corner Camera

CC-3408-01-IA FLIR Ariel

™

8 MP Corner Camera with Edge AI Video Analytics

CC-3405-01-I CC-3408-01-IA

Audio

Bidirectional audio Line in and Microphone built in, G.711/G.726/AAC/LPCM,

Line out

Alarm

Input 2 dry alarm contacts, 5 V with 10 KΩ pull up, 100

mA @ room temperature

Output 1 relay contact max. 350 V DC/AC, 130 mA

Physical

Enclosure Metal IK10 vandal resistant/IP66

Dimensions 150 × 82 × 52 mm (5.9 × 3.23 × 2.05 in)

Unit weight Net: 1.01 kg (2.22 lb)

Gross: 1.35 kg (2.97 lb)

Net: 1.03 kg (2.27 lb)

Gross: 1.39 kg (3.06 lb)

Electrical

Input voltage PoE IEEE802.3af (class 0), 12 V DC, 24 V AC

Power consumption 12.95 W

Power connection RJ45, DC, AC

IR Illumination

Distance 15 m (49.2 ft) 10 m (32.80 ft)

Angle of illumination Full 90°

LED type High-efciency SMD

Peak emission wavelength 940 nm 850 nm

Environmental

Operating temperature -30°C to 55°C

(-22°F to 131°F)

-10°C to ~55°C

(14°F to ~131°F) – IR off

Heater not required

Storage temperature -20°C to 70°C (-4°F to 158°F)

Humidity 10%–90% (non-condensing)

Warranty and Regulatory

Warranty According to FLIR RMA Policy and Process

Notice document

USA FCC Part 15 (subpart B, class A, ICES-003)

International CE marked, EN 61000-6-3, EN 62368-1, EN 50130-4, CB

62368-1, LVD (CoC), RoHS, RCM, WEEE, ISTA-3A

MTBF (hours) 526,279 (30°C); 149,537 (60°C)

Shock and vibration IEC 60068-2-64: 2008

Bump and vibration IEC 60068-2-27: 2008

SPECIFICATIONS, CONT.
