7160-1882-XX

DELL 7030 TABLET DOCKING STATION

Rev A

INST-1141

Printing Spec:

PS-001

This instruction sheet is for the following products:

Item No. 7160-1882-00

Lite PCB (No HDMI)

Item No. 7160-1882-10

Full PCB (With HDMI)

1 / 6

This instruction sheet is for the Dell 7030 Tablet Docking Station. For instructions on

features, set-up, and operation of the Dell 7030 Tablet, please refer to the manual provided

by Dell with the Tablet.

This Docking Station is designed to be used with a variety of Gamber-Johnson mounting

systems. Installation instructions for other Gamber-Johnson products are provided with

each individual product.

A Dell certified power adapter

must

be used to power the docking station, the below power

adapter are sold separately unless ordered through a KIT.

(See Page 4 For Isolated Power Adapter Options)

7300-0468

- 11-16VDC Input - Available with the Docking Stations as a KIT:

7170-1053-00 (No

HDMI) or 7170-1053-10 (With HDMI)

If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868

Form

Revision

Product

INSTALLATION INSTRUCTIONS

Product Mounting Disclaimer

Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage

of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson

products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brake lines, electrical, drive train or other systems), air-bags and other safety equipment is

required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with original vehicle manufactures specifications

and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program.

During Installation:

DO NOT

connect this docking station to the vehicle battery until:

All other electrical connections are made

Mounting of all components is complete

Verification that no shorts exist in the entire system

DO NOT

install equipment or route wiring or cords in the deployment path of any air bag.

When drilling into the vehicle, DO make sure that both sides of the surface are clear of anything that

could be damaged.

CAUTION:

If wiring is shorted to the frame, high current conductors can cause hazardous sparks

resulting in electrical fires or flying molten metal.

After installation:

Test the docking station to ensure that it is working properly.

File these instructions in a safe place and refer to them when performing maintenance or re-

installing.

WARNING

: Failure to follow all safety precautions and instructions may result in property damage,

serious injury, or death.

IMPORTANT SAFETY INFORMATION FOR INSTALLERS

Safety is dependent on the proper installation and servicing of this docking station. It is important to

read and follow all instructions before installing this product.

To properly install a Gamber-Johnson docking station you must have a good understanding of

automotive electrical procedures and systems, along with proficiency in the installation and service of

aftermarket vehicle equipment.

There are no adjustments required at any time of the electrical components within the docking station.

Opening the docking station will void the product warranty.

Conduct a "Bench Test"

Gamber-Johnson strongly advises a "bench test" be conducted to verify all electronic and

software issues are resolved prior to installation:

Make sure the computer is operational by itself.

Insert computer into the docking station and verify that the computer is

operating in the dock.

Interconnect entire assembly and verify start-up of all components, including

other equipment (printers, modems, scanners, etc.)

Gamber-Johnson recommends positioning of all mounts and equipment in the vehicle

prior to the actual install to verify that mounting locations are safe and practical.

PRE-INSTALLATION RECOMMENDATOINS

2 / 6
