Side 1/2

1. General Safety Warnings

Always ensure the computer case is placed on a stable, flat surface to prevent it from tipping over.

Keep the case away from water, moisture, or high humidity environments to avoid electrical hazards.

Do not block or obstruct the ventilation openings to ensure proper airflow and prevent overheating.

1. Gaming Case : ATHENA M3

1. Front Panel

2. Top Megnetic Dust Filter

3. IO Port Module

4. Top Radiator (Fan) Mounting Holes

5. Right Side Panel

6. Left Side Tempered Glass

7. PCIe Slots

8. Power Supply Unit Mounting Hole

9. Power Shroud

10. Power Shroud Fan Mounting Hole

11. Rear Fan

12. Front Fans

13. Fan Hub

14. Motherboard Placement

15. Motherboard Mounting Holes

16. HDD/ SSD Cage

17. SSD Cage

18. Bottom Megnetic Dust Filter

19. Chassis Pedestals

ARGB Port

ARGB Cable Port

LED Switch Button

Cable Port

SATA Cable Port PWM Cable Port

PWM Port

SATA Cable LED Switch Button Cable ARGB Cable PWM Cable

2. Chassis Protection : EPS Protection Foam

3. Chassis Dust Cover

4. Preinstalled Fans : GAMDIAS NOTUS Fans x 4

5. Accessory Box : Screws and Standoffs

A. Motherboard/ SSD screws --------------------------------------------------------------------

B. Motherboard additional standoffs ----------------------------------------------------------

C. PSU/ GPU PCIe screws ---------------------------------------------------------------------------

D. HDD cage screws ------------------------------------------------------------------------------------

E. Cable ties --------------------------------------------------------------------------------------------------

6. Accessory Box : Cable Ties

1. Case Type: MID Tower

2. Motherboard Support: E-ATX, ATX, Micro-ATX, Mini-ITX

3. Expansion Slots: 7

4. Material: SPCC, ABS, Tempered Glass

5. Product Dimension : 460 x 218 x 450 mm(18.1 x 8.6 x 17.7 inch)

6. Chassis Dimension : 430 x 218 x 430 mm(16.9 x 8.6 x 16.9 inch)

7. Radiator Support : Top: 360 mm Front: 360mm Rear:120 mm、、

8. Fan Support : Top: 3 x 120mm , 2 x 140mm Front : 3 x 120 mm Rear: 1 x 120mm、、

9. Motherboard Sync : 5V 3-Pin Addressable Header

10. Drive Bays : 2 x 3.5" or 1 x 2.5"+1 x 3.5"(HDD Cage) 4 x 2.5"、

11. Clearence : CPU cooler height limitation: 170mm VGA length limitation: 420mm、、

PSU length limitation: 200mm

2. Electrical Safety

Disconnect the power supply before installing or modifying any internal components.

Avoid touching internal components directly; always ground yourself to prevent static discharge, which can

damage sensitive components.

Use only compatible power supplies and cables, ensuring that all connections are secure and free from

fraying or damage.

3. Handling Precautions

Handle the computer case with care during transportation to prevent physical damage.

Use appropriate tools when assembling or disassembling components inside the case to avoid injury.

Do not force components into place; ensure they align properly before securing them.

4. Fire Hazard Warnings

Ensure all components are properly ventilated and not overheating, as this can be a potential fire hazard.

Avoid overloading electrical circuits connected to the computer case to prevent overheating and potential

fire risks.

Keep flammable materials away from the computer case.

5. Child Safety

Keep the computer case and its components out of reach of children.

Do not allow children to play with or operate the computer case, especially when it is powered on.

6. Cleaning and Maintenance

Unplug the computer case from the power source before cleaning.

Use a dry, soft cloth for cleaning the exterior of the case. Do not use liquid cleaners or aerosols.

Periodically check and clean the ventilation openings to ensure proper airflow.

7. Installation Safety

Ensure that all components are installed correctly and securely before powering on the system.

Double-check connections and screws to prevent potential hazards during operation.

Follow the manufacturer's guidelines for component installation and ensure compatibility with the case.

8. Disposal Instructions

Dispose of the computer case and its components according to local electronic waste regulations.

Safety Information

Motherboard Installation

01 02 01 02

Fan Hub

Case Layout and Parts Identification

Specification

Power Supply Unit (PSU) InstallationPackage Contents

ATHENA

MID-Tower PC Case

Place the standoffs in the appropriate

positions for your motherboard size.

Slide the PSU into the bottom compartment. Secure the PSU with screws and connect the

power cables to the motherboard.

Align the motherboard with the standoffs and

secure it with screws.

LED SWITCH

Fan and Cooling System Setup

Front I/O cables

1. Lightly touch the LED button on the case to switch lighting effects.

2. Press and hold the LED button on the case to enter motherboard sync mode.

3. In motherboard sync mode, lightly touch the button to exit motherboard sync mode.

https://www.gamdias.com

GPU Installation

Troubleshooting and Maintenance

•Regularly clean the dust filters and fans to maintain airflow.

•Check all connections if the system is not powering on.

Warranty and Support Information

•Provide details on the warranty period and how to contact support for assistance

Other Supports

01 0302

SSD Installation

HDD Installation

01 A-01

B-01 B-02

A-02

Identify the appropriate drive bay in your case for the hard drive.

Ensure compatibility of all non-power connectors, RGB, USB, and fan controls.

Front I/O cables

Verify compatibility for installing additional fans if needed,

following the airflow direction for optimal cooling.

If using liquid cooling, mount the radiator and connect the

pump.

Identify the PCI-E p2-x16 slot on the motherboard, usually the largest slot, closest to the CPU.

Align the graphics card s connector with the PCI-E slot and gently press down until the card is firmly seated in the slot. ’

Secure the card to the case with screws

Attach the grouped cables to the case s cable management points. Ensure that the cables are not obstructing any ’

airflow or components

Use additional zip ties or Velcro straps to secure any loose or excess cables. You can also use cable management

Motherboard

Control Box

Motherboard

LED Switch

Button Cable

HD Audio

Power Switch

USB 3.1 (Type C)

USB 3.0 ARGB Cable

LED Switch Button
