Side 1/8

Genelec 7360A and 7370A

Smart Active Subwoofers

Operating Manual

7300 Series

750-7360A/7370A

Genelec 7360A and 7370A Smart Active Subwoofers

Introduction

Congratulations and a thank-you for the

purchase of this Genelec 7300 series

subwoofer. This manual addresses setting

up and using the Genelec 7360A and 7370A

subwoofers. These subwoofers are designed

to integrate easily into all environments, both

those using analogue audio as well as those

using digital AES/EBU audio. Genelec 7360A

and 7370A subwoofers are designed for

precise monitoring of multichannel analogue

audio signals and stereo AES/EBU signals.

Multichannel AES/EBU signal can be

monitored by using the 9301A multichannel

digital audio interface device connected to

the subwoofer.

Energy saving Intelligent Signal Sensing

(ISS) can be turned on to put the subwoofer

automatically into a standby state when

audio signal has been absent for a selected

time. In the standby mode the product

consumes less than one Watt of power.

Upon sensing an input signal the subwoofer

automatically wakes up to full operation. The

wait until entering the ISS power save can be

congured using the Genelec Loudspeaker

Manager (GLM) software. When the ISS is

active you can have your monitoring system

ready for action at all times.

Installation

Each subwoofer is supplied with a mains

cable, one 5 m GLM network cable and an

operating manual. Before connecting switch

the subwoofer and monitors o.

Connections

Analogue input 1 thru 7

XLR balanced inputs, typically provided from

console or monitor controller. +24 dBu max.

Multichannel digital signal can be

monitored by using the 9301A AES/EBU

Multichannel Interface device connected to

the subwoofer.

LFE In

This is a dedicated input for LFE use with

analogue signals. Its bandwidth is extended

to 150 Hz. The addition of +10 dB is enabled

by the +10 dB DIP Switch.

Analogue Output 1 thru 7

Balanced XLR connectors for connecting the

main monitors to the subwoofer. Depending

on the chosen mode of bass management,

these outputs may carry either unltered or

high-pass ltered signal to the main monitors.

See chapter "Bass Management" for details.

LFE Out

Straight thru-put of the LFE In. Typically LFE

Out will be connected to LFE In when daisy-

chaining multiple subwoofers.

Link Out

Combined summation of main inputs 1 thru

7 that are passed along to a second or more

daisy-chained subwoofers. See chapter

"Using Multiple Subwoofers."

Link In

Use this input when daisy-chaining

subwoofers. Accepts ONLY the signal from

Link Out. Analogue inputs 1-7 should not be

used when Link In is connected. See chapter

"Using Multiple Subwoofers."

OUT1 / Test 1

Passes the 85 Hz Phase Test Tone when used

in the Stand Alone Manual Mode. Enabled

with the Dip Switch labeled "Test Tone".

OUT2/Test 2

Reserved for future use.

AES/EBU IN

Two channel AES/EBU digital input. This

input can also be congured to receive a

digital LFE channel using the GLM software

or the "Digital LFE" and "LFE Channel A/B"

switches.

AES/EBU OUT

Output is straight thru-put of AES/EBU IN.

BYPASS

Bass manager subwoofer Bypass. For use

with Stand-alone Manual mode. Accepts a

TRS/TS contact open/close device.

GLM NETWORK

Two CAT5 (RJ45) GLM Network connectors

for computer control using the Genelec

Loudspeaker Manager (GLM) software.

MAINS INPUT

Supports a wide mains voltage range

(100-240 VAC, 50-60 Hz) and enables the

subwoofer to be plugged in anywhere

globally. If the mains power is provided with

a generator, inverter or certain lower-quality

UPS devices, we recommend ltering of the

mains power voltage harmonics and taking

care that the voltage supply is stable.

Bass Management

Bass management splits the signal from each

input into low and high frequency components.

Signal content below the crossover frequency

is reproduced by the subwoofer and signal

content above the crossover frequency is

reproduced by the monitors connected to the

outputs of the subwoofer.

The 736

0A and 7370A offer two bass

management methods:

Centralized bass management

This method builds both the highpass and

the lowpass lters in the subwoofer and can

be used in all setups, with or without GLM

control. A xed 85 Hz crossover lter for the

analogue main channels is default for manual

stand-alone use. However, we recommend

the use of the much more exible distributed

bass management method.

In this method all analogue signal cables

are routed through the subwoofer's IN/OUT

connectors to the respective main monitors.

Distributed bass management

In this method the lowpass lter is applied

in the subwoofer and the highpass lter in

the monitor, and these are set in synchrony

using the GLM network. This method is only

available in systems where GLM is used.

The GLM management software enables

adjusting the subwoofer/monitor crossover

from 50 Hz to 100 Hz when distributed bass

management is used.

The distributed bass management

supports three different signal cabling

congurations:

• All channels routed through the

subwoofer's IN/OUT connectors to the

respective monitors.

Produkt Specifikationer

Mærke:	Genelec
Kategori:	Subwoofer
Model:	7360APM
Produktfarve:	Sort
Strømkilde type:	Vekselstrøm
Subwoofer RMS-effekt:	300 W
Subwoofer driver diameter (britisk):	10 "
XLR indgang:	Ja
Subwoofer driver diameter:	254 mm
Subwoofer type:	Aktiv subwoofer
Subwoofer frekvensomrpde:	19 - 100 Hz
Subwoofer, følsomhed:	109 dB
Subwoofer dybde:	365 mm
Subwoofer bredde:	462 mm
Subwoofer vægt:	27000 g
Subwoofer højde:	527 mm
