Assembly Instructions: (Chatham)1048-6 and 1048-9

IMPORTANT:

• ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

• SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

• USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes

above. Shut off the power at the circuit breaker and completely remove

theoldxturefromtheceiling,includingtheoldmountingstrap.

1. From the parts bag remove the mounting strap assembly. One end

ofnipple(F)shouldbeattachedtomountingstrap(A)withwasherand

hexnut(CandD)inplace.Theotherendshouldhavecanopyloop(H)

attached.Attachmountingstrap(A)tothejunctionboxusingmounting

screws(B)andascrewdriver.Tightensecurely.

2. Unscrew canopy loop collar (I) from canopy loop (H). Pass canopy (G)

overthemountedcanopylooptotesttheheight.Approximatelyhalfof

thecanopyloop’sexteriorthreadsshouldbeexposed,andthecanopy

loopcollarshouldtsnuglyontothecanopyloop.Removecanopy(G)

andadjusttheheightofnipple(F)andcanopyloop(H)untilthedesired

heightisreached.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, please

contact the place of purchase.

ASSEMBLING THE FIXTURE

3. Review the diagram. Decide whether you would like the sockets to

faceupordownandpositionthelampbodyaccordingly.Connectropes

(P) to anchors (O).

4. By measuring, determine the correct number of chain links needed

forproperhangingheight.Ifnecessary,useapairofplierstoopenand

removeanyexcess chain. Attachchain connectors (K)to each endof

chain(J)beforeattachingone endofthechainconnector/chaintothe

top of hook (L). Close the chain connector. Connect the other chain

connector (K) to canopy loop (H).

5.Connecthook(L)toloop(M).Feedthexture’swiresupoverhook(L)

andthen throughchain(J) (every threelinksor so).Slide canopy loop

collar(I)andcanopy(G)ontothechain/wire.

CONNECTING THE WIRES

6.Haveanassistantsupporttheweightofthexturewhile completing

the wiring. Cut away excess wire. Thread the xture’s wires through

canopyloop (H)and nipple (F).Attach thexture’swiresto the power

supplywiresfromthejunctionbox.Connectblacktoblack(orsmooth);

whitetowhite(orribbed);groundtoground(greenorcopper).Twistthe

endsofthewirepairstogether,andthentwistonawireconnector.Make

surealltwistsareinthesamedirection.Ifthereisnogroundwire(green

or copper) coming from the junction box, locate ground screw (E) on

mountingstrap(A)andwrapthexture’sgroundwirearoundthegreen

groundscrew(E).Useascrewdrivertosecuregroundscrew(E)ontothe

mountingbracket.Tuckallwiresneatlyintothejunctionbox.

FINISHING THE INSTALLATION

7.Pushcanopy(G)uptotheceilingandslidecanopyloopcollar(I)up

beneath the canopy. Tightly threadcanopy loop collar (I) onto canopy

loop (H) to secure canopy (G) in place.

Install light bulbs (not provided) in accordance with the xture’s

specications.Donotexceedthemaximumrecommendedwattage.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

House Wires

Fixture Wires

Hot

How to Identify the Fixture’s Wires

Hot Neutral Ground

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

PLEASE NOTE:

Thisxturemaybemountedwiththe socketsfacingupor

down.

Please decide whether you would like the sockets to face up or

downandfollowthecorrespondinginstructions.

Lights Down

Lights Up
