IMPORTANT:

• ALLINSTALLATIONWORKSHOULDBEDONEBYACCREDITEDPROFESSIONAL.

• SHUTOFFPOWERSUPPLYATFUSEORCIRCUITBREAKER!

• USEONLYTHESPECIFIEDBULBS.DONOTEXCEEDTHEMAXIMUMWATTAGE!

PREPARING FOR INSTALLATION

Carefullyremoveallofthecontentsfromthecarton.Seetheimportantnotes

above.Shutoffthepoweratthecircuitbreakerandcompletelyremovetheold

xturefromtheceiling,includingtheoldmountingstrap.

Fromthepartsbagremovethemountingstrapassembly.Mountingstrap(B)

containsthreadedholes.Twoofmountingscrews(A)shouldbeattachedto

mountingstrap(B).Youmayneedtotightennuts(C)thatholdthesescrewsin

place.Placemountingstrap(B)overthejunctionboxsothatmountingscrews

(A)arevertical,andinalignmentwiththeholelocationsonthexture’scanopy

(F).Securemountingstrap(B)tothejunctionboxwithmountingscrews(D)anda

screwdriver.Tightenthescrewssecurely.

ASSEMBLING THE FIXTURE

Rods(T,JandK)areonthexture’swires,butnotconnectedtothexture.

Connectrod(T)tothexturebodyatposts(SandQ).Bymeasuring,determine

thecorrectnumberofrodsneededforproperhangingheight.Thereare3optional

12inchrods(K)and1ofa6inchrod(L)included.Tolengthenthexture,add

additionalrods.Ifadditionalrodsareneeded,contacttheplaceofpurchaseto

order.Toshortenthexture,trimthewirestothedesiredlengthaddingatleast8

to10inchesofwiretothedesiredlength.Slideanyexcessrodsoffthexture’s

wirestodiscard.Threadthewiresthroughtherodsandpullthewiresuntiltaut

beforethreadingtherodstogether.Threadbottomrod(JorK)ontopost(L)atthe

topofthexture’sbody.Twistthetoprod(JorK)ontothethreadsofswivelpost

(I)ofcanopy(F).Locktherodinplacebytwistingscrew(G).Pullthexture’swires

throughthetopofcanopy(F).

CONNECTING THE WIRES

Supporttheweightofthexturewhilecompletingthewiring.Attachthexture’s

wirestothepowersupplywiresfromthejunctionbox.Connectblacktoblack

(orsmooth);whitetowhite(orribbed);groundtoground(greenorcopper).Twist

theendsofthewirepairstogether,andthentwistonawireconnector.Makesure

alltwistsareinthesamedirection.Ifthereisnogroundwire(greenorcopper)

fromthejunctionbox,locategroundscrew(E)onmountingstrap(B)andwrap

thexture’sgroundwirearoundthegreengroundscrew(E).Useascrewdriver

tosecuregroundscrew(E)ontomountingstrap(B).Tuckallwiresneatlyintothe

junctionbox.

FINISHING THE INSTALLATION

Pushcanopy(F)uptotheceilingandtightlythreadnuts(H)ontotheexposed

threadsofmountingscrews(A).

Carefullyslidecandlesleeves(P)oversockets(N)beforeslidingglassshades(O)

oversockets(N).

Twistlightbulbs(R-notprovided)intosockets(N)inaccordancewiththexture’s

specications.Donotexceedthemaximumwattage.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

For Customer Service, contact

the place of purchase to arrange

for replacement parts.

BLACK

(Hot)

WHITE

(Neutral)

GREEN

(Ground)

HOUSE WIRES

SMOOTH

(Or Black)

FIXTURE WIRES

RIBBED

(Or White)

BARE COPPER

(Or Green)

A :ssemblyInstructions  (Mercer)4309-3P

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
