Assembly Instructions: (Monroe)7041-6

IMPORTANT:

• ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

• SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

• USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

House Wires

Fixture Wires

Hot

How to Identify the Fixture’s Wires

Hot Neutral Ground

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes

above. Shut off the power at the circuit breaker and completely remove

theoldxturefromtheceiling,includingtheoldmountingstrap.

1. Take the mounting strap assembly from the parts bag. One end of

nipple(F)shouldbeattachedtomountingstrap(A)withwasherandhex

nut (C and D) in place. Canopy loop (H) is attached to the other. Securely

attachmountingstrap(A)tothejunctionboxusingmountingscrews(B)

and a screwdriver.

2. Unscrew canopy loop collar (I) from canopy loop (H). Pass canopy (G)

overthemountedcanopylooptotesttheheight.Approximatelyhalfof

thecanopyloop’sexteriorthreadsshouldbeexposed,andthecanopy

loopcollarshouldtsnuglyontothecanopyloop.Removecanopy(G)

andadjusttheheightofnipple(F)andcanopyloop(H)untilthedesired

heightisreached.

3.Oneofconnectorrods(N)hasthexture’swiresinside.Hook

connectorrods(N)totheframeatloops(Q)andthenpullthexture

wires until taut. Attach the top of connector rods (N) to loops (R). Top

loop(L)isonthexturewires,butnotattachedtothebodyofthexture.

Passthexturewiresthroughtoploop(L).Pullthewiresuntiltautand

threadtoploop(L)ontothexturebody.

4.Bymeasuring,determinethecorrectnumberofchainlinksneeded

forproperhangingheight.Ifnecessary,useapairofplierstoopenand

removeanyexcesschain.Attachonechainconnector(K)toeachendof

chain (J). Use one of chain connectors (K) to attach chain (J) to top loop

(L)andclosethechainconnector.Feedthexturewiresupthroughthe

chain(everythreelinksorso),pullingthewiresuntiltaut.Slidecanopy

loop collar (H) and canopy (G) onto the chain/wire. Use the free chain

connector (K) to attach chain (J) to canopy loop (H).

FINISHING THE INSTALLATION

6.Raisecanopy(G)uptotheceilingandslidecanopyloopcollar(I)upbeneaththecanopy.Tightlythreadcanopyloopcollar(I)onto

canopy loop (H) to secure canopy (G) in place.

7.Slideglassshades(P)oversockets(M)andsecureinplacewithsocketcovers(O).

Installlightbulbs(notprovided)inaccordancewiththexture’sspecications.Donotexceedthemaximumrecommended

wattage.

Yourinstallationiscomplete.Turnonthepowerandtestthexture.

For Customer Service, please

contact the place of purchase.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

CONNECTING THE WIRES

5.Haveanassistantsupportthextureweightwhilecompletingthewiring.Cutawayexcesswire.Attachthexture’swirestothe

powersupplywiresfromthejunctionbox.Connectblacktoblack(orsmooth);whitetowhite(orribbed);groundtoground(green

orcopper).Twisttheendsofthewirepairstogether,thentwistonawireconnector.Makesurealltwistsareinthesamedirection.If

thereisnogroundwire(greenorcopper)fromthejunctionbox,locategroundscrew(E)onmountingstrap(B)andwrapthexture’s

groundwirearoundthegreengroundscrew(E).Useascrewdrivertosecuregroundscrew(E)ontothemountingbracket.Tuckall

wiresneatlyintothejunctionbox.
