Assembly Instructions: (Manhattan)2243-M1L/1SF
IMPORTANT:
• ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
• SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
• USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See the important notes
above. Shut off the power at the circuit breaker and completely
remove the old xture from the ceiling, including the old mounting
1. Take the mounting strap assembly from the parts bag. Mounting strap
(B) should have mounting screws (D) attached. You may need to tighten
hex nuts (C) that hold the screws in place.
2. Use mounting screws (A) and a screw driver to attach mounting strap
(B) to the junction box.
ASSEMBLING THE FIXTURE
3.Rods(KandL)areonthexture’swires.Bymeasuring,determinethe
correct number of rods needed for proper hanging height.
Tolengthenthexture,addadditionalrods.Ifadditionalrodsareneeded,
contact the place of purchase to order.
Toshortenthexture,addatleast8to10inchesofwiretothedesired
length and trim the wires.Slide any excess rods off the xture’s wires
to discard. For the shortest installation, as a 1SF, thread the wires
through swivel (I) and connect the swivel to post (M).
4. Pull the wires taut through the rods before threading the rods together.
Threadbottom rod (K or L) onto post (M) at the center of the xture’s
body.
5. Twist the top rod (K or L) into the threads of swivel post (I) of canopy
(F).Locktherod(s)inplacebytwistingthumbscrew(G).Pullthexture’s
wires through the top of canopy (F).
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
For Customer Service, please
contact the place of purchase.
CONNECTING THE WIRES
6.Haveanassistantsupporttheweightofthexturewhilecompleting
thewiring.Cutawayexcesswire.Attachthexture’swirestothepower
supply wires from the junction box. Connect black to black (or smooth);
white to white (or ribbed); ground to ground (green or copper). Twist the
endsofthewirepairstogether,andthentwistonawireconnector.Make
sure all twists are in the same direction. If there is no ground wire (green
or copper) coming from the junction box, locate ground screw (E) on
themountingstrapandwrapthexture’sgroundwirearoundthegreen
ground screw (E). Use a screwdriver to secure ground screw (E) onto the
mounting bracket. Tuck all wires neatly into the junction box.
FINISHING THE INSTALLATION
7. Raise canopy (F) to the ceiling. Position canopy (F) so that mounting screws (D) protrude through the openings of canopy (F). Secure
canopy (F) to mounting strap (B) with decorative nuts (H).
8.
Installalightbulb(notprovided)inaccordancewiththexture’sspecications.Donotexceedthemaximumrecommended
wattage.
Yourinstallationiscomplete.Turnonthepowerandtestthexture.
House Wires
Fixture Wires
Hot
How to Identify the Fixture’s Wires
Hot Neutral Ground
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
G
ND
A
E
B
C
F
I
M
H
L
L
L
K
D
G
