Side 1/30

OPERATOR MANUAL

IMPORTANT INFORMATION, KEEP FOR OPERATOR

THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,

UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED

IN THIS MANUAL.

FOR YOUR SAFETY Instructions to be followed in the event user smells gas.

This information shall be obtained by consulting your local gas supplier. As

a minimum, turn off the gas and call your gas company and your authorized

service agent. Evacuate all personnel from the area.

WARNING Improper installation, adjustment, alteration, service or

maintenance can cause property damage, injury or death. Read the

installation, operating and maintenance instructions thoroughly before

installing or servicing this equipment.

NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the

consignee to inspect the container upon receipt of same and to determine

the possibility of any damage, including concealed damage. Groen suggests

that if you are suspicious of damage to make a notation on the delivery

receipt. It will be the responsibility of the consignee to le a claim with the

carrier. We recommend that you do so at once.

Manufacture Service/Questions 888-994-7636.

PART NUMBER 177049, REV. G (03/25)

This manual provides information for:

STEAM JACKETED KETTLE WITH STANDARD

ELECTRONIC IGNITION

MODELS DH(T)-20/40/60/80 &

DH(T)-20/40/60/80(C,A) DOMESTIC & CE

EQUIPMENT DESCRIPTION

The Groen DH is a oor-mounted, tilting, steam jacketed kettle with a

thermostatically or electronically controlled, self-contained, gas-heated steam

source and appropriate controls, mounted on a sturdy base. The Model DH is

available in 20, 40, 60 or 80 gallon capacities.

The body of the DH Kettle is constructed of stainless steel, welded into one

solid piece. The kettle is furnished with a reinforced rim and a buttery shaped

pouring lip. It has a steam jacket which is ASME shop inspected and registered

with the national board for working pressures up to 50 PSI, 3.45 bars. Kettle

nish is 180 emery grit on the inside and bright high buff polish on the outside.

The kettle is tilted with a hand crank to pour out its contents. Stainless steel

panels enclose the controls and the base. Four stainless steel tubular legs

support the unit. Bullet or anged feet on each of the legs can be adjusted to

level the kettle. Standard DHT units include a two inch tangent draw-off valve.

The self-contained steam source is heated by propane or natural gas. Ignition

is electronic.

The kettle is charged at the factory with chemically pure water which contains

rust inhibitors. The steam source provides kettle temperatures of 150º to

approximately 295ºF (65 to 150ºC). Unit controls include a thermostat or

controller, pressure gauge, safety valve, pressure limit control, low water cut-

off, power switch and gas regulator valve. The gas supply shuts off automatically

when the kettle is tilted.

The unit must be specied for use with natural or propane gas. Service

connections for gas and electricity are required. Standard power supply is 115

Volt (domestic) or 230V (CE). Alternate single-phase voltages (208-240V) are

available.

KETTLE DIMENSIONS

DH/DHT-20 DH/DHT-40 DH/DHT-60 DH/DHT-80

Kettle

Capacity

20 gal.

(75 ltr)

40 gal.

(150 ltr)

60 gal.

(225 ltr)

80 gal.

(302 ltr)

Kettle Body

Diameter

20 in.

(508 mm)

26 in.

(660 mcm)

30 in.

(762 mm)

34 in.

(863 mm)

Base Width

35 in.

(889 mm)

47 in.

(1194 mm)

47 in.

(1194 mm)

52 in.

(1320 mm)

Base Front to Back

29 in.

(736 mm)

29 in.

(736 mm)

29 in.

(736 mm)

37.5 in.

(952 mm)

REFERENCES

CSA INTERNATIONAL

8501 East Pleasant Valley Road

Cleveland, Ohio 44131

NATIONAL SANITATION FOUNDATION

3475 Plymouth Road

Ann Arbor, Michigan 48106

KLENZADE SALES CENTER ECOLAB, Inc.

370 Wabasha

St. Paul, Minnesota 55102

ZEP MANUFACTURING COMPANY

1310-T Seaboard Industrial Boulevard

Atlanta, Georgia 30318

AMERICAN NATIONAL STANDARDS INST.,

Inc.

1430 Broadway

New York, New York 10018

Z223.1-1984 - National Fuel Gas Code

Z21.30 - Installation Gas Appliances &

Piping

NATIONAL FIRE PROTECTION ASSOCIATION

60 Battery march Park

Quincy, Massachusetts 02269

NFPA/54 -Installation Gas Appliances &

Piping

NFPA/70 - The National Electric Code

888-994-7636, fax 888-864-7636

groen.com

Information contained in this document is known to be current and accurate at the time of printing/creation. Reference our product line

2 OM-DH(T) DOMESTIC & (CE) INTERNATIONAL

Available Options:

1. 2” (50.8 mm) tangent drawoff standard on DHT models

2. Strainers, solid disk, 1/4” (6.35mm) or 1/8” (3.18mm) holes

3. No. 31 lift-off cover

4. No. 51 counterbalanced cover w/actuator*

5. Basket Inserts (Tri-BC)

6. Water ll faucets with swing spout

7. Kettle Brush Kit

IMPORTANT - READ FIRST - IMPORTANT

IMPORTANT:

THESE APPLIANCES MUST BE INSTALLED BY A COMPETENT PERSON IN

CONFORMITY WITH THE INSTALLATION AND SERVICING INSTRUCTIONS

AND NATIONAL REGULATIONS IN FORCE AT THE TIME. PARTICULAR

ATTENTION MUST BE PAID TO THE FOLLOWING (CE):

I. E. E. REGULATIONS FOR ELECTRICAL INSTALLATIONS

ELECTRICITY AT WORK REGULATIONS

GAS SAFETY (INSTALLATION & USE REGULATIONS

HEALTH AND SAFETY AT WORK ACT

FIRE PRECAUTIONS ACT

LOCAL AND NATIONAL BUILDING REGULATIONS

DETAILED RECOMMENDATIONS ARE CONTAINED IN INSTITUTE OF GAS

ENGINEERS PUBLISHED DOCUMENTS: IGE/UP/1, IGE/UP/2, BS6173 AND

BS5440 (CE).

THESE APPLIANCES HAVE BEEN CE-MARKED ON THE BASIS OF

COMPLIANCE WITH THE GAS APPLIANCE DIRECTIVE, EMC AND LOW

VOLTAGE DIRECTIVE FOR THE COUNTRIES, GAS TYPES AND PRESSURES

AS STATED ON THE DATA PLATE.

WARNING: TO PREVENT SHOCKS, ALL APPLIANCES WHETHER GAS OR ELECTRIC,

MUST BE EARTHED.

ON COMPLETION OF THE INSTALLATION, THESE INSTRUCTIONS SHOULD

BE LEFT WITH THE ENGINEER-IN-CHARGE FOR REFERENCE DURING

SERVICING. FURTHER TO THIS, THE USERS INSTRUCTIONS SHOULD

BE HANDED TO THE USERS AND THE INSTALLER SHOULD INSTRUCT

THE RESPONSIBLE PERSON(S) IN THE CORRECT OPERATION AND

MAINTENANCE OF THE APPLIANCE. EMPHASIS SHOULD BE MADE WITH

REGARD TO SAFE OPERATION OF DRAIN VALVE.

IT IS MOST IMPORTANT THAT THESE INSTRUCTIONS BE CONSULTED

BEFORE INSTALLING AND COMMISSIONING THE APPLIANCE. FAILURE TO

COMPLY WITH THE SPECIFIED PROCEDURES MAY RESULT IN DAMAGE OR

THE NEED FOR A SERVICE CALL.

CAUTION: SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN CUT.

WARNING: DISCONNECT POWER BEFORE SERVICING. FAILURE TO DISCONNECT

COULD RESULT IN ELECTROCUTION AND DEATH.

CAUTION: UNIT WEIGHS 535 TO 973 LB. (245 TO 400 KG). FOR SAFE HANDLING,

INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE

MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR

PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE

PLACE OF INSTALLATION.

WARNING: INSTALLATION OF THE KETTLE MUST BE DONE BY PERSONNEL QUALIFIED

TO WORK WITH GAS AND ELECTRICITY. IMPROPER INSTALLATION CAN

RESULT IN INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT.

WARNING: THIS UNIT IS DESIGNED FOR COMMERCIAL USE. NEVER USE HOME

OR RESIDENTIAL GRADE GAS CONNECTIONS. THEY DO NOT MEET

COMMERCIAL GAS CODES AND COULD BE HAZARDOUS.

DANGER: ELECTRICALLY GROUND THE UNIT AT THE TERMINAL PROVIDED. FAILURE

TO GROUND UNIT COULD RESULT IN ELECTROCUTION AND DEATH.

WARNING: DO NOT CONNECT ANY PIPING TO THE POP SAFETY VALVE, THE VALVE

MUST BE FREE TO VENT STEAM AS NEEDED. THE ELBOW ATTACHED TO THE

SAFETY VALVE SHOULD POINT TO THE FLOOR. IMPROPER INSTALLATION

WILL VOID WARRANTY.

WARNING: FAILURE TO CHECK SAFETY VALVE OPERATION PERIODICALLY COULD

RESULT IN PERSONAL INJURY AND/OR DAMAGE TO EQUIPMENT.

WARNING: WHEN TESTING SAFETY VALVE, AVOID ANY EXPOSURE TO THE STEAM

BLOWING OUT OF THE SAFETY VALVE. DIRECT CONTACT WITH STEAM

COULD RESULT IN SEVER BURNS.

WARNING: KEEP THE APPLIANCE AREA FREE AND CLEAR OF COMBUSTIBLE MATERIALS.

FAILURE TO DO SO COULD RESULT IN FIRE OR PROPERTY DAMAGE.

CAUTION: BE SURE ALL OPERATORS READ, UNDERSTAND AND FOLLOW THE OPERATING

INSTRUCTIONS, CAUTIONS AND SAFETY INSTRUCTIONS CONTAINED IN THIS

MANUAL.

CAUTION: KEEP FLOORS IN KETTLE WORK AREA CLEAN AND DRY. IF SPILLS OCCUR,

CLEAN IMMEDIATELY TO AVOID THE DANGER OF SLIPS OR FALLS.

WARNING: WHEN TILTING KETTLE FOR PRODUCT TRANSFER:

1) USE CONTAINER DEEP ENOUGH TO CONTAIN AND MINIMIZE PRODUCT

SPLASHING.

2) PLACE CONTAINER ON STABLE, FLAT SURFACE, AS CLOSE TO KETTLE AS

POSSIBLE.

3) STAND TO SIDE OF KETTLE WHILE POURING — NOT DIRECTLY IN POUR

PATH OF HOT CONTENTS.

4) RETURN KETTLE BODY TO LEVEL POSITION AFTER CONTAINER IS FILLED OR

TRANSFER IS COMPLETE.

5) DO NOT OVERFILL CONTAINER, AVOIDING DIRECT SKIN CONTACT WITH HOT

CONTAINER AND ITS CONTENTS.

WARNING: DO NOT HEAT AN EMPTY KETTLE. EXCESSIVE STEAM PRESSURE COULD

DEVELOP.

WARNING: IF THE KETTLE CONTAINS ITEMS IN HOT LIQUIDS SUCH AS SAUCE OR MELTED

FAT, THEY CAN SLIDE FORWARD SUDDENLY DURING TILTING AND CAUSE THE

HOT LIQUID TO SPLASH OUT.

WARNING: AVOID ALL DIRECT CONTACT WITH HOT FOOD PRODUCT OR WATER IN THE

KETTLE. DIRECT CONTACT COULD RESULT IN SEVERE BURNS.

CAUTION: DO NOT OVER FILL THE KETTLE WHEN COOKING, HOLDING OR CLEANING. KEEP

LIQUIDS A MINIMUM OF 2-3” (5-8 CM) BELOW THE KETTLE BODY RIM TO

ALLOW CLEARANCE FOR STIRRING, BOILING AND SAFE PRODUCT TRANSFER.

WARNING: IT IS RECOMMENDED THAT WATER AND SOLUTIONS BE KEPT OUT OF

CONTROLS AND BURNERS. DO NOT USE HIGH PRESSURE SPRAY DIRECTLY ON

THE CONTROL CONSOLE, ELECTRICAL CONNECTIONS AND BURNERS. USE A

GARDEN HOSE SPRAY CONNECTED TO CITY WATER SUPPLY.

CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS MEMBRANES

AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES,

GOGGLES OR FACE SHIELD AND PROTECTIVE CLOTHING. CAREFULLY READ THE

WARNINGS AND FOLLOW THE DIRECTIONS ON THE LABEL OF THE CLEANER TO BE

USED. FAILURE TO DISCONNECT COULD RESULT IN ELECTROCUTION AND DEATH.

WARNING: BEFORE REPLACING ANY PARTS, DISCONNECT THE UNIT FROM THE ELECTRIC

POWER SUPPLY AND CLOSE THE MAIN GAS COCK. ALLOW FIVE MINUTES FOR

UNBURNED GAS TO VENT.

CAUTION: USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY

AUTHORIZED DISTRIBUTORS CAN CAUSE INJURY TO THE OPERATOR AND

DAMAGE TO THE EQUIPMENT AND WILL VOID ALL WARRANTIES.

IMPORTANT

: SERVICE PERFORMED BY OTHER THAN GROEN AUTHORIZED SERVICE AGENT

WILL VOID ALL WARRANTIES.

CAUTION: THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8 YEARS AND

ABOVE AND PERSONS WITH REDUCED PHYSICAL, SENSORY OR MENTAL

CAPABILITIES OR LACK OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE BEEN

GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE

IN A SAFE WAY AND UNDERSTAND THE HAZARDS INVOLVED.

CAUTION: CHILDREN SUPERVISED ARE NOT TO PLAY WITH THIS APPLIANCE.

CAUTION: CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY CHILDREN

WITHOUT SUPERVISION.

CAUTION: FOR APPLIANCES INTENDED FOR USE AT ALTITUDES EXCEEDING 2,000 M, THE

MAXIMUM ALTITUDE WILL BE STATED OR MARKED ON APPLIANCE.

PERFORMANCE DATA (DOMESTIC)

Model DH/DHT-20 DH/DHT-40 DH/DHT-60 DH/DHT-80

BTU/hr 72,000 100,000 150,000 150,000

kW 21.1 29.3 44.0 44.0

Produkt Specifikationer

Mærke:	Groen
Kategori:	Ikke kategoriseret
Model:	AH/1E

Har du brug for hjælp?

Hvis du har brug for hjælp til Groen AH/1E stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Ikke kategoriseret Groen Manualer

3 September 2025

3 September 2025

2 September 2025

2 September 2025

2 September 2025

2 September 2025

2 September 2025

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

AstralPool Niche Switch Manual

18 Oktober 2025

Sungrow SH8.0RT-V113 Manual

18 Oktober 2025

AstralPool Roma Manual

18 Oktober 2025

Evenflo SafeMax Manual

18 Oktober 2025

NEO Tools 94-002 Manual

18 Oktober 2025

LC-Power Platinum Pro LC1000P V3.1 Manual

17 Oktober 2025

Metz 130B21-E Manual

17 Oktober 2025

NEO Tools 99-038 Manual

17 Oktober 2025

FBT MPU 2120 Manual

17 Oktober 2025

Icy Box IB-MS404-T Manual

17 Oktober 2025
