Side 1/8

Rayden

Quick Start Guide

Rayden LED Lights

What’s Included

RB5

RW5

RB10

RW10

1 x Light Fixture

1 x Yoke Mount

1 x Neutral Density Filter

1 x Power Supply with Cable

www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re tooﬁlmmakers

Getting to know your Rayden Lights

PRECAUTIONS

• Keep the ﬁxture away from water and all ﬂammable gases or liquids.

• Use ONLY the recommended batteries.

• Handle the unit with care.

• DO NOT attempt to disassemble or repair the unit without ﬁrst contacting the service department at www.ikancorp.com

• Keep the unit clean and free of dust. The unit can be cleaned with a soft, dry cloth.

• Use ONLY parts provided by the manufacturer.

• Always use caution when plugging in the ﬁxture.

Mounting the Rayden to a stand

The Rayden LED Light comes with a pre-installed yoke and combo mount. This allows the ﬁxture to easily sit and adjust on any

stand. The 30° yoke gives the light free-range motion without obstructions. The Baby 5/8“ and Junior 1-1/8” Combo Pin allows

the user a wide range of stands. The light can be mounted either horizontally or vertically on a 5/8” baby pin.

Power the LEDs

The Rayden light comes with an included AC power supply and 6 foot cable. This allows the user to plug into any standard 120-

240v electrical outlet. The Rayden LED light can be powered from either an AB Mount pro battery, or a V-Mount battery. The

ﬁxture comes standard with either AB-Mount or V-Mount plates. The plates can be easily removed and replaced for the type of

batteries that are available.

Adjusting the Color & Brightness of the Light

The Rayden LED light is controlled by the large yellow knob on the rear of the ﬁxture. The knob was designed with the idea that

it could be reached and adjusted when the light is up on a stand. The knob has two push settings.

The default setting is the brightness from 10%-100% brightness.

By pressing in on the knob, the color temperature can be adjusted. (Bi-Color lights)

www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re tooﬁlmmakers

Produkt Specifikationer

Mærke:	Ikan
Kategori:	Lettelse
Model:	RB5
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Pakkevægt:	4000 g
Pakkedybde:	406.4 mm
Pakkebredde:	457.2 mm
Pakkehøjde:	152.4 mm
Husmateriale:	Plast
Strømforbrug (maks.):	150 W
Strømkilde type:	Vekselstrøm
Strålevinkel:	50 °
Lys farvetype:	Hvid
Farvetemperatur (maks.):	5600 K
Lys output (maks.):	1218 lm
Form:	Rektangulær
Antal lysdioder:	608
Farvetemperatur (min.):	3200 K
Farve-gengivelse (CRI):	95
