Side 1/6

www.ikancorp.com

713.272.8822

CHECKED BY

What’s Included

1 x 15V Power supply

1 x Yoke Mount

RWX5

Rayden Daylight LED Half x 1 Soft Light with DMX

RWX10

Rayden Daylight LED 1 x 1 Soft Light with DMX

QUICKSTART GUIDE

RAYDEN DMX

Rayden Daylight DMX Flat Panel Light

General Information

Thank you for buying the ikan Rayden DMX512 Daylight LED Lights. This ﬁxture has been designed to perform reliably for

years when the guidelines in this booklet are followed. Please read and understand the instructions in this manual carefully and

thoroughly before attempting to operate this unit. These instructions contain important information regarding safety during use

and maintenance.

Every ﬁxture has been thoroughly tested. Carefully check the shipping carton for damage that may have occurred during

shipping. If the carton appears to be damaged, carefully inspect your unit for damage and be sure all accessories necessary

to operate the unit have arrived intact. In the event damage has been found or parts are missing, please contact our customer

support team for further instructions. Please do not return this unit to your dealer without ﬁrst contacting customer support at

the number listed below. Please do not discard the shipping carton in the trash. Please recycle whenever possible.

Safety Instructions:

This ﬁxture is an extremely sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to

follow the guidelines in this manual. The manufacturer of this device will not accept responsibility for damages resulting from the

misuse of this ﬁxture due to the disregard of the information printed in this manual.

This device falls under PROTECTION CLASS 1. It’s essential this device be grounded properly. Only qualiﬁed personnel should

perform all electrical connections.

INDOOR USE ONLY!

DO NOT EXPOSE FIXTURE TO RAIN AND/OR MOISTURE!!

DO NOT PLUG FIXTURE INTO A DIMMER PACK!

For proper operation, follow the Installation guidelines described in this manual. Only qualiﬁed and certiﬁed personnel should

perform installation of this ﬁxture and only the original rigging parts (yoke) included with this ﬁxture should be used for installation.

Any modiﬁcations will void the original manufacturer’s warranty and increase the risk of damage and/or personal injury.

Never look directly into the light source of this ﬁxture to prevent risk of injury to your retina, which may induce blindness.

Always disconnect from main power source before performing any type of service and/or cleaning procedure. Only handle the

power supply by the plug end, never pull out the plug by tugging the wire portion of the cord.

Do not operate this ﬁxture if the power cord had become frayed, crimped, and/or damaged. If the power

cord is damaged, replace it immediately with a new one of similar power rating.

General Guidelines:

NEVER OPEN THIS FIXTURE WHILE IN USE!!

Please make sure there are NO FLAMMABLE MATERIALS close to the ﬁxture while operating, to prevent any ﬁre hazard.

The ﬁxture must be installed in a location with adequate ventilation, at least 1.5 feet (.5m) from adjacent surfaces. Be sure no

air ventilation slots are blocked.

DO NOT attempt installation and/or operation without knowledge of how to do so.

DO NOT permit operation by persons who are not qualiﬁed to operate this type of ﬁxture. Most damages are the result of

operations by nonprofessionals.

Consistent operational breaks may ensure the ﬁxture will function properly for many years to come.

DO NOT shake ﬁxture and avoid brute force when installing and/or operating the ﬁxture.

Always install the ﬁxture with an appropriate safety cable. When installing the ﬁxture in a suspended environment, always use

correct mounting hardware that can be inserted into the Baby 1/8 or Junior 1-1/8 combo pin adapter." "

Use the original packaging and materials to transport the ﬁxture in for service.

Produkt Specifikationer

Mærke:	Ikan
Kategori:	Lys
Model:	RWX5
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Pakkevægt:	4000 g
Pakkedybde:	406.4 mm
Pakkebredde:	457.2 mm
Pakkehøjde:	152.4 mm
Husmateriale:	Plast
Strømforbrug (maks.):	150 W
Strømkilde type:	Vekselstrøm
Strålevinkel:	50 °
Lys farvetype:	Hvid
Farvetemperatur (maks.):	5600 K
Lys output (maks.):	2506 lm
Form:	Rektangulær
Antal lysdioder:	608
Farve-gengivelse (CRI):	95
