ADA-WS-SEC

SECURITY HANDICAP

HAND SINK

INSTALLATION

GUIDE

For Design and Installation Assistance

Call: 800-221-5644

info@imcteddy.com

50 Ranick Drive East Amityville, NY 11701

(P) 800-221-5644 (F) 631-789-8881

www.imcteddy.com

Project Name:

Item #:

Model #:

INTRODUCTION

Installing the IMC Teddy Security Handicap Hand Sink is a straightforward procedure that can be accomplished

with normal construction materials and techniques. Installation procedures may vary due to eld conditions and

state regulations. Please note that the following instructions are recommendations only. These instructions

apply to all Wall Mounted Hand Sink Models. The installer is responsible for proper setting and making sure the

appropriate codes are followed. Please contact the IMC Teddy Engineering Department (800-221-5644) prior

to considering retrot installations. Click here for a video on mounting your equipment on a Z-Clip: https://bit.

ly/3lmZBr2

Please read the attached information carefully, as much of the information provided is reecting proven installa-

tion techniques used in previous installations.

Parts Included

Position z-bracket onto wall at the

appropriate height above the oor

and mark holes for drilling. (Make

sure bracket is level.) Once holes are

drilled screw bracket to wall.

(Hardware not included.)

In preparation for mounting, remove

the bottom apron cover of the sink.

Use the tamper proof screwdriver to

safely remove the screws.

• WS-SEC Hand Sink

• “Z clip” Mounting Bracket

• Tamper Proof Screws (part of apron

cover)

• Tamper Proof Screwdriver

Step 1:

Step 2:

WS-SEC Hand Sink

Z-Clip

Wall

Drill

Tamper Proof Screwdriver

Tamper

Proof

Screws

Tamper Proof

Screwdriver

Tamper Proof

Screws
