12.9.21 357-00056-01 Rev A © Inovonics, 2021 - www.inovonics.com

EN1262HT High Traffic Motion Detector

Installation and Operation Manual

1 Overview

The EN1262HT high traffic motion detector solves the battery limitation

problems of motion sensors in commercial applications through an

intelligent sleep timer and low current technology. It features a pet immune

PIR detection element, and wall and housing tamper switches.

1.1 Inovonics Contact Information

If you have any problems with this procedure, contact Inovonics technical

support:

• E-mail: support@inovonics.com.

• Phone: (800) 782-2709; (303) 939-9336.

2 Installation and Startup

2.1 Installation Notes

• These products are designed to be maintained by professional

security technicians.

• Products are tested for indoor use.

• All products should be manually tested weekly.

2.2 Mount the Housing and Install the Battery

1. Loosen the captive housing screw.

2. Open the housing

Figure 1 Open the housing

3. Remove the EN1262HT from the mounting bracket per Figure 2.

Figure 2 Remove the EN1262HT from the mounting bracket

4. Noting the detection coverage in Figure 3, determine mounting location.

• Avoid areas facing direct sunlight, areas that may change temperature

rapidly, and areas where there are air ducts or substantial airflows.

• The recommended mounting height is 6.5 feet to 7.5 feet

(2.1 to 2.3 m).

Figure 3 EN1262HT detection coverage area

For product and installation videos visit us at

www.inovonics.com/videos or use the QR

code below.

TOP VIEW

along side wall

7.2 ft

26.2 ft

6.6 ft

13.1 ft

89°

37 ft

26.2 ft

37 ft 26.2 ft

Side VIEW

6.6 ft

13.1 ft

26.2 ft

Produkt Specifikationer

Mærke:	Inovonics
Kategori:	Bevægelsesdetektor
Model:	EN1262HT
Bredde:	60 mm
Dybde:	50 mm
Højde:	132 mm
Vægt:	120 g
Produktfarve:	Hvid
Batterispænding:	1.5 V
Relativ luftfugtighed ved drift (H-H):	0 - 93 %
Driftstemperatur (T-T):	0 - 49 °C
Forbindelsesteknologi:	Trådløs
Strømkilde type:	Batteri
Monteringstype:	Loft/væg
Batterilevetid:	3 År
Batteritype:	AA
Antal understøttede batterier:	2
Bæredygtighedscertifikater:	Federal Communications Commission (FCC), RoHS
Sensortype:	Passiv infrarød (PIR) sensor
Driftsfrekvens:	902 - 928 MHz
Opdagelsesafstand:	8 m
