3.28.22 357-00045-03 Rev A © Inovonics, 2022 - www.inovonics.com
EN1263 Motion Detector with Pet Immunity
Installation and Operation Manual
1 Overview
The EN1263 motion detector with pet immunity is an advanced, fully
supervised low-current wireless motion detector with the most advanced
mirror optics detection method for reliable system operation. It features pet
immunity up to 55 pounds (25 kg).
1.1 Inovonics Contact Information
If you have any problems with this procedure, contact Inovonics technical
support:
• E-mail: support@inovonics.com.
• Phone: (800) 782-2709; (303) 939-9336.
2 Installation and Startup
2.1 Installation Notes
• These products are designed to be maintained by professional
security technicians
• Products are tested for indoor use
• All products should be manually tested weekly
2.2 Mount the Housing and Install the Battery
1. Loosen the captive housing screw.
2. Open the housing.
Figure 1 Open the housing
3. Remove the EN1263 from the mounting bracket per Figure 2.
Figure 2 Remove the EN1263 from the mounting bracket
4. Noting the detection coverage in Figure 3, determine mounting location.
• Avoid areas facing direct sunlight, areas where areas that may
change temperature rapidly, and areas where there are air ducts or
substantial airflows.
• The recommended mounting height is 6.5 feet to 7.5 feet (2.1 to 2.3
m).
Figure 3 EN1263 detection coverage area
For product and installation videos visit us at
www.inovonics.com/videos or use the QR
code below.
TOP VIEW
along side wall
7.2 ft
26.2 ft
6.6 ft
13.1 ft
0
89°
37 ft
26.2 ft
37 ft 26.2 ft
Side VIEW
6.6 ft
13.1 ft
26.2 ft
3.28.22 357-00045-03 Rev A © Inovonics, 2022 - www.inovonics.com 2
5. Use the included three mounting screws to mount the EN1263.
• To mount on the wall, see Figure 4.
• To mount in a corner, see Figure 5.
Note: The black arrows represent recommended mounting screw
locations; the gray arrows represent optional mounting screw locations
should the recommended locations be unavailable.
Figure 4 Wallmount configuration
Figure 5 Cornermount configuration
6. Install the battery per Figure 6.
Figure 6 Install the battery
2.3 Select Pulse Count
The pulse count options provides control for difficult operating
environments. Automatic pulse count is recommended for reliable
operation in environments subject to temperature fluctuation that can
cause false alarms. The single pulse count mode is more sensitive to minor
temperature variations, and should be used in sites where variant heat
sources will not cause alarms. Automatic pulse count is the factory default
because it allows more reliable operation in environments subject to
temperature fluctuation. To select pulse count:
1. Press the tamper button five times within three seconds.
Figure 7 Press the tamper button
2. Wait for the green LED to blink five times, then:
• Press the tamper button one time within three seconds to select single
pulse count.
• Press the tamper button two times within three seconds to select
automatic pulse count.
3. Confirm your selection.
• The green LED will blink once to indicate single pulse count has been
selected; twice to confirm automatic pulse count has been selected.
