car audio

power amplifier

owner’s manual

THANK

for purchasing a JBL Power Series

amplifier.

In order that we may better serve you should you

require warranty service for your new amplifier

, please

retain your original purchase receipt and return the

enclosed warranty registration card.

INSTALLATION

WARNING: Playing loud music

in an automobile can hinder your

ability to hear traffic and permanently

damage your hearing. We recommend

listening at low or moderate levels

while driving your car. JBL accepts

no liability for hearing loss, bodily

injury or property damage resulting

from the use or misuse of this product.

IMPORTANT: To get the best

performance from your JBL Power

Series

amplifiers, we strongly recom-

mend that installation be entrusted to

a qualified professional. Although

these instructions explain how to

install JBL Power Series amplifiers in

a general sense, they do not show

specific installation methods that may

be required for your particular vehicle.

If you do not have the necessary tools

or experience, do not attempt the

installation yourself. Instead, please

ask your authorized JBL car audio

dealer about professional installation.

INSTALLATION

WARNINGS AND TIPS

• Always wear protective eyewear

when using tools.

• Turn off all audio systems and other

electrical devices before you start.

Disconnect the (–) negative lead from

your vehicle’s battery.

• Check clearances on both sides of a

planned mounting surface before

drilling any holes or installing any

screws. Remember that the screws

can extend behind the surface.

• At the installation sites, locate and

make a note of all fuel lines,

hydraulic brake lines, vacuum lines,

and electrical wiring. Use extreme

caution when cutting or drilling in

and around these areas.

• Before drilling or cutting holes, use

a utility knife to remove unwanted

fabric or vinyl to keep material from

snagging in a drill bit.

• When routing cables, keep input-

signal cables away from power

cables and speaker wires.

• When making connections, make

certain they are secure and properly

insulated.

• If the amplifier’s fuse must be

replaced, use only the same type and

rating as that of the original. Do not

substitute another kind.

CHOOSING A LOCATION

AND MOUNTING THE

AMPLIFIER

Amplifiers need air to stay cool.

Suitable locations are under a seat

(provided the amplifier doesn’t

interfere with the seat adjustment

mechanism), in the trunk, or in any

other location which provides enough

air for the amp to cool itself. Do not

mount the amplifier with the heat sink

facing downward, as this makes

convection cooling of the amplifier

impossible.

Mount the amplifier so that it is not

damaged by the feet of backseat

passengers or shifting cargo in the

trunk. Mount the amplifier so that it

remains dry – never mount an amplifier

outside the car or in the engine

compartment. Using the amplifier as

a template, mark the location of the

mounting holes on the mounting

surface, drill pilot holes, and attach

the amplifier to the mounting surface

with screws. Make sure the amplifier

is mounted securely.

POWER CONNECTIONS

The Power Series amplifiers are

capable of delivering extremely high

power levels, and require a heavy-duty

and reliable connection to the vehicle’s

electrical system in order to perform

optimally. Please adhere to the

following instructions carefully:

Ground Connection

Connect the amplifier’s Ground (GND)

terminal to a solid point on the

vehicle’s metal chassis, as close to

the amplifier as possible. Refer to the

chart below to determine minimum

wire-gauge size. Scrape away any

paint from this location; use a star-type

lock washer to secure the connection.

Power Connection

Connect a wire (see chart at right for

appropriate gauge) directly to the

vehicle’s positive battery terminal,

and install an appropriate fuse holder

within 18" of the battery terminal.

not install the fuse at this time.

Route

the wire to the amplifier’s location, and

connect it to the amplifier’s Positive

(BATT +) terminal. Be sure to use

appropriate grommets whenever

routing wires through the firewall

or other sheet metal.

Failure to

adequately protect the positive wire

from potential damage may result in

a vehicle fire.

When you are done

routing and connecting this wire, you

may install the fuse at the battery.

NOTE: The BPx2200.1 is supplied

with an external 150A fuse. If you

are running a dedicated wire to this

amplifier, this fuse should be installed

near the battery, as specified above. If

you are running multiple amplifiers off

a power distribution block, this fuse

should be installed between the

distribution block and the BPx2200.1.

In any case, a fuse must be installed

within 18" of the battery terminal.

Remote Connection

Connect the amplifier’s Remote (REM)

terminal to the source unit’s Remote

Turn-On lead using a minimum of

18-gauge wire.

Speaker Connections

Refer to the application guides on

the pages that follow. Speaker

connections should be made using

a minimum of 16-gauge wire.

Wire Gauge Chart

Amplifier Maximum Minimum

Model Current Draw Wire Gauge

Px300.4 78A #6 AWG

Px600.2 78A #6 AWG

BPx500.1 50A #8 AWG

BPx1100.1 110A #4 AWG

BPx2200.1 190A 2x #4 AWG

These recommendations assume

7' – 10' wire runs. If your installation

differs markedly, you will need to

adjust the wire gauge accordingly.

IMPORTANT NOTE: If you are planning

to use optional neon tubes, you

must install them before making any

electrical connections to the amplifier

(refer to “Installing Neon Tubes” on

page 7).
