EXPLEXPLORER 700
ORER 700
ORER 700
ORER 700ORER 700
Expansion board
1. GENERAL INFORMATION
1. GENERAL INFORMATION
1. GENERAL INFORMATION
1. GENERAL INFORMATION1. GENERAL INFORMATION
Dear customer,
Thank you for purchasing our product. In the following, we will show you
which things should be noted during the use.
Should you encounter any unexpected problems, do not hesitate to
contact us.
www.joy it.net-
Pascalstr. 8 47506 Neukirchen Vluyn-
2. CONNECTIONS
2. CONNECTIONS
2. CONNECTIONS
2. CONNECTIONS2. CONNECTIONS
0,9" OLED:
SSD1306 driver,
resolution 128 x 64 Buzzer
CP2102 :
USB to UART converter
USB to UART: controlling the Pi
via serial interface
AD / DA IO interface: -
screw terminal
sensor interface:
connecting various sensors
Raspberry Pi GPIO interface:
to connect something with Raspberry Pi
PCF8591: 8bit AD/DA
converter, I2C interface
BMP280: pressure
sensor, I2C interface
PCF8574: I/O expension chip,
I2C interface
DS3231: real time clock chip,
I2C interface
Power indicator
user LED
joystick
LFN0038K IR
receiver
1 WIRE -
interface: to
connect
1 WIRE -
devices like
DS18B20
