Side 1/3

RF connection is done with the device powered

with battery only. You do not have to connect the

power supply. The product label must not be re-

moved as it contains important information re-

garding the product.

All alarms to be connected in the house should

be put into ‘Learn Mode’ by sliding the switch on

the back of the alarm to the ‘Learn Mode’ position.

Please note: The learn switch placed on the back

of the alarm can only be in learn position when

the alarm is disassembled from the power supply

unit. The learn switch will automatically switch to

normal position when the alarm head is tted to

the power supply.

The red LED will light up to indicate that ‘Learn

Mode’ has been selected.

Press and hold the test button at one alarm only,

until it beeps and the LED ashes. This alarm will

become the master and will start sending out a

specic house code to the other alarms.

As the other alarms receive the specic house

code, they will also ash the LED light.

When the red LED light flashes on all alarms,

they are connected and MUST BE SWITCHED

OUT OF ‘LEARN MODE’and installed.

Label the original “Learn” alarm in order to easily

add new CAVIUS Wireless Family alarms to the

system.

2. THE BEST AREAS TO INSTALL THE SMOKE

ALARM:

• Note the local country regulations regarding

installation.

• Note the local regulations about information

to your insurance company regarding installed

smoke alarms.

• Install an alarm between possible re sources

and bedrooms as a minimum.

• Install alarms on each oor of the house, in

hallways and landings.

• Alarms in each room such as bedrooms and

living rooms.

Additional alarms increase the security.

3. NOTAREAS WHERE TO INSTALL SMOKE

ALARMS:

• In dusty rooms

• At the top of a high pointed ceiling, in ceiling

corners, and within 50cm of a wall.

• In rooms where temperature goes outside the

range +4

to 38°Cor above 90% relative humidity

not condensing.

• In kitchens, garages, laundries, or too close to

replaces; areas where either dampness, gases

or smoke could occur.

Place the alarm where it is reachable in order to

test the alarm and for maintenance.

4. PLACEMENT:

The smoke alarm is designed to be installed on a

ceiling. With a minimum of one smoke alarm per

oor and a maximum distance between smoke

alarms of 10 meters.

For ceiling installation:

The smoke alarm should be a minimum of 30cm from

the wall.

Mains powered smoke alarm device

Model no.: 2208

The smoke alarm is designed for private homes.

PLEASE READ THE INSTALLATION GUIDE

CAREFULLY BEFORE INSTALLATION AND

RETAIN FOR FUTURE USE.

SAFETY INSTRUCTIONS:

The device comes with a 3V lithium battery. Bat-

teries are to be handled with care and battery pow-

ered devices should be kept out of reach of chil-

dren. Do not try to recharge or burn the batteries.

TECHNICAL INFORMATION:

battery with 10-year life (included).

It can be RF interlinked with other CAVIUS

Wireless Family alarms.

The maximum number of alarms that can be

interlinked within a house group are 32. Please

note: These must be alarms from the CAVIUS Wire-

less Alarm Family.

The distance between interlinked alarms depends

on the house layout and they should always be

tested after installation. It is not advised to install

alarms with a separation of more than 10m.

Diameter: 97mm. Height: 41mm (without mount-

ing base) 52mm (with mounting base).

1. HOW TO SET UP AND CONNECT ALARMS:

Start by pulling out the battery isolation strip as

shown.

Minimum 30cm

from wall

Wall

Ceiling

CHAMBER

FILTER

TEST BUTTON

SOUND

OUTPUT

RED & GREEN LED

Optical

Siting of Optical Smoke alarms

ISOLATION

STRIP

NORMAL MODE

LEARN MODE

Connect the 3 wires to the power supply: Live

feed (L1), neutral (N), earth ( ).

Screw the mounting base on the ceiling.

Screw the power supply on the mounting base.

Once the mounting base with power supply is

installed, attach the alarm by twisting clockwise

until it clicks.

OPTION 2: ALARM MOUNTED ON TOP OF

CONDUIT BOX:

Connect the 3 wires from the conduit box on the

alarm power supply:

Live feed (L1), neutral (N), earth ( ).

Screw the power supply on conduit box.

NOTE: Mounting base is not used when

the alarm is installed on conduit box.

6. SAFETY LOCK:

7. TEST FUNCTION:

After installation, and at least once per quarter,

test all of your alarms to ensure they are operating

correctly and are within range of each other.

It is recommended to check visually every week if

the LED ashes correctly (every 48sec.).

Press the test button on any alarm for at least

10 seconds.This will send out a test signal

from the alarm; all other connected alarms

should receive the signal within a short time.

The alarms will emit a short beep and the LED

will ash every 8 seconds for 2 minutes.

NOTE: Test function also transmits a weaker RF

signal to ensure an optimal operation in normal

conditions.

When the test signal is sent out, the alarms will

respond in two ways:

1. A single beep every 8 seconds indicates that

the alarms are connected and functioning.

2. Three short beeps every 8 seconds indicates a

smoke sensor fault. The alarm should be cleaned

by running the vacuum (on a low setting) around

the smoke alarm chamber and tested again.

For cathedral or peak ceiling:

5. INSTALLING THE SMOKE ALARM:

NOTE: THIS ALARM NEEDS TO BE INSTALLED

BY A PROFESSIONAL.

MAKE SURE ELECTRICITY IS SWITCHED OFF

BEFORE STARTING THE INSTALLATION.

CAUTION: LIVE, NEUTRAL AND EARTH MUST

BE CORRECTLY INSTALLED AND NOT MIXED UP.

NOTE: The alarm is delivered in the packaging

with a dust cover, installed to protect the alarm for

exposure to excessive dust which could potentially

damage or reduce the function of the alarm while

the building is under construction. The dust cover

must be removed after the building is fully cleaned.

OPTION 1: ALARM MOUNTED ON MOUNTING

BASE OUT ON THE CEILING:

Use the mounting base ring to mark the screw

holes on the ceiling.

For surface wiring pass the feed wire through

the mounting base cable holder and screw after

termination.

MARK UP

4 SCREW HOLES

WITH A PEN

USE THE

ENCLOSED

SCREWS AND

PLUGS

Peak ceiling

Minimum 60cm

from peak

Mount the

safety lock
