KA-B2

WIRING ADAPTER FOR

USE WITH FIRST ALERT®

AND BRK® WIRING HARNESS

User Guide

IMPORTANT! READ ALL INSTRUCTIONS BEFORE INSTALLATION

AND KEEP THIS GUIDE FOR FUTURE REFERENCE.

Read and become familiar with the user guide and all other literature

supplied with each alarm in your home.

! WARNING! If the power harness currently wired into the structure

does not match the photo in FIGURE 1, this is not the correct wiring

adapter for your application. This Connector Must Have An Orange

Interconnect Wire.

THIS ADAPTER CAN ONLY BE USED WHEN REPLACING FIRST

ALE R T ® AN D BRK ® MO DEL S ; S A4121 B , 4 1 2 0 , 4 919, 5 9 1 9 ,

AND 86 RAC WITH PLUG-I N CON NECTO R, MA NUFACTU RED

BEFORE JUNE 1, 2003. THESE MODELS HAVE BEEN TESTED

FOR INTERCONNECT COMPATIBILITY WITH THE KIDDE ALARM

MOD EL S : 1 235 , 12 7 5, 127 6 , 1 285 , i1 2 02 0 , i1 202 0 A, i1 2 040 ,

i12040A, i12060, i12060A, i12080, i12080A, i4618, i4618A, i4618AC,

KN-SMFM-I, RF-SM-ACDC, PE120, P12040, Pi2000, Pi2010, KN-COSM-I,

KN-COSM-IB, KN-COSM-IBA, KN-COPE-I, KN-COPE-IC, i12010S,

i12010SCO, P4010ACSCO, P4010ACSCO-W, P4010LACS-W, P4010ACS,

P4010ACS-W.

This smoke alarm adapter allows the installation of new Kidde alarm to

existing First Alert® and BRK® wiring harnesses. When using this adapter,

the power harness supplied with your new Kidde alarm is not used. You will

need to remove the existing First Alert

® or BRK® mounting plate and install

the mounting plate supplied with your new Kidde alarm. Connect the KA-B2

adapter to the First Alert® or BRK® wiring harness. To install the adapter,

pinch the tabs on the side and insert into the opening of your Kidde unit

(FIGURE 2). Secure the Kidde alarm to the mounting plate.

After installation, be sure that the AC power indicator is operating and test

all your alarms following the instructions supplied by the alarm manufacturer

for your specic alarm model. If the alarms are interconnected push the test

button on each alarm and verify that all the interconnected alarms sound

when any alarm is activated. The interconnect system should not exceed

the NFPA interconnect limit of 12 smoke alarms.

FIVE YEAR LIMITED WARRANTY

KIDDE Safety warrants the original purchaser that the enclosed smoke alarm

adapter will be free of defects in material and workmanship or design under

normal use and service for a period of ve years from the date of purchase.

The obligation of KIDDE Safety under this warranty is limited to repairing or

replacing the smoke alarm adapter which we nd to be defective in material,

workmanship or design, free of charge to the customer, upon sending the

smoke alarm adapter with proof of date of purchase, postage and return

postage prepaid to: Warranty Service Department, Kidde Safety, 1394 South

Third St, Mebane, NC 27302.

THE LIABILIT Y OF KIDDE SAFET Y OR ANY OF ITS PARENT OR

SUBSIDIARY CORPORATIONS ARISING FROM THE SALE OF THIS SMOKE

ALARM ADAPTER OR UNDER THE TERMS OF THIS LIMITED WARRANTY

SHALL NOT IN ANY CASE EXCEED THE COST OF REPLACEMENT OF

THE SMOKE ALARM ADAPTER AND IN NO CASE SHALL KIDDE SAFETY

OR ANY OF ITS PARENT OR SUBSIDIARY COPORATIONS BE LIABLE

FOR CONSENSEQUENTIAL LOSS OR DAMAGE RESULTING FROM THE

FAILURE OF THE SMOKE ALARM ADAPTER OR THE BREACH OR THIS OR

ANY OTHER WARRANTY, EXPRESSED OR IMPLIED, EVEN IF THE LOSS

IS CAUSED BY THE COMPANIES NEGLIGENCE OR FAULT.

Since some states do now allow limitations on the duration of an implied

warranty or do not allow the exclusion of limitations or incidental or

consequential damages, the above limitation or exclusions may not apply to

you. While this warranty gives you specific legal rights, you may also have

other rights, which vary, from state to state. The above warranty may not be

altered except in writing signed by both parties hereto.

Since some states do now allow limitations on the duration of an implied

warranty or do not allow the exclusion of limitations or incidental or

consequential damages, the above limitation or exclusions may not apply to

you. While this warranty gives you specific legal rights, you may also have

other rights, which vary, from state to state.

The above warranty may not be altered except in writing signed by both parties

hereto.

QUESTIONS OR FOR MORE INFORMATION

Call our Consumer Hotline at

1-800-880-6788

Or contact us at our web site www.kidde.com

Made in China

FIRST ALERT ® is a registered trademark of First Alert Trust.

BRK® is a registered trademark BRK Brands Inc. 1275-7246-00

FIGURE 1 FIGURE 2

KA-F2

WIRING ADAPTER FOR

USE WITH FIREX® WIRING HARNESS

User Guide

The Kidde and Firex alarm models listed in this user guide have been

tested to be interconnect compatible. That compatibility exists with or

without the use of the wiring harness adapters.

IMPORTANT! READ ALL INSTRUCTIONS BEFORE INSTALLATION AND

KEEP THIS USER GUIDE FOR FUTURE REFERENCE.

Read and become familiar with the user guide and all other literature

supplied with each alarm in your home.

! Warning! If the power harness currently wired into the structure

does not match the photo in FIGURE 1, this is not the correct wiring

adapter for your application.

T H I S A D A P T E R C A N O N LY B E U S E D W H E N R E P L A C I N G

FIREX® MODELS; FADC, ADC, AND AD. THESE MODELS HAVE

BE EN TE ST E D FOR INT ERCONN ECT CO MPAT IBI LIT Y W ITH

THE KIDDE ALARM MODELS: 1235, 1275, 1276, 1285, i12020,

i12020A, i12040, i12060, i12060A, i12080, i4618, i4618A, i4618AC,

K N - S M F M - I , P E 1 2 0 , P i 2 0 0 0 , K N - C O S M - I ,

K N - C O S M - I B , K N - C O S M - I B A , K N - C O P E - I ,

i12010S, i12010SCO, P4010ACSCO, P4010ACSCO-W, P4010LACS-W,

P4010ACS, P4010ACS-W.

This smoke alarm adapter allows the installation of new Kidde alarm to

existing Firex® wiring harnesses. When using this adapter, the power

harness supplied with your new Kidde alarm is not used. You will need

to remove the existing Firex® mounting plate and install the mounting

plate supplied with your new Kidde alarm. Connect the KA-F2 adapter

to the Firex® wiring harness then attach your Kidde alarm to the adapter

(FIGURE 2). Secure the Kidde alarm to the mounting plate.

After installation, be sure that the AC power indicator is operating

and test all your alarms following the instructions supplied by the

alarm manufacturer for your specic alarm model. If the alarms are

interconnected push the test button on each alarm and verify that all

the interconnected alarms sound when any alarm is activated. The

interconnect system should not exceed the NFPA interconnect limit of

12 smoke alarms.

Each alarm shall be installed and tested in accordance with its user

guide.
