60821, 60822

Hard Hat Turbo Cooling Fan -

Instructions (English - Page 2)

Ventilador turbo de enfriamiento para casco de seguridad tipo cachucha -

Instrucciones (Español - Página 3)

Ventilateur de refroidissement turbo pour casque de chantier-

Instructions (Français - Page 4)

BASED ON 1390771 Rev 04/24 A

FIG. A

FIG. B

FIG. C

FIG. D

FIG. H

FIG. I

FIG. J

FIG. E

FIG. F

FIG. G

The 60821/60822 Hard Hat Turbo Cooling Fan is

designed to fit on the brim of most hard hats and

safety helmets, but can also be used with the included

dual-mount strap and mounting bracket for shells

without a brim. The included Hinged Adapter Bracket

mounts directly to the front and back accessory

mounts on Klein Tools hard hats and safety helmets

as well as the dual Mount Strap for hard hats without

mounts. The fan is powered by a separate Modular

Battery (Cat. No. 29025, see battery instruction sheet

for features & specifications).

CONTENTS

•

Hard Hat Turbo Cooling Fan

•

Dual Mount Strap (Cat. no 60949)

•

Mount adapter bracket

•

Modular rechargeable Li-ion battery (see battery

instruction sheet for features & specifications

•

USB-A to USB-C charging cable

•

This Instruction Sheet

GENERAL SPECIFICATIONS

•

Con guration:

Centrifugal Dual-Inlet Fan

•

Dimensions:

2.7" × 2.6" × 1.6"

(69 × 65 × 40 mm)

•

Weight (fan only):

3.17 oz. (90 g)

•

Runtime (full-charge, continuous use):

Turbo:

6 hours

High:

8 hours

Low:

12 hours

•

Drop Protection:

6.6' (2 m)

•

Ingress Protection (IP) Rating:

IPX4

Conforms To

UL STD. 507

Certi ed To

CSA NO C22.2 No

60335-1, 60335-2-80

Specifications subject to change.

WARNINGS

Read, understand, and follow these instructions

to ensure safe operation. Failure to observe

these warnings can result in risk of  re and

burns, electric shock, serious injury and/or

property damage. Always check with your site

safety supervisor before use of this product.

Local regulations may not permit use. Keep this

user manual and comply with the instructions

provided for this product.

•

For use with Klein Tools batteries ONLY

•

Before each use, inspect components for damage

Secure and keep any loose hair away from the fan

•

DO NOT use a damaged or modified battery.

Damaged or modified batteries may exhibit

unpredictable behavior resulting in fire, explosion

or risk of injury.

•

Risk of fire and burns. DO NOT open, crush,

heat above specified maximum temperature o

incinerate. Prolonged exposure to direct sunlight

can result in elevated temperatures

•

DO NOT immerse in water or other liquids

•

Properly seal the USB port cover to achieve

specified water & foreign object ingress protection

Keep seal free of dirt, oil, sand, or other material

that interferes with proper sealing. Failure to do so

can result in risk of fire or electric shock

•

DO NOT open the USB port cover if wet or in a wet

environment. Thoroughly dry the unit and the sea

around water-resistant cover completely before

opening water resistant cover

•

DO NOT subject to vibration, impacts, or drops

greater than 6.6' (2m). The housing may not show

signs of damage, but internal components may

have been compromised. It is advisable to replace

the unit if any such severe events occur

•

Per CSA C22.2 60335-1. This appliance is not

intended for use by persons (including children

with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge

unless they have been given supervision or

instruction concerning use of the appliance by a

person responsible for their safety. Children should

be supervised to ensure that they do not play with

the appliance.

•

DO NOT attempt to repair the battery, fans, or

charging cable. There are no user-serviceable

parts.

5017951

CUSTOMER SERVICE

KLEIN TOOLS, INC.

450 Bond Street, Lincolnshire, IL 60069

1-800-553-4676

customerservice@kleintools.com

www.kleintools.com

DISPOSAL / RECYCLE

Do not place equipment and its

accessories in the trash. Items

must be properly disposed of in

accordance with local regulations

See

www.epa.gov/recycle

for

additional information

ENGLISH

SYMBOLS ON FAN

Warning or Caution

Read Instructions

Independently tested by Intertek and

meets applicable standards

FEATURE DETAILS (FIG.A)

Power / Mode Button

Spring Bracket/Brim Clip

Integrated USB-C Power Cable

Air Intake Vents

Adjustable Vent

Cable Management Clip

Klein Mount Brackets (×2)

Hinged Adapter Bracket

Adapter Bracket Release Tab

29025 Modular Battery

Adjustable Silicone Strap

INSTALLATION

Inspect and familiarize yourself with the

components that need to be assembled onto

the hard hat or safety helmet, then follow the

instructions below to install and use the fan.

DO NOT try to rework or substitute missing or

damaged components.

NOTE: It is highly recommended that a

chinstrap be used, even for hard hat models

that do not include one, especially on jobs

at-height or requiring constant head motion.

An optional Klein Tools Chinstrap for Klein

Tools hard hats ONLY is available (Cat. No.

KHHSTRP). A chinstrap is included with Klein

Tools Safety Helmets. Use the appropriate

chinstrap for any other brand.

KLEIN FULL-BRIM & REVERSED-DONED CAP-

STYLE HARD HATS

Slide the Spring Bracket/Brim Clip

onto

the hard hat brim (FIG. B).

Attach the Modular Battery

to the hard

hat's accessory mount (FIG. B)

Attach the Integrated USB-C Power Cable

USB-C Input/Output Port on the battery

(FIG. H).

To prevent the cable from snagging, use the

Cable Management Clip

to attach the to

the brim or wall of the hard hat (FIG. I).

Adjust vent for desired direction of airflow

(FIG. J).

The fan is now ready to be used (FIG. C)

KLEIN CAP STYLE (BRIM IN FRONT) AND

SAFETY HELMETS

Attach the Spring Bracket/Brim Clip

the fan onto the

Hinged Adapter Bracket

, then install assembly into the shell's rea

accessory mount (FIG. D).

Install Modular Battery

into the opposite

accessory mount (FIG. D).

Attach the Integrated USB-C Power Cable

USB-C Input/Output Port on the battery

(FIG. H).

To prevent the cable from snagging, use the

Cable Management Clip

to attach the to

the brim or wall of the hard hat (FIG. I).

Adjust vent for desired direction of airflow

(FIG. J).

Flip the fan into thedown position

(FIG. E).

The fan is now ready to be used (FIG. E)

INSTALLATION

HARD HATS AND SAFETY HELMETS

WITHOUT KLEIN MOUNTS

Install the Adjustable Silicone Strap

onto the shell

ensuring that the Klein Mount

Brackets

are centered on the front and

back of the shell. Adjust strap as necessary

to achieve a secure fit (FIG. F)

Install Modular Battery

into the

appropriate Klein Mount Adapter Bracket

(FIG. F).

To install fan:

FULL-BRIM HARD HATS:

Slide the Spring

Bracket/Brim Clip

onto the hard hat

brim (FIG. B)

SAFETY HELMETS OR CAP STYLE HARD

HATS:

Attach

the Spring Bracket/Brim

Clip

of the fan onto the Hinged Adapter

Bracket

, then install into the appropriate

Klein Mount Adapter Bracket

(FIG. F).

Attach the Integrated USB-C Power Cable

USB-C Input/Output Port on the battery

(FIG. H).

To prevent the cable from snagging, use the

Cable Management Clip

to attach the to

the brim or wall of the hard hat (FIG. I).

Adjust vent for desired direction of airflow

(FIG. J).

Flip the fan into thedown position

(FIG. G).

The fan is now ready to be used (FIG. G)

OPERATING INSTRUCTIONS

The power / Mode Button

cycles through

Turbo Mode, High Mode, Low Mode, and Off:

Power-on the fan by single-pressing

the Power / Mode Button

. The fan

defaults to Turbo Mode upon powering on

Single-press the Power / Mode Button

repeatedly to cycle through the modes and/

or power-off the fan

Adjust the direction of the airflow by

positioning the Adjustable Ven

downward to push air up into the shell, or

upward to push air down towards the neck

area (FIG. J).

NOTE: It could take 10-15 seconds

(or more) to feel effects of proper air

circulation, especially in a very hot

environment.

NOTE: To install second fan, follow the

same instructions, connecting the second

fan to the battery's unused USB port. The

fans will operate independently per the

OPERATION section above (FIG. H).

NOISE LEVELS

The fans emit noise below 85db while in use

Klein Tools recommends wearing earplugs i

you experience discomfort

CLEANING

Prior to cleaning, be sure fan is disconnected

from the battery. Use clean, dry, soft lint-free

cloth to wipe down. If any debris is stuck in the

fan blades or vents, gently free any objects using

a blunt wooden pick.

DO NOT

use harsh cleaning

chemicals, sharp metal picks, abrasive brushes

and/or pressurized air to dislodge stuck debris

from the fan blades. The debris may become

dislodged inside the fans and permanently

damage the fan and electronics.

Wipe down the cables with soft, clean, dry cloth

Inspect for tears, cuts, cracks, corrosion, bent

connectors, discoloration and other such damage

DO NOT

attempt to repair.

STORAGE

NOTE: It is highly recommended to remove the

fan(s) and battery from the hard hat or safety

helmet prior to placing in storage.

DAILY STORAGE:

To reduce potential for damage to the fan(s) if

storing while still attached to a hard hat, flip the

fan(s) upward into the storage position, and

store hard hat on a flat, clean surface (FIG. H).

LONG-TERM STORAGE:

Be sure battery and fan(s) are disconnected

from one another and any other power sources

or devices. Store components in a cool, dry

place away from direct sunlight when not in

use.

After taking out of storage,visually inspect fan,

battery and all accessories for any damage

Replace any damaged parts as needed. It is

recommended to clean each component prior to

use (See CLEANING section above).

Allow all components to return to ambien

conditions before recharging battery and/or

operating.

REPLACEMENT PARTS AND ACCESSORIES

•

29025

– Replacement Modular Battery

•

60822

– Replacement Hard Hat Turbo Fan

•

60949

– Dual-Mount Hard Hat Strap

•

56049

– Rechargeable Light Array Headlamp,

260 Lumens

•

56062

– Rechargeable Headlamp/Worklight,

300 Lumens

•

56063

– Safety Lamp

•

56414

– Rechargeable 2-Color LED

Headlamp

FCC & IC COMPLIANCE

See this product’s page at

www.kleintools.com

for

FCC compliance information

Canada ICES-003 (B) / NMB-003 (B)

Produkt Specifikationer

Mærke:	Klein Tools
Kategori:	Ikke kategoriseret
Model:	60822

Har du brug for hjælp?

Hvis du har brug for hjælp til Klein Tools 60822 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Ikke kategoriseret Klein Tools Manualer

Klein Tools 50550 Manual

13 Juni 2025

Klein Tools VDV826-704 Manual

3 Juni 2025

Klein Tools 34055 Manual

18 Marts 2025

Klein Tools 60957 Manual

18 Marts 2025

Klein Tools 60953 Manual

18 Marts 2025

Klein Tools 34056 Manual

17 Marts 2025

Klein Tools MODbox 54801MB Manual

12 Marts 2025

Klein Tools 56417 Manual

13 Februar 2025

Klein Tools 54825MB Manual

14 Januar 2025

Klein Tools ESF100 Manual

5 Januar 2025

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

AmpliVox Airvox SW695 Manual

15 Juni 2025

Stiga SBC 635 KD Manual

15 Juni 2025

Cleveland 36CGM300 Manual

15 Juni 2025

Gourmia GTF7970 Manual

15 Juni 2025

Planet Audio P9630B Manual

15 Juni 2025

ORNO OR-DOM-YR-934UD Manual

15 Juni 2025

Lavex 842CD12VST12 Manual

15 Juni 2025

Marshall RCP-PLUS Manual

15 Juni 2025

Hughes & Kettner BassForce XL Manual

15 Juni 2025

Hughes & Kettner Red Box Mk III Manual

15 Juni 2025
