Side 1/50

P/N: 2900-300802 Rev 6 www.kramerAV.com

USER MANUAL

MODEL:

PA-240Z

240W Power Amplifier

PA-120Z

120W Power Amplifier

Kramer Electronics Ltd.

PA-120Z, PA-240Z – Contents
i

Contents
Introduction  1
Getting Started  1
Overview  2
Typical Applications  3
Defining the PA-240Z 240W Power Amplifier  4
Connecting the PA-240Z  6
Connecting the Output to a Balanced/Unbalanced Stereo Audio Acceptor  7
Connecting a Balanced/Unbalanced Stereo Audio Source to the Balanced Input  8
Connecting to PA-240Z via RS-232  8
RJ-45 Pinout  8
Connecting PA-240Z via the Ethernet Port  9
Operating the PA-240Z  12
Setting the DIP-Switches  12
Adjusting the Master Volume  12
Using the Embedded Web Pages  13
Setting the Speaker Output Parameters  15
Setting the Line Level Output Parameters  17
Selecting Hi-Z Mono Settings  18
Changing Standby Settings  19
Setting Device Parameters  19
Managing Web Page Security  23
Viewing the About Page  26
Technical Specifications  27
Default Communication Parameters  28
Protocol 3000  29
Understanding Protocol 3000  29
Kramer Protocol 3000 Syntax  31
Protocol 3000 Commands  32
