Side 1/4

TP TP-583Txr/ -583Rxr Quick Start

P/N:

2900- 301159QS

Rev:

Scan for full manual

TP TP-583Txr/ -583Rxr Quick Start Guide

This guide helps you install and use your TP-583Txr/TP-583Rxr for the first time.

Go to www.kramerav.com/downloads/TP-583Txr, TP-583Rxr to download the latest user manual and check

if rmware upgrades are available.

Step 1: Check what’s in the b ox

TP-583Txr HDMI Line Transmitter or

1 Power adapter and cord

1 Quick start guide

TP-583Rxr HDMI Line Receiver

4 Rubber feet

1 Bracket set

Step 2: Get to know your -583Txr and -583Rxr TP TP

TP-583Txr

Feature

Function

IN LED

Lights green when an active source device input signal is detected.

OUT LED

Lights green when an active, far- sink (acceptor) connection is end

detected via the HDBT link.

LINK LED

Lights green when an HDBT link is established with the HDBaseT

receiver.

ON LED

Lights green when the device receives power.

LINE RJ-45 Connector

Connect to the RJ- HDBT LINE connector on a receiver (for 45

example, so on TP-583Rxr, TP-780Rxr and ).

HDMI IN Connector ™

Connect to an HDMI source.

SETUP DIP-switches

Set the operation DIP-switches.

RS-232 (G, Rx, Tx) 3-pin Terminal Block Connector

Connect to a laptop to control the receiver or perform rmware

upgrade.

Connect to a controller device (for example, ) to serially SL-240C

control a remote device (for example, the HDMI OUT acceptor) that

is connected to . TP-583Rxr

IR 3.5mm Mini Jack Connector

Connect to an external infrared emitter / sensor.

12V DC Power Connector

12V DC connector for powering the unit.

TP-583Rxr

Feature

Function

IN LED

Lights green when an active, far- source device input signal is end

detected via the HDBT link.

OUT LED

Lights green when an active sink (acceptor) connection is detected.

LINK LED

Lights green when an HDBT link is established with the HDBaseT

transmitter.

ON LED

Lights green when the device receives power.

LINE RJ- Connector 45

Connect to the RJ- HDBT LINE connector on a transmitter (for 45

example, TP-583Txr, TP- T780 xr and so on).

HDMI OUT Connector

Connect to an HDMI acceptor.

SETUP DIP-switches

Set the operation DIP-switches.

RS-232 (G, Rx, Tx) 3-pin Terminal Block

Connector

Connect to a laptop to control the receiver or perform rmware

upgrade.

Connect to a serially controlled device (for example, the HDMI OUT

acceptor) to enable its control by a remote controller device (for

example, ) that is connected to . SL-240C TP-583Txr

IR 3.5mm Mini Jack Connector

Connect to an external infrared emitter / sensor.

12V DC Power Connector

12V DC connector for powering the unit.

Step 3: Install -583Txr/ -583Rxr TP TP

Install / using one of the following methods: TP-583Txr TP-583Rxr

• Attach the rubber feet and place the unit on a at surface.

• Fasten a bracket (included) on each side of the unit and attach it to a at surface.

For more information go to

www.kramerav.com/downloads/TP-583Txr, TP-583Rxr.

• Mount the unit in a rack using the recommended rack adapter

(see

www.kramerav.com/product/TP-583Txr, TP-583Rxr).
