Lab Gruppen LUCIA 60/2 Manual

Lab Gruppen Modtager LUCIA 60/2

Læs gratis den danske manual til Lab Gruppen LUCIA 60/2 (2 sider) i kategorien Modtager. Denne vejledning er vurderet som hjælpsom af 9 personer og har en gennemsnitlig bedømmelse på 4.5 stjerner ud af 5 anmeldelser. Har du et spørgsmål om Lab Gruppen LUCIA 60/2, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

W W W . L A B G R U P P E N . C O M

LUCIA® 60/2

Technical Data

LUCIA: Localized Utility Compact Intelligent Ampliﬁcation

▸ Maximum output power across range of loads – 2 x 30 W

into 8, 4 or 2 ohms

▸ Comprehensive DSP features – Per channel presets for

high-pass filter, parametric EQ, multi-band compressor,

and look-ahead limiter

▸ Automatic Dynamic Loudness Contouring™ – DSP

automatically adapts to optimize performance at any

output level

▸ Optimized presets – Available for specific loudspeaker models

▸ Auto Load Sense™ – Proprietary auto-set VPL™ (Voltage Peak

Limiter) for optimum performance with any connected load

▸ 2 x 2 mix matrix – Route input signals internally to either one or

both amplifier channels

▸ Configuration software – Windows and Mac software wizard for

initial set-up, and advanced editor for preset configuration (LUCIA

connection via USB)

▸ RS232 – Remote control and monitoring from third party

control solutions

▸ GPIO – Remote control (e.g.

wall panel) for channel switching,

level control and integration with paging systems

▸ Efficient Class D amplifier – Patented design for low distortion

and minimal heat dissipation

▸ Compact form factor – Half-rack, 1U chassis and supplied

bracket for discreet on-wall mounting (e.g. behind

display screens)

▸ Intelligent fan control – Silent operation at idle and at lower

output levels

▸ Fail-safe operation – Comprehensive short circuit, thermal,

and under-voltage protection

▸ Universal power supply – Operates at 100 - 240 V AC

(50 or 60 Hz)

▸ ENERGY STAR® qualified – Conforms to latest specification

energy efficiency standards

Great sound, ﬂexibility and ease of use

Lab.gruppen’s innovative LUCIA (Localized Utility Compact

design. Power, processing, control and I/O are conveniently placed

exactly where they are needed. In many AV applications requiring

solution that eliminates the complications and added expense

Lab.gruppen output stage.

Fast installation, reliable operation

wall-mount bracket enabling discreet on-wall placement behind

video displays. All connections are via Euroblock screw terminals,

and level setting is available on front-panel potentiometers. An

loudspeakers from potential damage caused by clipping, thermal

overload, or extreme low line voltage.

Green credentials

period with no signal input, consuming less than 1 watt. Automatic

power-up occurs within two seconds after an input signal is sensed.

•

Retail outlets

• Bars & restaurants

• Entertainment venues

• Corporate board rooms

• Classrooms

• Multimedia spaces

• Hotel reception/lobbies

• Museums & galleries

• Small corporate event

spaces

Applications

Presets available at launch for selected Tannoy loudspeakers including the industry

leading CMS Series in-ceiling systems

Produkt Specifikationer

Mærke:	Lab Gruppen
Kategori:	Modtager
Model:	LUCIA 60/2
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	216 mm
Dybde:	280 mm
Højde:	44 mm
Vægt:	1900 g
Produktfarve:	Sort
Equalizer:	Ja
Strømforbrug (standby):	1 W
Materiale:	Aluminium, Steel
Frekvensområde:	5 - 22000 Hz
Forbindelsesteknologi:	Ledningsført
Lyd-output kanaler:	2.0 kanaler
Certificering:	CE, CSA, CCC, PSE, FCC, Energy Star
LED-indikatorer:	Ja
Højpasfilter:	Ja
Bæredygtighedscertifikater:	ENERGY STAR
Formål:	Hjem
klirfaktor (THD):	0.3 %
Signal/støjforhold:	95 dB
Forstærker klasse:	D
Spidseffekt pr. kanal:	30 W
Højttalere tilslutningstype:	Euroblok
Indgangsimpedans:	10000 ohm (Ω)
Kølingstype:	Aktiv
Linie indgående (RCA):	2
Krydstale (1 kHz):	60 dB
Rackkapacitet:	1U
