Side 1/78
ENGLISH_index
65QNED90UPA
65QNED95UPA
65QNED99UPA
75QNED90UPA
75QNED95UPA
75QNED99UPA
86QNED90UPA
86QNED99UPA
www.lg.com
Copyright © 2021 LG Electronics Inc. All Rights Reserved.
Printed in Korea
LED TV*
Safety and Reference
OWNER’S MANUAL
Please read this manual carefully before operating
your set and retain it for future reference.
* LG LED TV applies LCD screen with LED backlights.
*MFL71793633*
(2106-REV01)
2
Important Safety Instruction
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the
apparatus.
•Only use attachments/accessories specified by the manufacturer.
•Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
By using this product, you agree that all disputes between you and LG arising out of or relating in any way to this product (including but not limited
to warranty disputes) shall be resolved exclusively through binding arbitration on an individual basis. The terms of the arbitration agreement
(including details on the procedure for resolving disputes) is available at www.lg.com/us/arbitration (USA) or www.lg.com/ca_en/arbitration
(Canada).
3
Title
Before reading this manual
•Read this manual thoroughly before operating your TV, and keep it for future reference.
•On the website you can download the manual including installation, using, troubleshooting, specifications, license etc and view its
contents on your PC or mobile device.
User Guide For more information about this TV, read the USER GUIDE embedded in the product. (Depending upon model)
•To open the USER GUIDE [Support] [User Guide] → → →
Optional Extras
•Optional extras can be changed or modified for quality improvement without any notification. Contact your dealer for buying these
items. These devices work only with certain models.
•The model name or design may be changed due to the manufacturer’s circumstances or policies.
•A cable to connect antennas and external devices must be purchased separately.
Note •Product specifications or contents of this manual may be changed without prior notice due to upgrade of
product functions.
•The items supplied with your product may vary depending upon the model.
•Image shown may differ from your TV.
Warning! Safety instructions
Preparing
-Lifting and moving the TV
-Mounting on the Table
-Mounting to the Wall
-Antenna/Cable
Starting TV
-Turning on the TV
-Registering Magic Remote Control
-Connecting Smart Devices using NFC Tagging
Using Remote Control
-Using Magic Remote Control
Connections
Troubleshooting
Specifications
-Open Source Software Notice Information
-Licenses
Regulatory
5
•Disconnecting the Device from the Main Power
-The power plug is the disconnecting device. In case of an
emergency, the power plug must remain readily accessible.
•Do not let your children climb or cling onto the TV. Otherwise,
the TV may fall over, which may cause serious injury.
•Outdoor Antenna Grounding (Can differ by country):
-If an outdoor antenna is installed, follow the precautions
below.
An outdoor antenna system should not be located in the
vicinity of overhead power lines or other electric light or
power circuits, or where it can come in contact with such
power lines or circuits as death or serious injury can occur.
Be sure the antenna system is grounded to provide some
protection against voltage surges and built-up static
charges.
Section 810 of the National Electrical Code (NEC) in
the U.S.A. provides information with respect to proper
grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge unit,
connection to grounding electrodes and requirements for
the grounding electrode.
Antenna grounding according to the National Electrical
Code, ANSI/NFPA 70
•Grounding (Except for devices which are not grounded.)
-TV with a three-prong grounded AC plug must be
connected to a three-prong grounded AC outlet. Ensure
that you connect the earth ground wire to prevent possible
electric shock.
•Never touch this apparatus or antenna during a lightning
storm. You may be electrocuted.
•Make sure the power cord is connected securely to the TV and
wall socket if not secured damage to the Plug and socket may
occur and in extreme cases a fire may break out.
•Do not insert metallic or inflammable objects into the
product. If a foreign object is dropped into the product,
unplug the power cord and contact the customer service.
•Do not touch the end of the power cord while it is plugged in.
You may be electrocuted.
•If any of the following occur, unplug the product
immediately and contact your local customer service.
-The product has been damaged.
-If water or another substance enters the product (like an AC
adapter, power cord, or TV).
-If you smell smoke or other odors coming from the TV.
-When lightning storms or when unused for long periods
of time.
Even the TV is turned off by remote control or button, AC
power source is connected to the unit if not unplugged in.
•Do not use high voltage electrical equipment near the TV
(e.g., a bug zapper). This may result in product malfunction.
•Do not attempt to modify this product in any way without
written authorization from LG Electronics. Accidental fire or
electric shock can occur. Contact your local customer service
for service or repair. Unauthorized modification could void the
user’s authority to operate this product.
•Use only an authorized attachments / accessories approved
by LG Electronics. Otherwise, this may result in fire, electric
shock, malfunction, or product damage.
•Never disassemble the AC adapter or power cord. This may
result in fire or electric shock.
•Handle the adapter carefully to avoid dropping or striking it.
An impact could damage the adapter.
•To reduce the risk of fire or electrical shock, do not touch
the TV with wet hands. If the power cord prongs are wet or
covered with dust, dry the power plug completely or wipe
dust off.
7
Preparing
Lifting and moving the TV
When moving or lifting the TV, read the following to prevent the TV from being scratched or damaged and for safe transportation regardless of its
type and size.
•It is recommended to move the TV in the box or packing material that the TV originally came in.
•Before moving or lifting the TV, disconnect the power cord and all cables.
•When holding the TV, the screen should face away from you to avoid damage.
•Hold the top and bottom of the TV frame firmly. Make sure not to hold the transparent part,
speaker, or speaker grille area.
•Use at least two people to move a large TV.
•When transporting the TV by hand, hold the TV as shown in the following illustration.
•When transporting the TV, do not expose the TV to jolts or excessive vibration.
•When transporting the TV, keep the TV upright; never turn the TV on its side or tilt towards the left or right.
•When handling the TV, be careful not to damage the protruding buttons.
•Avoid touching the screen at all times, as this may result in damage to the screen.
•Do not place the product on the floor with its front facing down without padding. Failure to do so may result in damage to the screen.
•When attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from
scratches.
8
Mounting on the Table
1 Lift and tilt the TV into its upright position on a table.
• Leave a minimum of 10 cm (4 inches) space from the wall for proper
ventilation.
2 Connect the power cord to a wall outlet.
10cm
10cm
(4inches)
10cm
(Depending upon model)
•Do not apply foreign substances (oils, lubricants, etc.) to the screw parts when assembling the product. (Doing so may damage the
product.)
•If you install the TV on a stand, you need to take actions to prevent the product from overturning. Otherwise, the product may fall over,
which may cause injury.
•Do not use any unapproved items to ensure the safety and lifespan of the product.
•Any damages or injuries by using unapproved items are not covered by the warranty.
•Make sure that the screws are fastened tightly. (If they are not fastened securely enough, the TV may tilt forward after being installed.)
•Do not fasten the screws with excessive force otherwise they may strip and become loose.
Securing TV to the Wall
1 Insert and tighten the eye-bolts or TV brackets and bolts on the back of the TV.
• If there are bolts inserted at the eye-bolts position, remove the bolts first.
2 Mount the wall brackets with the bolts to the wall. Match the location of the wall bracket and the
eye-bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly with a sturdy rope or cable. Make sure to keep
the rope parallel to the flat surface.
•Use a platform or cabinet that is strong and large enough to support the TV securely.
•Brackets, bolts, and ropes are optional. You can obtain additional accessories from your local
dealer. (Depending upon model)
9
Mounting to the Wall
An optional wall mount can be used with your LG Television. Consult with
your local dealer for a wall mount that supports the VESA standard used
by your TV model. Carefully attach the wall mount bracket at the rear of
the TV. Install the wall mount bracket on a solid wall perpendicular to the
floor. If you are attaching the TV to other building materials, please contact
qualified personnel to install the wall mount. Detailed instructions will be
included with the wall mount. We recommend that you use an LG brand
wall mount. The LG wall mount is easy to adjust or to connect the cables.
When you do not use LG’s wall mount bracket, use a wall mount bracket
where the device is adequately secured to the wall with enough space to
allow connectivity to external devices. If you are using a non-adjustable
mount, attach the mount to the wall. Attach the cables to the TV first, then
attach the TV to the mount.
10cm
10cm (4inches)
10cm
10cm
(Depending upon model)
•Remove the stand before installing the TV on a wall mount by performing the stand attachment in reverse.
•For more information of screws and wall mount bracket, refer to the Separate Purchase.
•If you intend to mount the product to a wall, attach VESA standard mounting interface (optional parts) to the back of the product.
When you install the set to use the wall mounting bracket (optional parts), fix it carefully so as not to drop.
•When mounting a TV on the wall, make sure not to install the TV by hanging the power and signal cables on the back of the TV.
•Do not install this product on a wall if it could be exposed to oil or oil mist. This may damage the product and cause it to fall.
•When installing the wall mounting bracket, it is recommended to cover the stand hole using tape, in order to prevent the influx of dust and
insects, (Depending upon model).
Stand hole
(Depending upon model)
10
Wall Mounting Bracket
(Depending upon model)
Make sure to use screws and wall mount bracket that meet the VESA standard. Standard dimensions for the wall mount kits are described in the
following table.
A
B
Model
65QNED90*
65QNED95*
65QNED99*
Model
75QNED90*
75QNED95*
75QNED99*
86QNED90*
86QNED99*
Screws distance (A)
(mm) 400 Screws distance (A x B)
(mm) 1,281x125 1,586x125
Standard screw Standard screwM6 M8 M8
Number of screws Number of screws2 4 4
Wall mount bracket Wall mount bracket WB21LMC WB21LGB WB21LGB
A
B
Model
65/75QNED90*
65/75QNED95*
65/75QNED99*
86QNED90*
86QNED99*
VESA (A x B) (mm) 400x400 600x400
Standard screw M6 M8
Number of screws 4 4
Wall mount bracket LSW440B LSW640B
12
Starting TV
Turning on the TV
You can simply operate the TV functions, using the button.
Using button
Power On (Press)
Power Off1) (Press and Hold)
Menu Control (Press2))
Menu Selection (Press and Hold3))
1) All running apps will close.
2) You can access and adjust the menu by pressing the button when TV is on.
3) You can use the function when you access menu control.
Note •When the TV is turned on for the first time after being shipped from the factory, initialization of the TV may take
approximately one minute.
Adjusting the menu
When the TV is turned on, press the button one time. You can adjust the Menu items using the button.
Turns the power off. Changes the input source.
Adjusts the volume level. Scrolls through the saved channels.
Note •Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
•The available menus and options may differ from the input source or product model that you are using.
•New features may be added to this TV in the future.
•The device must be easily accessed to a location outlet near the access. Some devices are not made by turning on / off
button, turning off the device and unplugging the power cord.
13
Inserting the battery
When the message [Magic Remote battery is low. Please change the battery.] is displayed, replace
the batteries.
To install batteries, open the battery cover, replace batteries (1.5VAA) matching the and
ends to the label inside the compartment, and close the battery cover.
To remove the batteries, perform the installation actions in reverse.
•Do not mix new batteries with old batteries. This may cause the batteries to overheat and leak.
•Failure to match the correct polarities of the battery may cause the battery to burst or leak, resulting in fire, personal injury, or ambient
pollution.
•This apparatus uses batteries. In your community there might be regulations that require you to dispose of these batteries properly due
to environmental considerations. Please contact your local authorities for disposal or recycling information.
•Batteries inside or inside the product shall not be exposed to excessive heat such as sunshine, fire or the like.
Registering Magic Remote Control
How to register the Magic Remote Control
To use the Magic Remote, first pair it with your TV.
1 Put batteries into the Magic Remote and turn the TV on.
2 Point the Magic Remote at your TV and press the on the remote control. Wheel (OK)
* If the TV fails to register the Magic Remote, try again after turning the TV off and back on.
How to deregister the Magic Remote Control
Press the and buttons at the same time, for five seconds, to unpair the Magic Remote with your TV.(Back) (Home)
* Press and hold the and (Home) (Q. Settings) buttons for more than 5 seconds to disconnect and re-register the Magic Remote at the
same time.
•It is recommended that an Access Point (AP) be located more than 0.2m (0.65ft) away from the TV. If the AP is installed closer than
0.2m (0.65ft), the Magic remote control may not perform as expected due to frequency interference.
14
Connecting Smart Devices using NFC Tagging
Using the NFC Feature
NFC is technology that uses Near Field Communication, allowing you to conveniently send and receive information without separate settings. By
bringing a smart device near the NFC-enabled remote control, you can install the LG ThinQ app and connect the device to the TV.
1 Turn on NFC in the smart device’s settings. To use NFC with Android devices, set the NFC option to enable ‘read/write tags’ in the smart device's
settings. The NFC settings may vary depending upon the device.
2 Bring the smart device near the (NFC) on the remote control. The required distance for NFC tagging is about 1 cm (0.39inches).
3 Follow the instructions to install the LG ThinQ app on your smart device.
4 Retagging the smart device to the remote control allows you to conveniently access various features on the connected TV through the LG ThinQ
app.
Note •This feature is available for NFC-enabled smart devices only.
•This feature is only available if the remote control has an NFC logo.
15
Using Remote Control
Using Magic Remote Control
(Depending upon model)
The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly.
This remote uses infrared light. When in use, it should be pointed in the direction of the TV’s remote sensor.
Power Turns the TV on or off.
Inserts a between numbers (DASH)
such as 2-1 and 2-2.
Accesses the saved channel list.
Accesses the [Guide].
Accesses the [Edit Quick Access].
-[Edit Quick Access] is a feature that allows
you to enter a specified app or Live TV
directly by pressing and holding the
number buttons.
Volume buttons Adjusts the volume level.
Home Accesses the Home menu.
Home Launches the last used apps.
Wheel (OK) Press the center of button
to select a menu. You can change channels
by using button.
Wheel (OK) Accesses the [Magic Explorer].
You can run the [Magic Explorer] feature
when the pointer color is changed to purple.
If watching a channel, press and hold down
the pointer onto the video. When using [TV
Guide], [Settings], [Sports Alert], or [Art
Gallery], press and hold down on the text.
Up/Down/Left/Right Press the up, down,
left or right button to scroll the menu. If you
press buttons while the pointer is in use,
the pointer will disappear from the screen
and Magic Remote will operate like a general
remote control. To display the pointer on the
screen again, shake Magic Remote to the
left and right.
Back Returns to the previous level.
Back Clears on-screen displays and returns
to last input viewing.
1 1
11
1 1
Microphone
Number buttons Enters numbers.
Accesses the [Quick Help].
More actions Displays more remote
control functions.
SAP (Secondary Audio Program) feature
can also be enabled by pressing the
button.
Channel buttons Scrolls through the
saved channels.
Mute Mutes all sounds.
Mute Accesses the [Accessibility] menu.
Voice recognition Network
connection is required to use the voice
recognition function.
Check for recommended content. (Some
recommended services may not be
available in some countries.)
Voice recognition Speak while
pressing and holding the button to use
the voice recognition feature.
Input Changes the input source.
Input Accesses the [Home Dashboard].
Q. Settings Accesses the Quick
Settings.
Q. Settings Displays the [All Settings]
menu.
These access special functions in some
menus.
1Streaming Service buttons Connects
to the Video Streaming Service.
(Some buttons and services may not be provided depending upon models or regions.)
Note To use the button, press and hold for more than 1 second.
16
Connections
You can connect various external devices to the TV. For more information on external device’s connection, refer to the manual provided with each
device.
HDMI •When connecting the HDMI cable, the product and external devices should be turned off and unplugged.
•Supported HDMI Audio format (Depending upon model):
True HD (48kHz),
Dolby Digital / Dolby Digital Plus (32kHz / 44.1kHz / 48kHz),
PCM (32kHz / 44.1kHz / 48kHz / 96kHz / 192kHz)
Note •If the device connected to Input Port also supports HDMI Deep Color, your picture may be clearer. However,
if the device doesn’t support it, it may not work properly. In that case, change the TV’s [HDMI Deep Color]
setting to off.
-This feature is available only on certain models which support HDMI Deep Color.
• [General] [Devices] [HDMI Settings] [HDMI Deep Color]→ → → → →
(Only QNED90*)
-On : Support 4K @ 50/60 Hz (4:4:4, 4:2:2, 4:2:0),
<3,4 port Only> 4K @ 100/120 Hz (4:4:4, 4:2:2, 4:2:0)
-Off : Support 4K @ 50/60 Hz (4:2:0)
(Except for QNED90*)
-8K: Support 8K @ 50/60Hz (4:4:4, 4:2:2, 4:2:0)
-4K: Support 4K @ 50/60Hz (4:4:4, 4:2:2, 4:2:0), 4K @ 100/120Hz (4:4:4, 4:2:2, 4:2:0)
-Off: Support 4K @ 50/60Hz (4:2:0)
•Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the screen may
not display or a connection error may occur.
•Recommended HDMI cable types (3m (9.84feet) or less)
-Ultra High Speed HDMI®/™ cable
Note •For an optimal connection, HDMI cables and USB devices should have bezels less than 10mm (0.39inches)
thick, 18mm (0.7inches) width and 8mm (0.31inches) a wire diameter. (Depending upon model)
•Use an extension cable that supports if the USB cable or USB flash drive does not fit into your TV’s
USB port.
A
B
C
A
B* A
<
=
10mm (0.39inches)
* B
<
=
18mm (0.7inches)
* C
<
=
8mm (0.31inches)
17
IR Blaster Control the set-top box (cable/satellite/IP/OTT), Blu-ray/DVD player, soundbar, game consoles, etc., using the IR
Blaster (Depending upon country) (Depending upon model).
Note •Connect the IR Blaster cable to the TV’s IR Blaster port.
•Place both ends (one or two) of the IR Blaster in front of the external device as shown in the picture below.
•Use universal control settings to control the device. Go to [General] [Devices] → → → →
[External Devices] [Universal Control Settings].→
•Secure the IR Blaster with the 3M tape provided.
External
Devices
Supported external devices are: Blu-ray player, HD receivers, DVD players, VCRs, audio systems, USB storage
devices, PC, gaming devices, and other external devices. For more information on external device’s connection,
refer to the manual provided with each device.
Note •If you record a TV program on a Blu-ray/DVD recorder or VCR, make sure to connect the TV signal input
cable to the TV through a DVD recorder or VCR. For more information about recording, refer to the manual
provided with the connected device.
•The external device connections shown may differ slightly from illustrations in a manual.
•Connect external devices to the TV regardless about the order of the TV port.
•If you connect a gaming device to the TV, use the cable supplied with the gaming device.
•Refer to the external equipment’s manual for operating instructions.
•In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or brightness. If
noise is present, change the PC output to another resolution, change the refresh rate to another rate or
adjust the brightness and contrast on the [Picture] menu until the picture is clear. Depending upon the
graphics card, some resolution settings may not allow the image to be positioned on the screen properly.
•Some USB Hubs may not work. If a USB device connected through a USB Hub is not detected, connect it
directly to the USB port on the TV.
•When connecting via a wired LAN, it is recommended to use a CAT 7 cable.
•The TV may be capable of operating without a set-top-box from a multichannel video programming
distributor (MVPD).
Remote
RS-232C
setup
To obtain the RS-232C external control setup information, please visit www.lg.com. Download and read the
manual, (Depending upon model).
•Do not drop the product or let it fall over when connecting external devices. Otherwise, this may result in
injury or damage to the product.
•When connecting external devices such as video game consoles, make sure the connecting cables are long
enough. Otherwise, the product may fall over, which may cause injury or damage the product.
18
Troubleshooting
Cannot control the
TV with the remote
control.
•Check if anything such as tape has been placed over the receiver.
•Check if there is any obstacle between the product and the remote control.
•Replace the batteries with new fresh ones.
No image display and
no sound is produced.
•Check if the product is turned on.
•Check if the power cord is connected to a wall outlet.
•Check if there is a problem in the wall outlet by connecting other products.
The TV turns off
suddenly.
•Check the power control settings. The power supply may be interrupted.
•Check if the auto-off function is activated in the settings menu.
•If there is no signal while the TV is on, the TV will turn off automatically after 15 minutes of inactivity.
Abnormal Display •If the TV feels cold to the touch, there may be a small flicker when it is turned on. This is normal; there
is nothing wrong with TV. Some minute dot defects may be visible on the screen, appearing as tiny red,
green, or blue spots. However, they have no adverse effect on the TV’s performance. Avoid touching the LCD
screen or holding your finger(s) against it for long periods of time. Doing so may produce some temporary
distortion effects on the screen.
•This panel is an advanced product that contains millions of pixels. In a very few cases, you could see fine
dots on the screen while you’re viewing the TV. Those dots are deactivated pixels and do not affect the
performance and reliability of the TV.
•Displaying a still image for a prolonged period of time may cause an image sticking. Avoid displaying a fixed
image on the TV screen for a extended length of time.
Generated Sound •Cracking noise A cracking noise that occurs when watching or turning off the TV is generated by plastic
thermal contraction due to temperature and humidity. This noise is common for products where thermal
deformation is required.
•Electrical circuit humming/panel buzzing A low level noise is generated from a high-speed switching
circuit, which supplies a large amount of current to operate a product. It varies depending upon the product.
This generated sound does not affect the performance and reliability of the product.
•When cleaning the product, be careful not to allow any liquid or foreign objects to
enter the gap between the upper, left or right side of the panel and the guide panel,
(Depending upon model).
•Make sure to wring any excess water or cleaner from the cloth.
•Do not spray water or cleaner directly onto the TV screen.
•Make sure to spray just enough of water or cleaner onto a dry cloth to wipe the screen.
20
(Except for QNED99*)
Wireless module(LGSBWAC95)Specifications
Wireless LAN (IEEE 802.11a/b/g/n/ac)
Frequency range Output Power (Max.)
2,400 to 2,483.5 MHz 18.5dBm
5,150 to 5,725 MHz 18dBm
5,725 to 5,850 MHz 18dBm
Bluetooth
Frequency range Output Power (Max.)
2,400 to 2,483.5 MHz 9dBm
As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional
frequency table.
For consideration of the user, this device should be installed and operated with a minimum distance of 20 cm (7.8 inches) between the device and
the body.
FCC ID: BEJLGSBWAC95 / IC: 2703H-LGSBWAC95
Environment condition
Operating Temperature 0°C to 40°C (32°F to 104°F)
Operating Humidity Less than 80%
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Storage Humidity Less than 85%
21
Open Source Software Notice Information
To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product, please visit https://opensource.lge.
com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of
media, shipping, and handling) upon email request to opensource@lge.com.
This offer is valid for a period of three years after our last shipment of this product. This offer is valid to anyone in receipt of this information.
Licenses
(Magic Remote supported models only)
22
Regulatory
-
-
-
-
23
(1)
(2)
(3)
(4)
24
NOTE TO CABLE/TV INSTALLER
(For USA and Canada)
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as
close to the point of the cable entry as practical.
WARNING! (STABILITY HAZARD)
A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions
such as:
-ALWAYS use cabinets or stands or mounting methods recommended by the manufacturer of the television set.
-ALWAYS use furniture that can safely support the television set.
-ALWAYS ensure the television set is not overhanging the edge of the supporting furniture.
-ALWAYS educate children about the dangers of climbing on furniture to reach the television set or its controls.
-ALWAYS route cords and cables connected to your television so they cannot be tripped over, pulled or grabbed.
-NEVER place a television set in an unstable location.
-NEVER place the television set on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the television
set to a suitable support.
-NEVER place the television set on cloth or other materials that may be located between the television set and supporting furniture.
-NEVER place items that might tempt children to climb, such as toys and remote controls, on the top of the television or furniture on which the
television is placed.
If the existing television set is going to be retained and relocated, the same considerations as above should be applied.
Symbols
Refers to alternating current (AC). Refers to stand-by.
Refers to direct current (DC). Refers to “ON” (power).
Refers to class II equipment. Refers to dangerous voltage.
FRANÇAIS
65QNED90UPA
65QNED95UPA
65QNED99UPA
75QNED90UPA
75QNED95UPA
75QNED99UPA
86QNED90UPA
86QNED99UPA
www.lg.com
Copyright © 2021 LG Electronics inc. Tous droits réservés.
TÉLÉVISEUR À DEL*
Sécurité et références
MANUEL D’UTILISATION
Veuillez lire ce manuel attentivement avant d’utiliser l’appareil
et conservez-le pour pouvoir vous y reporter ultérieurement.
* La mention « Téléviseur à DEL de LG » s’applique à l’écran ACL avec rétroéclairage à DEL.
2
Directives de sécurité importantes
•Lisez ces directives.
•Conservez ces directives.
•Soyez attentif à tous les avertissements.
•Suivez toutes les directives.
•N’utilisez pas cet appareil près de l’eau.
•Nettoyez-le uniquement avec un linge sec.
•Ne bloquez pas les ouvertures d’aération. Installez l’appareil en respectant les directives du fabricant.
•N’installez pas l’appareil près de sources de chaleur comme les radiateurs, les bouches de chaleur, les fours et tout autre appareil (y compris les
amplificateurs) produisant de la chaleur.
•Ne contournez pas la fonction sécuritaire de la fiche polarisée ou de type mise à la terre. Une fiche polarisée est munie de deux lames, dont l’une
est plus large que l’autre. Une fiche de mise à la terre comporte deux lames et une broche de mise à la terre. La lame la plus large ou la broche de
mise à la terre sont fournies pour votre sécurité. Si la fiche fournie ne s’insère pas dans votre prise, consultez un électricien pour la remplacer.
•Protégez le cordon d’alimentation de manière à ce qu’il ne soit ni piétiné ni pincé, particulièrement près de la fiche, des prises de courant et du
point de sortie de l’appareil.
•N’utilisez que les articles ou les accessoires recommandés par le fabricant.
•Utilisez uniquement avec un chariot, un socle, un trépied ou une table recommandé par le fabricant ou vendu avec l’appareil. Si vous déplacez
l’appareil à l’aide d’un chariot, faites preuve de prudence afin de prévenir les blessures causées par un basculement.
•Débranchez cet appareil pendant les orages électriques ou lorsqu’il n’est pas utilisé pendant de longues périodes.
•Confiez l’ensemble des réparations à du personnel qualifié. Une intervention est nécessaire dans les cas suivants: si la prise ou le cordon
d’alimentation est endommagé, si un liquide a été renversé sur l’appareil ou si des objets sont tombés dans l’appareil, si l’appareil a été exposé à
la pluie ou à l’humidité, s’il ne fonctionne pas normalement ou s’il est tombé.
En utilisant ce produit, vous acceptez que tout différend entre vous et LG relativement à ce produit ou découlant de ce dernier de quelque manière
que ce soit (y compris, sans toutefois s’y limiter, les différends concernant la garantie) se règle exclusivement par arbitrage exécutoire au cas par
cas. Les modalités de l’entente d’arbitrage (y compris les détails sur la procédure de règlement des différends) se trouvent sur les sites
www.lg.com/us/arbitration (États-Unis) et www.lg.com/ca_fr/arbitrage (Canada).
3
Titre
Avant de lire ce manuel
•Veuillez lire ce manuel attentivement avant d’utiliser votre téléviseur et le conserver pour pouvoir vous y reporter ultérieurement.
•Sur le site Web, vous pouvez télécharger le manuel qui comprend des renseignements sur l’installation, l’utilisation, le dépannage,
lescaractéristiques, la licence, etc., et consulter son contenu sur votre ordinateur ou votre appareil mobile.
Manuel
d’utilisation
Pour de plus amples renseignements sur ce téléviseur, lisez le MANUEL D’UTILISATION fourni avec le produit.
(Selon le modèle)
•Pour ouvrir le MANUEL D’UTILISATION [Assistance] [Guide d’utilisation] → → →
Articles supplémentaires en option
•Les articles vendus séparément peuvent être remplacés ou modifiés à des fins d’amélioration de la qualité, sans préavis. Communiquez
avec votre détaillant pour vous procurer ces articles. Ces dispositifs ne fonctionnent qu’avec certains modèles.
•Le nom ou la conception du modèle peuvent être modifiés selon les conditions ou les politiques du fabricant.
•Un câble pour brancher des antennes et des périphériques externes doit être acheté séparément.
Remarques •Les caractéristiques du produit ou le contenu de ce manuel peuvent être modifiés sans préavis à des fins de mise
à niveau des fonctionnalités du produit.
•Les articles fournis avec votre produit peuvent varier selon le modèle.
•L’image présentée peut ne pas correspondre à votre téléviseur.
Avertissements! Directives de sécurité
Préparation
-Soulèvement et déplacement du téléviseur
-Installation sur une table
-Installation sur un mur
-Antenne/Câble
Démarrage du téléviseur
-Mise sous tension du téléviseur
-Enregistrement de la télécommandeMagic
-Connexion d’appareils intelligents à l’aide du balisage de
communication en champ proche (NFC)
Utilisation de la télécommande
-Utilisation de la télécommandeMagic
Connexions
Dépannage
Caractéristiques techniques
-Informations sur les logiciels libres
-Licences
Réglementation
4
Avertissements! Directives de
sécurité
MISE EN GARDE
RISQUE DE DÉCHARGE ÉLECTRIQUE
NE PAS OUVRIR
MISE EN GARDE : AFIN DE RÉDUIRE LE RISQUE DE DÉCHARGE ÉLECTRIQUE, NE RETIREZ PAS LE COUVERCLE (OU LE PANNEAU ARRIÈRE). AUCUNE
PIÈCE POUVANT ÊTRE RÉPARÉE PAR L’UTILISATEUR NE SE TROUVE À L’INTÉRIEUR DE L’APPAREIL. CONFIEZ L’ENTRETIEN DE CET APPAREIL À DU
PERSONNEL QUALIFIÉ.
Ce symbole a pour fonction d’alerter l’utilisateur de la présence d’une tension dangereuse non isolée à l’intérieur du boîtier de l’appareil
qui pourrait être d’une puissance suffisante pour causer une décharge électrique.
Ce symbole vise à alerter l’utilisateur de la présence de directives d’utilisation et d’entretien importantes dans la documentation
accompagnant l’appareil.
AVERTISSEMENT: AFIN DE RÉDUIRE LE RISQUE D’INCENDIE ET DE DÉCHARGE ÉLECTRIQUE, N’EXPOSEZ PAS CE PRODUIT À LA PLUIE OU À
L’HUMIDITÉ.
•POUR ÉVITER LA PROPAGATION DES FLAMMES, MAINTENEZ À
TOUT MOMENT CE PRODUIT LOIN DES BOUGIES OU D’AUTRES
ÉLÉMENTS À FLAMMES NUES.
•N’installez pas le téléviseur ni la télécommande dans
les environnements suivants:
-En exposition directe à la lumière du soleil.
-Dans une zone avec une forte humidité comme une salle
de bains.
-À proximité d’une source de chaleur comme une cuisinière
et tout autre appareil produisant de la chaleur.
-À proximité des comptoirs de cuisine ou des
humidificateurs où ils peuvent facilement être exposés à de
la vapeur ou à de l’huile.
-Dans une zone exposée à la pluie ou au vent.
-Dans une zone où il existe un risque de ruissellement ou
d’éclaboussure. Évitez de poser des objets contenant du
liquide (p. ex. vase, tasse) sur l’appareil ou au-dessus de
celui-ci(p.ex.sur une tablette).
-À proximité d’objets inflammables comme de l’essence
ou des bougies, ou en exposition directe à un système de
climatisation.
-Dans un endroit très poussiéreux.
Cela pourrait entraîner des risques d’incendie, de décharge
électrique, de combustion, d’explosion, de mauvais
fonctionnement ou d’altération du produit.
•Aération
-Installez votre téléviseur à un endroit où l’aération est
suffisante. Ne l’installez pas dans un espace restreint
comme une bibliothèque.
-N’installez pas le produit sur un tapis ou un coussin.
-N’obstruez pas les ouvertures de l’appareil et ne le
recouvrez pas avec du tissu ou tout autre matériau lorsqu’il
est branché.
•Prenez soin de ne pas toucher aux ouvertures d’aération.
Lorsque le téléviseur fonctionne pendant une longue période,
les ouvertures d’aération peuvent devenir chaudes.
•Protégez le cordon d’alimentation contre les dommages
physiques ou mécaniques. Veillez notamment à ce qu’il ne
soit pas tordu, déformé, pincé, coincé dans une porte ou
piétiné. Soyez particulièrement attentif aux fiches, aux prises
de courant murales et à l’emplacement de sortie du cordon
sur l’appareil.
•Ne déplacez pas le téléviseur lorsque le cordon d’alimentation
est branché.
•N’utilisez pas un cordon d’alimentation endommagé ou
desserré.
•Assurez-vous de bien saisir la fiche lorsque vous débranchez
le cordon d’alimentation. Ne tirez pas sur le cordon
d’alimentation pour débrancher le téléviseur.
•Ne branchez pas trop d’appareils dans une même prise de
courant alternatif, car cela pourrait causer un incendie ou une
décharge électrique.
7
Préparation
Soulèvement et déplacement du téléviseur
Lorsque vous désirez déplacer ou soulever le téléviseur, lisez tout d’abord ce qui suit pour éviter d’égratigner ou d’endommager le téléviseur ainsi que
pour effectuer un transport sécuritaire sans égard au type ni à la taille du téléviseur.
•Il est recommandé de déplacer le téléviseur en utilisant la boîte ou le matériel d’emballage d’origine.
•Avant de déplacer ou de soulever le téléviseur, débranchez le cordon d’alimentation et tous les câbles.
•Lorsque vous manipulez le téléviseur, veillez à ce que l’écran ne soit pas orienté vers vous pour
éviter de l’endommager.
•Tenez fermement le haut et le bas du cadre du téléviseur. Assurez-vous de ne pas tenir la
partie transparente, le haut-parleur ou la grille du haut-parleur.
•La présence d’au moins deux personnes est requise pour déplacer un téléviseur de grande
taille.
•Lorsque vous transportez un téléviseur dans vos mains, tenez-le tel qu’il est illustré ci-contre.
•Lorsque vous transportez le téléviseur, évitez de l’exposer à des chocs ou à des vibrations excessives.
•Lorsque vous transportez le téléviseur, maintenez-le à la verticale; ne le tournez jamais sur le côté et ne le penchez ni à gauche ni à droite.
•Lors de la manipulation du téléviseur, veillez à ne pas endommager les boutons en saillie.
•Évitez de toucher l’écran, car cela pourrait l’endommager.
•Ne déposez pas le produit sur le plancher si la partie avant (l’écran) n’est pas posée sur une surface coussinée. Cela pourrait
endommager l’écran.
•Pour fixer le socle au téléviseur, placez l’écran face contre une table ou une surface plane matelassée afin de le protéger contre les
rayures.
9
Installation sur un mur
Un support de fixation murale offert en option peut être utilisé pour
installer votre téléviseur LG. Consultez votre détaillant local afin de
trouver un support de fixation murale qui correspond aux normes VESA
de votre modèle de téléviseur. Fixez soigneusement le support de fixation
murale au dos de votre téléviseur. Installez-le sur un mur solide qui est
perpendiculaire au sol. Si vous installez le téléviseur sur des matériaux de
construction autres que ceux indiqués dans cette section, veuillez faire
appel à du personnel qualifié pour installer le support de fixation murale.
Des directives détaillées seront comprises avec le support de fixation
murale. Nous vous recommandons d’utiliser un support de fixation murale
de marque LG. Le support de fixation murale de LG est facile à ajuster, et les
câbles s’y branchent aisément. Si vous n’utilisez pas un support de fixation
murale de LG, utilisez un support permettant de poser l’appareil au mur
de façon sécuritaire et offrant suffisamment d’espace pour la connexion de
périphériques externes. Si vous utilisez un support de fixation non réglable,
installez-le sur le mur. Branchez d’abord les câbles sur le téléviseur, puis
placez le téléviseur sur le support.
10cm
10cm (4 po)
10cm
10cm
(Selon le modèle)
•Avant d’installer le téléviseur sur un support de fixation murale, retirez son socle en suivant la procédure inverse de son installation.
•Pour de plus amples renseignements sur les vis et les supports de fixation murale, reportez-vous à la section Achats séparés.
•Si vous avez l’intention d’installer le produit sur un mur, fixez l’interface de fixation VESA (pièces en option) à l’arrière du produit. Sivous
souhaitez fixer l’appareil à un mur à l’aide d’un support de fixation murale (pièces en option), fixez-le soigneusement pour qu’il ne
tombe pas.
•Lors de l’installation du téléviseur au mur, assurez-vous de ne pas le suspendre à l’aide du câble de signal ou du cordon d’alimentation
se trouvant à l’arrière du téléviseur.
•N’installez pas le téléviseur sur un mur où il pourrait être exposé à de l’huile ou à un brouillard d’huile. Cela peut endommager le
produit et provoquer sa chute.
•Lors de l’installation du support mural, il est recommandé de couvrir les orifices de fixation du socle avec du ruban adhésif pour éviter
l’intrusion de poussière ou d’insectes. (Selon le modèle)
Orifice de fixation du socle
(Selon le modèle)
10
Support de fixation murale
(Selon le modèle)
Assurez-vous d’utiliser des vis et un support de fixation murale conformes à la normeVESA. Les dimensions standards des trousses de fixation murale
sont indiquées dans le tableau suivant.
A
B
Modèle
65QNED90*
65QNED95*
65QNED99*
Modèle
75QNED90*
75QNED95*
75QNED99*
86QNED90*
86QNED99*
Distance des vis (A) (mm) 400 Distance des vis (A x B)
(mm) 1281x125 1586x125
Vis standard Vis standardM6 M8 M8
Nombre de vis Nombre de vis2 4 4
Support de fixation
murale WB21LMC Support de fixation
murale WB21LGB WB21LGB
A
B
Modèle
65/75QNED90*
65/75QNED95*
65/75QNED99*
86QNED90*
86QNED99*
VESA (A x B) (mm) 400x400 600x400
Vis standard M6 M8
Nombre de vis 4 4
Support de fixation
murale LSW440B LSW640B
11
Antenne/Câble
Pour regarder la télévision, raccordez le téléviseur à une antenne, au câble ou à un décodeur de câblodistribution en vous reportant aux instructions
suivantes. Les illustrations peuvent différer des articles réels, et l’utilisation d’un câble RF est facultative.
•Assurez-vous de ne pas plier le fil de cuivre du câbleRF. Fil de cuivre
•Pour éviter d’endommager votre téléviseur, faites d’abord toutes les connexions entre les appareils, puis branchez le cordon d’alimentation
dans la prise d’alimentation.
•Utilisez un dispositif d’aiguillage de signaux pour utiliser deux téléviseurs ou plus.
•Codecs audio TVN pris en charge : MPEG, Dolby Digital
•Ce téléviseur ne peut pas recevoir de contenu diffusé en ULTRA-HD(3840x2160pixels) directement parce que les normes correspondantes
n’ont pas été confirmées.
Produkt Specifikationer
| Mærke: | LG |
| Kategori: | TV |
| Model: | QNED MiniLED 90 |
Har du brug for hjælp?
Hvis du har brug for hjælp til LG QNED MiniLED 90 stil et spørgsmål nedenfor, og andre brugere vil svare dig
TV LG Manualer
22 Juli 2025
22 Juli 2025
22 Juli 2025
11 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
TV Manualer
- Peerless-AV
- Saba
- OK
- EKO
- Blaupunkt
- Doffler
- Krüger&Matz
- Vivax
- Trevi
- Jay-tech
- Lenovo
- Sceptre
- Eizo
- Sunny
- Alba
Nyeste TV Manualer
23 Juli 2025
23 Juli 2025
23 Juli 2025
23 Juli 2025
23 Juli 2025
23 Juli 2025
23 Juli 2025
23 Juli 2025
22 Juli 2025
22 Juli 2025
