TECHNICAL DATA SHEET

Part No

36295

DESCRIPTION RELATED PRODUCTS

7.5M DISPLAYPORT CABLE 1.2, GOLD LINE

DP MALE TO MALE

7.5m DisplayPort Cable 1.2, Gold Line

No compromise, ultimate performance DisplayPort cable for demanding environments and mission critical systems

Supports UHD resolutions up to 4096x2160@60Hz 4:4:4 8bit

Full metal 24K gold plated housing, 24K gold plated connectors and contacts

Low attenuation triple shielded cable, corrosion resistant, high performance OFC 24AWG conductors

DisplayPort 1.2 compliant: 3D, 4K, 21.6Gbps, DisplayPort Certified; 25 year warranty

From the Lines cable connectivity concept developed by Lindy, Gold Line DisplayPort cables are the no compromise, high

performance connection solution for use in the most demanding professional environments.

Gold Line DisplayPort cables feature triple shielded construction with 24AWG OFC conductors for premium performance and

corrosion resistance. High quality 24K gold plated contacts and connectors maintain optimal signal integrity and maximum

reliability.

UHD resolutions up to 4K 4096x2160@60Hz 4:4:4 8bit, including stereoscopic 3D and HDCP are supported. DisplayPort 1.2

technology and DisplayPort compliance certification ensures compatibility with all DisplayPort enabled devices.

These superior quality cables utilise a unique low attenuation design that ensures consistent and reliable transmission even over

very long distances.

Gold DisplayPort cables are available in lengths from 0.5m to 20m.

36290 - 0.5m (1.64ft)

36291 - 1m (3.28ft)

36292 - 2m (6.56ft)

36293 - 3m (9.84ft)

36294 - 5m (16.40f)

36295 - 7.5m (24.61ft)

36296 - 10m (32.81ft)

36297 - 15m (49.21ft)

36298 - 20m (65.62ft)

DP Male to Male

No.

EAN

7.5M DISPLAYPORT CABLE 1.2, GOLD LINE

Pin Construction

19.8x42.5x12.5mm

(0.78x1.67x0.49in)

24K Gold 15µm

Phosphor Bronze

Standard

Colour

Connector A

Connector B

Housing Material

Connector Plating

DisplayPort Male

24 Gold Plated Zinc Alloy

Maximum Resolution

Nominal Attenuation

Supported Bandwidth

Pin Plating

Dimensions (approx.) WxDxH

SPECIFICATONS

PURCHASING INFORMATION

90mm (3.5in)

-20°C - 80°C (-4°F - 176°F)

-25°C - 80°C (-13°F - 176°F)

Minimum Bend Radius

Operating Temperature

Storage Temperature

ATC Approved

CABLE CONSTRUCTION

CONNECTORS

4096x2160@60Hz 4:4:4 10bit

Con

ductor Material

Conductor Gauge

Shielding

21.6Gbps

Copper Braid 85%

MISCELLANEOUS

Warranty (Years)

24AWG

Packaging Type

Polybag

CE, UKCA, RoHS,

RE UACH, L

DisplayPort Male

24K Gold 3µm

OFC Copper

Length 7.5m (24.61ft)

DisplayPort 1.2

Grey

Round

9mm (0.35in)

Type

Jacket Diameter

Jacket Material

Certificated

4002888362955

300kHz-825MHz <5dB

825MHz-2.475GHz <5dB

2.475GHz-4.125GHz <12dB

4.125GHz-5.1GHz <20dB

36295 36290 - 0.5m (1.64ft)

36291 - 1m (3.28ft

)

6292 - 2m (6.56ft)

36293 - 3m (9.84ft

)

294 - 5m (16.40f

)

36295 - 7.5m (24.61ft)

36296 - 10m (32.81ft

)

6297 - 15m (49.21ft)

36298 - 20m (65.62ft)

AVAILABLE IN OTHER LENGTHS

Produkt Specifikationer

Mærke:	Lindy
Kategori:	Kabler til computere og periferiudstyr
Model:	36295
Produktfarve:	Grå
Opbevaringstemperatur (T-T):	-25 - 85 °C
Driftstemperatur (T-T):	-20 - 80 °C
Certificering:	REACH, UL
Kabellængde:	7.5 m
Harmoniseret systemkode (HS):	84733080
Bæredygtighedscertifikater:	RoHS
DisplayPort-version:	1.2
Stik 1:	DisplayPort
Stik 2:	DisplayPort
Stik 1 køn:	Hanstik
Stik 2 køn:	Hanstik
Stikforbindelse kontakter plettering:	Guld
Dataoverførselshastighed:	21.6 Gbit/sek.
Materiale for kapper:	Polyvinylchlorid (PVC)
AWG-ledningsstørrelse:	24
