TECHNICAL DATA SHEET

Part No.

38344

DESCRIPTION RELATED PRODUCTS

100m Cat.6 HDMI 4K60, Audio, IR & RS-232 HDBaseT 3.0 KVM Extender

Extend uncompressed HDMI signals up to 100m via HDBaseT

100M CAT.6 HDMI 4K60, AUDIO, IR & RS-232 HDBASET 3.0 KVM

EXTENDER

EXTEND UNCOMPRESSED HDMI SIGNALS UP TO 100M VIA HDBASET

Distributes HDMI resolutions up to 100m over Cat.6 network cable via HDBaseT technology

Supports HDMI 18G resolutions up to 4K@60Hz 4:4:4, with additional support for HDR

ARC/eARC Support as well as USB, RS-232, CEC & Ethernet pass-through & bi-directional IR for simple control

Supports PoC (Power over cable), requiring a power supply connection from only one side of the installation

2 year warranty

The Lindy 100m Cat.6 HDMI 4K60, Audio, IR & RS-232 HDBaseT KVM Extender is a complete end to end high performance, reliable

solution for extending uncompressed HDMI signals over long distances via Cat.6 network cable.

The following distance and resolution combinations are possible when using high quality Cat.6 U/UTP or F/UTP cable:

100m: 3840x2160@60Hz 4:4:4 8bit / 4:2:2 12bit

Supporting resolutions up to 4K Ultra HD, video can be viewed in stunning clarity, while additional support for HDR (High Dynamic

Range) allows content to be displayed with enhanced brightness, greater contrasts of blacks and whites and a much wider colour

gamut. This provides a reliable solution for creating eye-catching digital signage in retail, immersive displays at events or engaging

setups in larger conference rooms or lectures halls.

An HDMI loop-out port on the transmitter allows an additional local display to be connected to the source side of the installation.

ARC and eARC support over HDMI allows for audio content to be returned from the display to a connected amplifier or soundbar, while

local audio extraction allows for the connection of audio outputs for immersive multi-channel audio. Audio embedding or de-

embedding at the transmitter side can easily be switched via the push button on the main unit while it supports audio de-embedding

at the receiver side to connect an audio source.

PoC (Power over Cable) functionality provides additional flexibility. This allows power to be supplied alongside data through Cat.6

network cable in a point-to-point connection between the transmitter and receiver, meaning only a single power supply is required at

the transmitter unit. Ideal when power outlets are limited at the receiver end of the installation.

USB 2.0 ports allow for mouse, keyboard, and other devices to be connected to both units to control a source device such as a PC or

laptop from each side of the installation. Featuring bi-directional IR ports at both sides of the setup, the source equipment can be

easily controlled from the display side, and the display can also be controlled from the HDMI source side. Combined with CEC control,

which allows commands from one main remote, this extension system allows for complete and simple control for the user. Bi-

directional RS-232 and Ethernet ports also allow for integration into larger control systems, or connection to network switches and

hubs with LAN access.

In addition, the power supply is connected via a screw type DC jack, providing a more secure and reliable connection, perfect for

professional installations where accidental disconnections could create a major issue.

HDBaseT is a globally recognised standard for high quality distribution of AV content and other technologies, including power and

control, over longer distances via low cost Cat.6 or above cable.

TDS TMP - AV // AV EXT (CAT FIBRE IP HDBaseT)

PURCHASING INFORMATION

Transmitter Input

HDMI Type A (Female)

USB Type B (Female)

3.5mm IR (Female)

MISCELLANEOUS

CE, UKCA, FCC, RoHS, REACH &

California Proposition 65

290x75x220mm

(11.42x2.95x8.66in)

Carton BoxPackaging Type

1.101kg (2.43lb)

4002888383448

38344

No.

Power Requirements

Operating Temperature

HDBaseT HDMI KVM Extender, Transmitter

HDBaseT HDMI KVM Extender, Receiver

IR Emitter Cable, 1.5m

IR Receiver Cable, 1.5m

4 x Mounting Ears & 8 x Screws

2 x 3-Pin Terminal Block

Multi-country Power Supply (UK, EU, US & AUS)

Lindy Manual

Transmitter Bi-directional Port

AV Interface

Interface Standard

Supported Bandwidth

CONNECTORSSPECIFICATIONS

HDMI

HDMI 2.0, USB 2.0

18 Gbps

100M CAT.6 HDMI 4K60, AUDIO, IR & RS-232 HDBASET

3.0 KVM EXTENDER

100m (328.08ft) 3.5mm Audio (Female)

RS-232 3-Pin Terminal Block

RJ-45 Ethernet (Female)

-20°C - 60°C (-4°F - 140°F)

0°C - 40°C (32°F - 104°F)

VS3000

Special Features

HDMI Loop Out Port

USB Host/Device on each

unit

PoC (Power over Cat.6)

ARC/eARC and Audio

embedding/de-embedding

Wavelength (only for Fibre)

Chipset

Storage Temperature

Net Weight

170x88x20mm

(6.69x3.46x0.79in) per unit

Transmitter Output

HDMI Type A (Female)

RJ-45 (Female)

TosLink (Optical) (Female)

3.5mm Audio (Female)

PACKAGING CONTENTS

Maximum Distance

Receiver Output

2.3

HDCP Support

Supported Audio

TosLink (Optical)

Laser Class (only for Fibre) -

CEC Support

Pass-through

Maximum Resolution

Separate Audio Ports

EDID Pass Through Pass-through

RJ-45 (Female)

USB Type B (Female)

TosLink (Optical) (Female)

3.5mm IR (Female)

HDMI Type A (Female)

2 x USB Type A (Female)

3.5mm Audio (Female)

3.5mm IR (Female)

Transmission Protocol HDBaseT 3.0

3840x2160@60Hz 4:4:4 8bit

Receiver Input

Receiver Bi-directional Ports RS-232 3-Pin Terminal Block

RJ-45 Ethernet (Female)

20 - 60KHz

Power

5.5/2.1mm

Transmission Medium

1 x Cat.6

Serial Interface RS-232

HDMI Audio Pass-through

TosLink (Optical) Up to 5.1Ch

3.5mm Up to 2.0Ch

IR Support

Housing Material

Metal

EAN

Packaging Dimension

Gross Weight

Certificated

Warranty (Years)

PHYSICAL PROPERTIES

Black

24VDC 1A

Dimensions (approx.) WxDxH

0.862kg (1.9lb)

20 - 90% RH (non-condensing)

Colour

Humidity
