User Guide ( )English
Introduction
Box Contents
BX4 Speakers (Stereo Pair)
Foam Feet
2-Prong IEC Power Cable
1/8” TS Speaker Interconnect Cable
1/8” to 1/8” TRS Aux Cable
1/8” TRS to RCA Cable
User Guide
Safety & Warranty Manual
Product Registration and Support
To download your included software, follow the instructions below:
1. Vist m-audio.com/softwaredownload.
2. Follow the on-screen instructions to register your product.
3. Upon successful registration, any applicable software downloads, product codes
and promotions will show in your account.
Note: A high-speed internet connection is recommended. If you need assistance, do not
return your product to the dealer. Instead, please contact our helpful technical support team
by visiting m-audio.com/support.
Setup
The configuration and placement of your BX4 monitors on speaker stands or your desktop
workstation may affect the performance of the speakers. Use the following tips to achieve the best
performance out of your BX4 monitors.
Tip: If possible, place your BX4 monitors on speaker stands instead of your desktop. Desks tend to
resonate sympathetically at low frequencies and may adversely affect the bass response of your
monitors. If speaker stands are not possible due to space restrictions and you notice a buildup in
bass, try placing the monitors on isolation pads to acoustically de-couple the monitors from the
desk.
Precautions
• Correct Power Operation: Since the BX4 contains amplifiers, it must be connected to a power
outlet. Before connecting power, please make sure that the Vol/Power knob is set to the off
position.
• Foam Feet: In order to maximize physical stability, we recommend you use the provided foam
feet on the bottoms of the BX4 monitors.
• Connecting to a Computer Sound Card or Other Audio Output Device: Your BX4 speakers
have a variety of inputs for use with a multitude of devices. Before connecting the BX4
speakers, make sure the power from the computer or other output device has been turned off
and the BX4 speakers are also turned off. Connect the RCA or 1/4" (6.35 mm) input jacks to the
corresponding output connectors of a computer sound card, portable music player, etc. You
can also use the included 1/8" (3.5 mm) TRS stereo aux cable to connect a secondary audio
device to the Aux input on the front of the BX4.
