Side 1/31

EN - English -Quick Guide

EN - English -Quick GuideEN - English -Quick Guide:

This is a wireless network device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.

https://mt.lv/um

Technical specifications, brochures, and more info about products at https://mikrotik.com/products

The most important technical specifications for this product can be found on the last page of this Quick Guide.

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants

This Device accepts input from a 24V DC power adapter, which is provided in the original packaging of this device.

This device needs to be upgraded to RouterOS v7.7 or the latest version to ensure compliance with local authority regulations!

It is the end user's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be professionally installed.

First steps:

Open the bottom lid;

Insert the SIM card into the slot;

Connect the device to the included PoE injector with Ethernet cable;

Connect the PoE injector into the PC or to the network switch;

Connect the power adapter to the PoE injector;

Navigate to the network connections section on your computer and locate the wireless network named "MikroTik-...". Proceed to connect to it (check the

wireless passwords on the sticker);

Configure via a wireless network using a mobile app. Alternatively, use a web browser through WebFig or the Winbox configuration tool ;

https://mt.lv/winbox

Download and open Winbox, and choose the Neighbors tab to find the device;

The default IP address is 192.168.88.1. Click on the IP address. If the IP is not available, use Winbox and connect using the MAC address. The username is

"admin" and there is no password (or, for some models, check user and wireless passwords on the sticker);

Click the "Check for updates" button and update RouterOS to the latest version;

For a manual update of the device, visit the products page at to find your product. The required packages are accessible under

https://mikrotik.com/products

the "Support&Downloads" menu;

Upload downloaded packages to the WebFig or Winbox "Files" menu and reboot the device;

By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;

In the "QuickSet" menu set up the following: Choose your country, to apply country regulation settings;

Set up your wireless network password in the left field;

Set up your router password in the bottom field;

Note: The RBwAPR-2nD (wAP R), RB912R-2nD-LTm (LtAP mini) devices come without a modem, install it before inserting a SIM card;

Safety Information:

Safety Information:Safety Information:

Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents. The installer should be familiar with network structures, terms, and concepts.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the

Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own

risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.

This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate

measures.

To avoid contamination of the environment, separate the device from household waste and dispose of it in a safe manner, for example, in designated areas.

Become familiar with procedures for properly transporting the equipment to designated collection points in your area.

This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an

Exposu

ExposuExposure

re re to

to to Radio

Radio

Radio Radio Frequency

Frequency

FrequencyFrequency

Radiation:

Radiation:Radiation:





uncontrolled environment. This MikroTik device should be installed and operated no closer than 38 centimeters from your body, occupational user, or the general

public.

Manufacturer: Mikrotikls SIA, Unijas iela 2, Riga, Latvia, LV1039.

BG - Български. Бързо ръководство

BG - Български. Бързо ръководствоBG - Български. Бързо ръководство:



Това е устройство за безжична мрежа. Можете да намерите името на модела на продукта на етикета на регистъра (ID).

Моля, посетете страницата с ръководството за потребителя на за пълното актуализирано ръководство за употреба.

https://mt.lv/um-bg

Или сканирайте QR кода с мобилния си телефон.

Технически спецификации, брошури и повече информация за продуктите наhttps://mikrotik.com/products

Най-важните технически спецификации за този продукт могат да бъдат намерени на последната страница на това Кратко ръководство.

Ръководство за конфигуриране на софтуер на вашия език с допълнителна информация можете да намерите на https://mt.lv/help-bg

Устройствата MikroTik са за професионална употреба. Ако нямате квалификация, моля, потърсете консултантhttps://mikrotik.com/consultants

Това устройство приема вход на 24V DC адаптер за захранване, който се предлага в оригиналната опаковка на това устройство.

Първи стъпки:

Първи стъпки:Първи стъпки:

Това устройство трябва да бъде надстроено до RouterOS v7.7 или най-новата версия, за да се гарантира спазването на местните регулаторни

разпоредби.

Крайните потребители са отговорни за спазването на местните разпоредби, включително работата в рамките на законни честотни канали,



извеждане на продукцияизисквания за захранване, окабеляване и изисквания за динамичен избор на честота (DFS). Всички радиоустройства

на MikroTik трябва да бъдатпрофесионално инсталиран.

Produkt Specifikationer

Mærke:	Mikrotik
Kategori:	Adgangspunkt
Model:	LTAP Mini LTE kit
Vekselstrømsindgangsspænding:	9 - 57 V
Bredde:	139 mm
Dybde:	77 mm
Højde:	28.5 mm
Produktfarve:	Sort
Ethernet LAN-porte (RJ-45):	1
Driftstemperatur (T-T):	-40 - 70 °C
Ethernet LAN-datahastigheder:	10, 100 Mbit/s
Intern hukommelse:	64 MB
Operativsystem installeret:	RouterOS
Strømforbrug (maks.):	9 W
Placering:	Bord
Netværksstandarder:	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
GPS (satellit):	Ja
Intern:	Ingen
Maksimal dataoverførselshastighed:	100 Mbit/s
Wi-Fi-datahastighed (maks.):	54 Mbit/s
USB-stik type:	Micro-USB
Flashhukommelse:	16 MB
Strøm over Ethernet (PoE):	Ja
Indbygget processer:	Ja
2.4 GHz:	Ja
5 GHz:	Ingen
WAN-forbindelse:	Mobilnetværk (SIM)
Niveau for antennestyrke (maks.):	1.5 dBi
RS-232 grænseflade:	Ja
