  SESPM‐4P‐ PMB OptionInstallGuide



33774Rev.A https://www.transition.com Page 1of 2

SESPM‐ ‐4P PMBPoleMountBracketKit

Option Install Guide

SESPM1040‐541‐LT‐xxSwitchPole Mounting UsingOptionalPoleMountBracket

SESPM‐4P‐PMB

Note:            For poles greater than 4” diameter, use pole straps (not provided) with bracket.

For less provided)poles than4”diameter,use ‐1 3/8” 1/4” bolts x ‐U(not withbrackets.

Note: PMBSESPM‐4P‐ installation is slightly AC anddifferentforthe ‐SESPM1040 541‐LT‐  ‐DCversions (machinescrews

are versusneededin 2 placesto toattach the heatsink) the‐PDversion(self‐tappingscrewscanbe used). 



SESPM‐4P‐PMBPartsList

Qty  DESCRIPTION

1 Packaging, 6 x    6,2MILReclosablePolyBag

1 Manual, PMB  SESPM‐4P‐ OptionInstallGuide 

2  PoleBracket,010685,Plastic,POE++ 

8 Screw, X  Self‐Tapping,SEMS,#6‐32 0.5"

2 Screw, x  Machine,TF,PPAN,10‐14 0.75

1 Packaging, 2 x    3,2MILReclosablePolyBag



  SESPM‐4P‐ PMB OptionInstallGuide



33774Rev.A https://www.transition.com Page 2of 2

SESPM‐4P‐PMBInstallProcedure

1. SeetheSESPM1040‐541‐LT‐xxInstallGuideforimportantCautionsandWarnings.

2. Unpackthekitandverifythecontents.

3. Mountupperbracket:

a. as Onthe–ACand–DC position upperbracket shown,insert andfourMachineScrews tighten.Repeatfor

Lowerbracket.

b. Onthe–PDpositionupper bracket asshown,inserttwo ScrewsSelf‐Tapping andtighten.

4. MountswitchwithSESPM‐4P‐ PMB attachedtopole. Use appropriate ‐U bolts(notincluded)ormetalstraps(not

included)to tosecureSESPM‐4P‐ PMB thepole.

  

SESPM1040‐541‐LT‐ACor‐DCwithPoleMountBracketKit KitSESPM1040‐541 Bracket‐LT‐PD with PoleMount  

    (Six  ‐    Self tapping and Two*Machine Screws) (Eight ‐  Self Tapping Screws)


