Side 1/7
1
This CO2 2 sensor changes the color of its LED light in accordance with the CO concentration within the room, optimizes the amount of airow, and thus
reduces the fresh air load.
■ This manual must be read both fully and carefully before commencing installation procedures; furthermore, the subsequent installation must be
performed correctly and safely in accordance with the instructions given.
■ After installation, ensure that this manual is given to the customer.
1. Safety Precautions
WARNING Incorrect handling could cause serious injury or death.
- Never modify or repair by yourself.
If the product is modied or inappropriately repaired, electric shock, re, etc. could result. Contact your dealer for repair.
- Do not move or reinstall the product by yourself.
If it is installed improperly, electric shock, re, etc. could result. Contact your dealer or technical representative.
-Usethespeciedcablesforwiringandconnectthemsecurely.Holdthecablessoasnottoapplyexternalforceofthecablestothe
connector.
Improper connection could result in heat generation or re.
-Allelectricalworkmustbeperformedbyalicensedtechnician,accordingtolocalregulationsandtheinstructionsgiveninthisInstallation
manual.
-Installtheproductinarmandstableplacetowithstandtheproductweight.
If the strength is inadequate, the product could drop and cause an injury.
- EnsurethatinstallationworkisdonecorrectlyfollowingthisInstallationmanual.
If it is installed improperly, electric shock, re, etc. could result.
- Close the control cover after installation.
-Donotinstalltheproductinaplacewhereammablegasesmayleak.
If gas should leak or accumulate around the product, re or explosion could result.
- Do not use the product in special environments.
The product could be damaged if it is used in locations subject to large quantities of oil (including machine oil), steam, or sulde gas.
-Donotinstalltheunitinaplacewherethetemperaturerisesabove40˚C(104°F),wherelargeamountsofoil,steam,organicsolvents,or
corrosivegases,suchassulfuricgas,arepresent,orwhereacidic/alkalinesolutionsorspraysareusedfrequently.
These substances can compromise the performance of the unit or cause certain components of the unit to corrode, which can result in electric shock,
malfunctions, smoke, or re.
- Donotinstalltheproductinaplacewherehighlyhumid,likeabathroom,orotherwetplace.
It could cause electric shock or injury.
CAUTION Incorrect handling could cause injury or damage to property or household e󰀨ects.
- Wire so that it does not receive any tension.
Tension could cause wire breakage, heating or re.
-Sealthecablefromthesensorcasewithputtyetc.
Any dew, moisture, cockroaches, insects entering the unit could cause electric shock or malfunctions.
-Putonglovesduringinstallation.
Failure to do so could cause injury.
-Toavoiddiscoloration,donotusebenzene,thinner,ethanol,hypochlorousacidorchemicalragtocleanthecase.Tocleanthecase,wipe
withasoftclothsoakedinwaterwithmilddetergent,wipeo󰀨thedetergentwithawetcloth,andwipeo󰀨waterwithadrycloth.
Lossnay CO Sensor Wall Mounted Type2-
PZ-70CSW-E
Installation and Instruction Manual
2107876H65401
2
2.Outlinedrawings,IncludedAccessories,and
Specications
■ Includedaccessories
Please conrm that the following accessory parts are included in the box.
1. Sensor case (top case, bottom case): x 1
2. Cross-slot pan-head screws M4x30: x 2
3. Wood screws 4.1x16: x 2
4. CO2 sensor cable (10 m (11 yards)): x 1*1
5. LED cable (10 m (11 yards)): x 1*2
6. LED display explanation nameplate: x 1
7. Safety caution for installation: x 1
■ Specications
Rated power supply voltage: 12 VDC (Supplied from the Lossnay)
Power consumption: 2 W or less.
Accessary wire length : 10 m (11 yards) [Maximum length is 20 m (22 yards) with eld supply extension]
Usage environment: 0 to 40 ˚C (32 to 104 ˚F), 80 % RH or less. (No Cigarette Smoke or Sulfur and with no dew condensation)
Detection range: 300 to 2000 ppm
Measurement accuracy: ± (70 + 5% of measurement value) ppm
Weight: 1.1 kg
LOW (Green LED) : CO concentration is below the threshold (1500 ppm at factory setting)2
MID (Orange LED) : CO concentration exceeds the threshold2
HIGH (Red LED) : CO concentration exceeds the threshold for a long time (20 minutes at factory setting).2
* 1: In the range of 0 ˚C (32 ˚F) or less, CO Sensor may not detect the correct CO2 2 Concentration.
* 2: Measures the CO sensor is installed. In addition, the measurement accuracy may vary depending 2 2 concentration around the location where the CO
on the usage environment, installation conditions, etc. but this is not a malfunction.
3. Installation Method
3.1 Determine the installation location for the sensor case
Ensure that you adhere to the following points.
(1) Ensure clear space around the case as shown in the gure on the right, regardless of whether it is
installed using a switch box or on a wall.
(2) Source the following items locally.
- Putty
<Extraitemsrequiredifinstallingusingaswitchbox>
- Single-gang switch box
- Thin steel conduit
- Lock nut and bushing
Note:
- Direct sunlight sometimes cause the sensor case to discolor. Please be careful when
deciding the install position.
- Determine the sensor installation location only after checking with local laws and
regulations.
- Ensure that no objects are placed in the clear space around the sensor case to detect the
correct CO concentrations.2
- Ensure a at surface is selected for the installation surface.
Cable access hole
■ Outlinedrawings
70(2 3/4) 26(1 1/32)
120(4 23/32)
83.5(3 9/32)
Unit: mm (inch)
*1
*2
30 (1 3/16)
30 (1 3/16)
120 (4 23/32)
30 (1 3/16)
Minimum required space
around the CO 2 sensor
Unit: mm (inch)
8
(5/16)
16
(
5/8
)
16
(
5/8
)
ø6
(
1/4OD
)
20
(
13/16
)
20
(
13/16
)
83.5±0.4
(
3
9/32±1/32
)
25
(
1
)
25
(
1
)
102
(
4
)
54
(
2 1/8
)
ø6
(
1/4OD
)
6
(
1/4
)
20
(
13/16
)
10
(
3/8
)
44
(
1 3/4
)
1.5(1/16)
or less
Unit: mm (inch)
