Marshall Electronics

Professional Audio Division

Phone: 310-333-0606



800-800-6608



Fax: 310-333-0688

www.mxlmics.com



sales@mxlmics.com

606

Condenser Instrument Microphone

Small Diaphragm

Thank you for choosing the MXL 606 Instrument Condenser microphone.

With proper care, this mic will provide many years of satisfaction. To get the

best results, please take a few moments to read this manual.

Enjoy your microphone!

The MXL Team

General Characteristics

This microphone has a twenty millimetre gold-sputtered diaphragm with a

ﬁxed cardioid pickup. In addition, the microphone has a switchable High

Pass Filter set at 6 dB/octave @ 150Hz useful for eliminating troublesome

unwanted low frequencies. In addition it has a 20 dB pad switch, (Pre-

attenuation switch) to prevent overloading the microphones internal

circuitry at high sound pressure levels. Condenser microphones are by

their nature very sensitive, readily revealing very subtle sonic details. They

also tend to pick up ambient sounds more than dynamic microphones,

which can lead to powerful feedback if you are not careful. We strongly

advise experimentationwith placement and isolation requirements with the

gain initially set low to avoid equipment and hearing damage!

Contents

Unpack your MXL 606 microphone carefully and verify that all of the

following items are included:

•MXL 606 microphone

•Carrying case

•Hard mount mic stand adapter

If any of these items are missing or damaged, contact the company from

which you purchased the microphone.

Power Requirement

The MXL 606 requires 48V phantom power (± 4V). If no sound is picked up

by the microphone, make sure that the phantom power on your mixer or

separate power supply is switched on.

Microphone Cable

The microphone cable can have a profound effect on the sound of

any microphone. Even the ﬁnest microphone will sound poor if the

interconnect cable allows noise to enter or causes distortion and loss of

information. We recommend that you use the best microphone cable that

your budget will allow.

Care

Dust and foreign material can reduce the performance of a microphone

over time, so you should store the MXL 606 in its case when not in use.

Speciﬁcations

Type Pressure gradient condenser mic

Diaphragm Gold-sputtered, 6 micron

Capsule Size 22mm/.87 in.

Frequency Response 20 Hz-20 kHz

Polar Pattern Cardioid

Impedance 150 ohms

Sensitivity -37dB re 1 V/Pa

S/N Ratio 77 dB

Equivalent Noise -17dBA (A-weighted IEC 268-4)

Max SPL for 0.5% THD 137dB SPL

High Pass Filter 6dB/Octave @150Hz

Pre-Attenuation Switch 0dB, -20dB

Power Requirement Phantom Power 48V ± 4V

Size 110mm x 23mm/4.3 in. x 0.89 in

Weight 0.25 lbs/113g

Metal Finish Nickel Plated

Polar PatternFrequency Chart

Warranty

Marshall microphones are guaranteed against defects in materials and

workmanship for one year from date of purchase. Should you encounter

any problem with this unit, promptly contact the company from which

you purchased it from for assistance. The original dated sales receipt

will be necessary for any warranty claim. Do not send any unit directly

to us without prior authorization from our service department. Warranty

coverage is limited to repair or replacement (at our option) of the

microphone, and does not cover incidental damages due to use of this

unit, nor damage caused by accidental misuse of this product.

90270

180

AD02092017a
