Side 1/2

A Division of Marshall Electronics

310-333-0606



800-800-6608



Fax: 310-333-0688

www.mxlmics.com



sales@mxlmics.com

Warranty

MXL microphones are guaranteed against defects in materials and workmanship

for one year from the date of purchase. If you encounter any problem with this unit,

promptly contact the company from which you purchased it for assistance. The

original dated sales receipt will be necessary for any warranty claim. Do not send

any unit directly to us without prior authorization from our service department.

Warranty coverage is limited to repair or replacement (at our option) of the

microphone, and does not cover incidental damages due to use of this unit, nor

damage caused by accidental misuse of this product.

R 14 4

Large Capsule

Condenser Microphone

Large Capsule

Condenser Microphone

V67G

Contents

Care

Unpack your Microphone package carefully and verify that all of the following items

are included:

• MXL V69G Microphone

• MXL MT-001 Mic Stand Adapter

If any of these items are missing or damaged, contact the company from which you

purchased the microphone.

Dust and foreign material can degrade the performance of a microphone over time,

so always store the unit in its box. For vocals closer than 3”, use a pop lter or a

foam windscreen to avoid getting moisture on the diaphragm as this can substantially

degrade the microphone’s performance. Store the microphone in its original packaging

in a cool, dry place along with the included packet of silica gel

Thank you for choosing the MXL V67G Microphone. For best results, please

take a few moments to read this manual and familiarize yourself with proper

operation and care of this microphone.

Frequency ChartPolar Pattern

Type: ........................................................Condenser microphone

Capsule: .................................... 25mm Gold Sputtered Diaphragm

Frequency Response: ...................................................... 30 Hz – 20 kHz

Polar pattern: ......................................................................................Cardioid

Sensitivity: ........................................................................................... 15mV/Pa

Impedance: ......................................................................................200 ohms

Equivalent Noise Level: .............20 dB (A-weighted IEC 268-4)

Max SPL for .5% THD: ............................................................................130 dB

Power Requirements: .......................................48V Phantom power

Size and Weight : 51 mm x 182 mm / 1.85 in. x 7.24 in. 395g / 1.3 lbs

Metal Finish: .............................................................Green with gold grill

Technical Specications

General Characteristics

This microphone has a one-inch gold sputtered diaphragm and a fairly wide xed

cardioid pickup pattern. Large capsule condensers are very sensitive, readily revealing

very subtle sonic details. They also tend to pick up sounds outside the pattern more

than some designs, which can lead to powerful feedback if you are not careful. We

strongly advise experimentation with placement and isolation requirements with the

gain initially set low to avoid equipment (and ear) damaging surprises.

Power Requirements

IMPORTANT - This unit requires phantom power at 48 volts, +/- 4 volts, in order to

operate. Each unit has been thoroughly checked before shipping, so if you do not

hear sound, check that the phantom power on your mixer or separate power supply

is switched on.

Microphone Cable

The microphone cable can have a profound effect on the sound of any microphone.

Even the nest microphone will sound poor if the interconnect cable allows noise to

enter or causes distortion and loss of information. We recommend that you use the

best microphone cable that your budget will allow.

Shock Mount

The MXL shock mount can shift in shipment. Simply shift the nylon bands to center the

microphone in the assembly. Be sure that the wire clamp does not rest on the chassis

of the mount, as this impairs mechanical isolation. Slide the mount all the way to the

rim of the microphone for the most secure hold.
